Side 1/11

Page  1of 11



TABLE OF CONTENTS

1 General Information ......................................................................................................... 2

1.1 Description.............................................................................................................. 2

1.2 Specifications.......................................................................................................... 2

2 Assembly & Adjustment..................................................................................................... 2

3 Trouble Shooting............................................ ................................................................. .. 4

4 Fork Frame Information..................................................................................................... 5

4.1 Fork Frame Parts Diagram...................................................................................... 5

4.2 Fork Frame Parts List.............................................................................................. 6

5 Pump Assembly Information.............................................................................................. 7

5.1 Pump Assembly Parts Diagram............................................................................... 7

5.2 Pump Assembly Parts List....................................................................................... 8

6 Handle Assembly Information............................................................................................ 10

6.1 Handle Assembly Parts Diagram............................................................................. 10

6.2 Handle Assembly Parts List..................................................................................... 11



WESCOINDUSTRIALPRODUCTS,INC



InstructionManual

TelescopingManualHigh Lift Truck



Part Number: 272754,272755, 272975 272976  &



Note: Operator MUST read and understand these operating instructions before

using this Truck.



Page  2of 11







Telescoping Manual High Lift Truck

(Part # 272754, 272755, 272975 & 272976)

Instruction Manual

ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HIGH LIFT

TRUCK, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.

1. GENERAL INFORMATION

1.1 DESCRIPTION

Thank you for purchasing a Wesco Telescoping Manual High Lift Truck. This pallet truck is

designed for transporting and horizontal lifting. The trucks feature a 180° steering arc, loop handles

with inside hand control and a 1 year pump warranty.

1.2 SPECIFICATIONS

Model 272754 272755 272975 272976

Capacity 2,200 lbs 2,200 lbs 3,300 lbs 3,300 lbs

Weight 228 lbs 219 lbs 260 lbs 276 lbs

Fork Lowered Height 3.3” 3.6” 3.6” 3.6”

Fork Raised Height 31.5” 31.5” 31.5” 31.5”

Single Fork Width 6.5” 6.5” 6.5” 6.5”

Fork Length 44.5” 44.5” 43” 43”

Overall Width 27” 21” 20” 27”

Overall Length 63” 63” 63” 63”

Overall Height 48.5” 48.5” 48.5” 48.5”

Telescoping Yes Yes Yes Yes

Steering & Load Wheels Polyurethane Polyurethane Polyurethane Polyurethane

Materials and specifications are subject to change without notice.

2. ASSEMBLY & ADJUSTMENT

1) Screw (Item 158)

- To prevent oil-leaking from oil tank during transportation the air screw (Item 158) is replaced with

oil-sealing screw in the factory. Upon reaching its destination and before operation the air screw

must be inserted back in place. Screw out the Oil-sealing screw, then screw in the air screw

which the pump housing (Item 160) is hung.

2) Handle

- During transportation, the handle is disassembled from the truck and packed separately. It must

be properly reassembled before operation of the unit.


