Heavy Duty Gas Griddles

924RX 936RX 948RX 960RX 972RX

MSA24 MSA36 MSA48 MSA60 MSA72

ASA24 ASA36 ASA48 ASA60 ASA72

VMG24 VMG36 VMG48 VMG60 VMG72

AGM24 AGM36 AGM48 AGM60 AGM72

- NOTICE -

This Manual is prepared for the use of trained Hobart Service Technicians and should not

be used by those not properly qualified.

This manual is not intended to be all encompassing. If you have not attended a Hobart Service

School for this product, you should read, in its entirety, the repair procedure you wish to

perform to determine if you have the necessary tools, instruments and skills required to

perform the procedure. Procedures for which you do not have the necessary tools,

instruments and skills should be performed by a trained Hobart Service Technician.

The reproduction, transfer, sale or other use of this manual, without the express written

consent of Hobart, is prohibited.

This manual has been provided to you by ITW Food Equipment Group LLC ("ITW FEG")

without charge and remains the property of ITW FEG, and by accepting this manual you agree

that you will return it to ITW FEG promptly upon its request for such return at any time in the

future.

SERVICE MANUAL

Vulcan and Wolf are divisions of ITW Food Equipment Group | 3600 North Point Blvd Baltimore, MD 21222

F25383 Rev. A (1023)

VMG48 948RX

TABLE OF CONTENTS

SERVICES UPDATES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SERVICE UPDATES ................................................................................... 3

TIS DOCUMENT LIST - 900RX SERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

GENERAL .................................................................................................. 4

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

INSTALLATION ........................................................................................ 4

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

CLEANING ............................................................................................. 4

SPECIFICATIONS ...................................................................................... 4

TOOLS ................................................................................................. 5

COMPONENT LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

REMOVAL AND REPLACEMENT OF PARTS ............................................................... 6

COVERS AND PANELS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

MOMENTARY POWER SWITCH (900RX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

ELECTRIC IGNITER (900RX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

GRAND MATE VALVE (MSA, ASA, 900RX) ............................................................. 7

THERMOSTAT VALVE ASSEMBLY (MSA, ASA, 900RX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

BURNER ............................................................................................... 9

PILOT, THERMOCOUPLE ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

SERVICE PROCEDURES AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

CALIBRATION ........................................................................................ 11

PILOT ADJUSTMENT ................................................................................. 12

GAS PRESSURE MEASUREMENT .................................................................... 12

GAS PRESSURE REGULATOR ADJUSTMENT ....................................................... 13

BURNER ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

THERMOCOUPLE TEST (MSA, ASA, 900RX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

ELECTRICAL OPERATION ................................................................................ 16

ELECTRICAL DIAGRAM (900RX) ..................................................................... 16

TROUBLESHOOTING ..................................................................................... 18

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Heavy Duty Gas Griddles

F25383 Rev. A (1023) Page 2 of 19
