Side 1/2

drain pan

motor

rear view of

refrigerator

KIT CONTENTS INSTRUCTIONS

FRIDGE DESCRIPTION

DESCRIPTION

Cover top cabinet wh GR

Cover top cabinet wh WHT

Ensure refrigerator is empty of all loose items and unplugged

from power source.

1. Remove top door by opening 45º and gently slide off hinge.

Set door aside to prevent damage.

Unscrew 2 centre hinge screw. Remove the cover hole

mullion with plastic lever. Do not discard screws

(if screws loosen can be use spare in kit content).

Remove RH centre hinge by lifting the door slightly and

sliding hinge out of the door.

Remove bottom door by opening 45º and gently slide off

hinge. Set door aside to prevent damage.

10.

Remove the cover door from top door and assemble it on

the other side. Remove the RH door auto closer and replace

with LH door auto closer (kit content) on the other side.

Repeat the same step with bottom door.

11.

Store power cord next to motor to prevent damage.

Check for water in drain pan and remove any water with

a cloth or sponge if necessary.

Lay the refrigerator on its back.3.

Remove the hinge cover with a soft plastic lever.4.

Remove the LH cap with a soft plastic lever.5.

Unscrew top hinge screws and remove RH top hinge.

Do not discard screws.

Cover top cabinet right GR

Cover top cabinet right WHT

Hinge top cover left GR

Hinge top cover left WHT

Hinge top left 1

Hinge centre left 1

Hinge bottom base left 1

Door auto closer LH 2

Screw centre mullion M5x8 3

Screw centre hinge M5x16 2

Cover screw mullion WH WHT

NOTE: Keep kit parts separate from other parts as you disassemble

them to avoid mix-ups.This installation manual is applicable to both

top freezer and bottom freezer models.

Phillips head screwdriver 8mm (5/16") hex head socket

TOOLS YOU WILL NEED (not supplied)

WARNING

Electrolux/Westinghouse takes no responsibility for incorrectly

assembled doors leading to injury or malfunction.

QTY

INSTALLATION MANUAL

REFRIGERATOR DOOR REVERSAL KIT

Models: ETB3200MG,ETB3400H,ETB3400J,ETB3400K,ETB3440K,ETB3700H,ETB3700J,ETB3700K,ETB3740K,ETM3100L,ETM3100SC,ETM3400L,ETM3440L,ETM3400SC,ETM3400BC,HTB3500AG,RTM3400L,

WTB3100AK,WTB3400AH,WTB3400AK,WTB3400WK,WTB3440WH,WTB3700AH,WTB3700WH,WTB3700WK,WTM3100WL,WTM3100SL,WTM3400WL,EBB3402K,EBB3442K,EBM3402L,EBM3442L,EBB3700H,

EBB3702K,EBB3742K,HBB3200AG,WBB3100WK,WBB3100AK,WBB3400AH,WBB3400HK,WBB3400WK,WBB3400AK,WBB3402BL,WBB3402WL,WBB3700AH,WBB3700HK,WBB3700AK

This installation manual is applicable to both top freezer (top mount) and bottom freezer (bottom mount).

WARNING

Your refrigerator is heavy – you may need assistance.

CAUTION

Refrigerator must stand for 30 minutes prior to connecting to

power supply to ensure system functions correctly.

IMPORTANT

All hinge screws require tightening to a torque setting of 5-10Nm.

Bottom view of right hand hinge cabinet

1 Cover top cabinet WH

2 Hinge top right and hinge
