Side 1/9

Page 1of9







InstructionManual

HandWinch Lift (

djustableStraddle

)



PartNumber:

   273512, 273513 & 273514



Note: Operator MUST read and understand these operating instructions before using this Lift.

Table of Contents

1 General Information ......................................................................................................... 1

1.1 Description...................................... ................................................... ..................... 1

1.2 Specifications.......................................................................................................... 2

2 Pre-Operation.................................................................................................................... 2

2.1 Inspection................................................................................................................. 2

3 Assembly.......................................................................................................................... 3

4 Function Tests....................................... ............................................................ ................ 6

3.1 Test Brake Operation............................................................................................... 4

3.2 Test Winch Operation.............................................................................................. 4

3.3 Braking..................................................................................................................... 4

3.4 Parking..................................................................................................................... 4

5 Operation........................................................................................................................... 6

5.1 Raising and Lowering Load-Manual Winch............................................................. 6

5.2 Moving Machine with a Load................................................................................... 7

5.3 Transporting Unit..................................................................................................... 7

5.4 Loading Unit............................................................................................................. 7

5.5 Positioning Load...................................................................................................... 7

5.6 Extended Storage.............................. ....................................................... ............... 7

6 Part Information................................................................................................................. 8

6.1 Part Diagram............................................................................................................ 8

Hand Winch Lifter (Adjustable Straddle)

(Part # 273512, 273513 & 273514)

Instruction Manual

ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HAND WINCH

LIFTER, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.

Page 2of9



6.2 Part List.................................................................................................................... 9





Hand Winch Lifter (Adjustable Straddle)

(Part # 273512, 273513 & 273514)

Instruction Manual

ATTENTION: TO INSURE SAFE AND EASY USE OF YOUR WESCO HAND WINCH

LIFTER, READ THESE INSTRUCTIONS ENTIRELY BEFORE USING.

1. GENERAL INFORMATION

NOTE: All of the information reported herein is based on data available at the moment of printing. We reserve the

right to modify our own products at any moment without notice and liability in any sanctions. So, it is suggested to

always verify possible updates and changes.

1.1 DESCRIPTION

Thank you for purchasing a Wesco Manual Winch Lift. This unit is designed to lift material to and

from shelves, move office equipment and install ceiling and wall appliances on level surfaces, including

workshops, warehouses, stockrooms, receiving departments. It is perfect for when aisles and congested

areas prevent the use of larger equipment. It is constructed of durable steel with a lightweight aluminum

frame. The forks can be inverted to provide two different lift heights. It is operated by a hand-crank winch.

1.2 SPECIFICATIONS

Part

Number

Model #

Load

Cap.

(lbs)

Lifting Height (in.) Overall Dimensions (in.)

Load

Center

(in)

Forks Up

Forks

Down

L W H

273510 HWLFX-4 400 120.5 99 34-1/2 24 67 10

273511 HWLFX-5 500 71 48.5 34-1/2 24 67 10

273512 HWLSD-3.5 350 142 120 43 29 79-3/4 10

273513 HWLSD-4 400 120.5 99 43 29 67 10

273514 HWLSD-5 500 71 48.5 43 29 67 10

273515 HWLCB-3.5 350 140 118.5 46 29 79-3/4 10

273516 HWLCB-4 400 120.5 99 46 29 67 10

273517 HWLCB-5 500 71 48.5 46 29 67 10

Materials and specifications are subject to change without notice.

2. PRE-OPERATION

2.1 Inspection

A visual inspection should be performed by the operator prior to each work shift. This inspection is designed

to discover if anything is apparently wrong with a machine before the operator test it.

Inspect the machine for modifications, damage or loose or missing parts. A damaged or modified machine

must never be used. If damage or any variation from factory delivered condition is discovered, the machine

must be tagged and removed from service. Repairs to the machine may only be made by a qualified service

technician, according to the manufacturer’s specifications. After repairs are completed, the operator must

perform a per-operation inspection again before testing the machine functions.

Check the following components or areas for damage, modifications and improperly installed or missing parts:

- Winch and related components

- Base components - Cable Anchor - Cable (frays, abrasions)

- Legs - Cable and pulleys -Brake system (if equipped)

- Roller wheels - Carriage hold-down assembly - Wheels and casters

- Inner and outer frames - Forks - Glide buttons

Check the entire machine for:

- Dents or damage

- Corrosion or oxidation

- Cracks in welds or structural components
