GB -1-
Chart
START/RESUME BUTTON
Push this button to start the selected program: the
indicator lights up and goes off at the end of the
program.
When the door is opened during a washing cycle,
the cycle is temporarily paused: the Start indicator
blinks. To resume the cycle close the door and
push Start button again.
PROGRAM SELECTION
BUTTON
Push “Programs” button
(repeatedly) until the indicator
of the required program lights
up (see “Table of programs”
below).
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute.
If pressed when the dishwasher is switched off it
drains any possible liquids from dishwasher (1
minute process).
If the indicator flashes repeatedly, see page 6 -
chapter ”What to do if ...”.
(see at right for options description)
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional
options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the
appliance’s automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information
on the EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.
Table of programs
Deter-
gent
Consumption
PPrograms Available
options Loading instructions Litres kWh Minutes 1)
1Pre-Wash cold Delay Crockery to be washed later. — 4.0 0.03 14
2Quickwash 45°C Delay Lightly soiled crockery, with no dried-
on food. X 11.0 0.80 30
3Eco 2) 50°C Delay Normally soiled crockery.
Energy-saving program. X 12.0 1.05 165
4Antibacterial 3) Delay
Normally or heavily soiled crockery,
with additional antibacterial wash.
Program interruption (e.g. due to door
opening) can compromise elimination
of germs.
X 13.0 1.50 115
5Intensive 70°C Delay
Recommended program for heavily
soiled crockery, especially suitable for
pans and saucepans.
X 14.0 1.55 155
5019 396 01953ADG 4620
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
Options and display description
SALT INDICATOR
When lit (at the end of the
cycle), the salt reservoir
needs to be refilled.
DELAYED START
BUTTON
The wash cycle can be
programmed to start
after 2, 4 or 8 hours.
Then press the Start
button. The wash
program will start after
the set time.
RINSE AID INDICATOR
When lit (at the end of the
cycle), the rinse aid
dispenser needs to be
refilled.
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
ANY BUTTON EXCEPT CANCEL/OFF BUTTON.
FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES
AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.
TABLET SETTING
This setting allows to optimize the cycle performances
according the type of detergent used.
Push the Tablet button for 3 seconds (until the indicator
lights up) if you are using the combined detergents in
tablet (rinse aid, salt and deteregent in 1 dose).
If you are using powder detergent or liquid detergent,
the Tablet indicator on the control panel has to be off.
Quick reference guide
