TABLE OF CONTENTS

1 General Information ........................................................................................................................... 2

1.1 Description.............................................................................................................................. 2

1.2 Specifications.......................................................................................................................... 2

2 Safety Information................................................................................................................................ 2

3 Assembly.....……….............................................................................................................................. 2

4 Hydraulic Valve Adjustment................................................................................................................. 2

5 Operation.............................................................................................................................................. 4

6 Battery Charging & Replacement......................................................................................................... 5

7 Maintenance......................................................................................................................................... 7

8 Trouble Shooting.................................................................................................................................. 8

9 Hydraulic & Circuit Diagrams............................................................................................................... 9

9.1 Hydraulic Flow Diagram (Models Manufactured Before 2010)................................................ 9

9.2 Circuit Diagram (Models Manufactured Before 2010).............................................................. 9

9.3 Hydraulic Flow Diagram (Models Manufactured Between 2010 & 2015)................................. 10

9.4 Circuit Diagram (Models Manufactured Between 2010 & 2015).............................................. 10

9.5 Hydraulic Flow Diagram (Models Manufactured After 2015)................................................... 11

9.5 Circuit Diagram (Models Manufactured After 2015)................................................................. 11

10 Part Information (Models Manufactured Before 2010)......................................................................... 12

10.1 Handle Part Diagram................................................................................................................ 12

10.2 Handle Part List........................................................................................................................ 12

10.3 Frame Part Diagram................................................................................................................. 13

10.4 Frame Part List......................................................................................................................... 13

10.5 Pump Part Diagram.................................................................................................................. 14

10.6 Pump Part List.......................................................................................................................... 14

10.7 Steer Wheel Assembly Part Diagram....................................................................................... 15

10.8 Steer Wheel Assembly Part List............................................................................................... 16

10 Part Information (Models Manufactured Between 2010 & 2015)......................................................... 17

10.1 Frame & Handle Part Diagram................................................................................................. 17

10.2 Frame & Handle Part List......................................................................................................... 18

10.3 Pump Part Diagram.................................................................................................................. 19

10.4 Pump Part List.......................................................................................................................... 20

11 Part Information (Models Manufactured After 2015)............................................................................ 21

11.1 Handle Part Diagram................................................................................................................ 21

11.2 Handle Part List........................................................................................................................ 21

11.3 Frame Part Diagram................................................................................................................. 22

11.4 Frame Part List......................................................................................................................... 22

11.5 Pump Part Diagram.................................................................................................................. 23

11.6 Pump Part List.......................................................................................................................... 24

11.7 External Charger Part Diagram................................................................................................ 25

11.8 External Charger Part List........................................................................................................ 26

WESCOINDUSTRIALPRODUCTS,LLC



InstructionManual

ElectricNon‐TelescopingHighLiftTruck



PartNumber: 272460&272461



Note: Operator MUST read and understand these operating instructions before using

this High Lift Truck.

Page2of26







Electric Non-Telescoping High Lift Truck

(Part # 272460 & 272461)

Instruction Manual

ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR HIGH LIFT TRUCK,

READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.

WARNING: The battery in this product contains lead. The State of California under

Proposition 65 has determined that exposure to lead is known to cause cancer or birth

defects or other reproductive harm. Please wash hands after use.

1. GENERAL INFORMATION

1.1 DESCRIPTION

Thank you for purchasing an Electric Non-Telescoping High Lift Truck. This truck has been

designed for transporting and horizontal lifting of loads of up to 2,200 lbs.

The electric high lift trucks

feature a one year pump warranty and a battery powered hydraulic lift system that is operated with fingertip

controls. It can greatly reduce labor and increase working efficiency and is an efficient tool for various work

environments.

1.2 SPECIFICATIONS

Model 272460 272461

Capacity 2,200 lbs 2,200 lbs

Weight 367 lbs 372 lbs

Fork Lowered Height 3.3” 3.3”

Fork Raised Height 31” 31”

Single Fork Width 6.5” 6.5”

Fork Length 45” 45”

Overall Width 21” 27”

Overall Length 60” 63”

Overall Height 48.5” 48.5”

Telescoping No No

Steering & Load Wheels Polyurethane Polyurethane

Materials and specifications are subject to change without notice.

2. SAFETY INFORMATION

1) Read the manual carefully before operation. Go through every procedure as required in the

manual.

2) Lift the fork to its full range a few times before use to release the air in the hydraulic system.

3) Do not lift or pull personnel with the truck.

4) Do not operate the unit on sloped or tilted surfaces.

5) Do not put your hand or foot under the fork or into the moving parts

6) Put all loads in the center of the fork.

7) The safety valve in the pump station will automatically open when the unit becomes overloaded. If

this occurs, don’t try to lift the load any more by pushing the “UP” button. This will reduce the

lifespan of the pump unit.

8) Power off the unit when not in use.

9) To replace or fill hydraulic oil, the fork should be lowered to its lowest position. The oil to be used

should be clean and filtered. The condensation point of the oil should be ≤ -4˚F (-20˚C), and the

motion viscosity should be 20–30 cst.

Note: Hydraulic Oil ISO VG 32 and multipurpose lubricating grease ZG2# or 3# are recommended

for maintenance of this unit.


