Whirlpool ADG6500 Manual

Whirlpool Opvaskemaskine ADG6500

Læs gratis den danske manual til Whirlpool ADG6500 (8 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Whirlpool ADG6500, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/8

-1-

Chart

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute.

If pressed when the dishwasher is switched off it

drains any possible liquids from dishwasher (1

minute process).

If the indicator flashes repeatedly, see page 6 -

chapter ”What to do if ...”.

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the

program. When the door is opened during a

washing cycle, the cycle is temporarily paused: the

Start indicator blinks.

To resume the cycle push the Start button and

close the door within 3 seconds.

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions

(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible

with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for

detailed information on the EN/Standard loading comparison test and other tests, contact the following address:

“nk_customer@whirlpool.com”.

Table of programs

Deter-

gent

Consumption

Programs Loading instructions

Litres kWh

Minutes

1 Pre-Wash cold

Crockery to be washed later. — 5.0 0.02 10

2 Quickwash 40°C

Lightly soiled crockery, with no

dried-on food.

X 13.0 0.70 30

Eco

50°C

Normally soiled crockery.

Energy-saving program.

X 15.0 1.05 165

4 Intensive 70°C

Recommended program for

heavily soiled crockery, especially

suitable for pans and saucepans.

X 15.0 1.50 140

5 Half Load 50°C

Ideal for washing a half load of

lightly or normally soiled crockery.

X 13.0 1.00 130

5019 396 03515ADG 6500

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ

THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING

ANY BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

Quick reference guide

-2-

First time use

1- salt reservoir

2- rinse aid dispenser

3- detergent dispenser

4- racks system

5,6,7,8- available functions on the panel

9- filters

10- spray arms

Ask your water supply company what the

water hardness

is...

...enter this value on

your dishwasher

Suggestions for detergent use

German

degrees °dH

French

degrees °fH

English

degrees °eH

Water hardness

level

3 first PROGRAM LEDs

lit on the panel

(see table of programs)

P1 P2 P3

Gel or Powder

(rinse aid and

salt)

Tablets

0 - 5 0 - 9 0 - 6.3 Soft 1

go to step 1

(see “Daily

check”)

6 - 10 10 - 18 7 - 12.6 Medium 2

11 - 15 19 - 27 13.3 - 18.9 Average 3

16 - 21 28 - 37 19.6 - 25.9 Medium-hard 4

if water is

HARD extra salt

needs to be

added

(go to step 1,

“Daily check”)

22 - 28 38 - 50 26.6 - 35 Hard 5

29 - 35 51 - 63 35.7 - 44.1 Very hard 6

36 - 50 64 - 90 44.8 - 62.4 Extremely hard 7

Water hardness should be set only

before the first wash or if water

hardness has been changed

Visual indicator

(depending

on the model).

Unscrew cap.

Fill the salt reservoir with water

before the first wash only.

(depending on the model)

The salt level indicator lamp may remain lit

at the end of several wash cycles. If the

water hardness level falls within category

(soft), no salt is required.

Salt indicator on the control panel Salt indicator on the salt reservoir cap

The indicator lamp lights up when SALT

NEEDS TO BE ADDED.

green: OK.

clear: NEEDS TO

BE ADDED

Daily check

Filling the salt reservoir -

Dissolve limescale (not necessary if water hardness level is set to “soft”!)

-Press and hold together Programs and CANCEL/Off buttons for minimum 3 seconds.

- Programs LEDs will indicate the water hardness setting.

-Press the

Programs

button to increase setting (when the level reaches 7, the next key press will set the level back to 1.

- Wait 30 seconds (control panel switches off) or press

START/Resume

button to save setting.

Add salt (never add detergent!)

min. 0.8 kg / max. 1 kg

Water hardness level is factory

set for medium-hard water

(level 4).

Even if you use tablets which

include salt functionality, you

must still add regeneration salt

since such detergents are not

effective enough at softening

hard water.

Screw on the cap.

Salt residual

around the cap

need to be

removed. Some

salt reservoir have

a level indicator

integrated in the

cap (see below

how to check).

At first time use, the salt reservoir has to be filled independently from water hardness level (see description below in step 1 “Daily check”).

How to set water hardness in order to always assure the best cleaning results

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG6500
