Side 1/8

-1-

Chart

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the

program.

When the door is opened during a washing cycle,

the cycle is temporarily paused: the Start indicator

blinks. To resume the cycle close the door and

push Start button again.

PROGRAM SELECTION

BUTTON

Push “Programs” button

(repeatedly) until the indicator

of the required program lights

up (see “Table of programs”

below).

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute.

If pressed when the dishwasher is switched off it

drains any possible liquids from dishwasher (1

minute process).

If the indicator flashes repeatedly, see page 6 -

chapter ”What to do if ...”.

(see at right for options description)

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions

(without additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible

with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for

detailed information on the EN/Standard loading comparison test and other tests, contact the following address:

“nk_customer@whirlpool.com”.

Table of programs

Deter-

gent

Consumption

Programs

Available

options

Loading instructions

Litres kWh

Minutes

Pre-Wash cold

Delay

Crockery to be washed

later.

— 4.0 0.03 14

Quickwash 45°C

Delay

Lightly soiled crockery, with

no dried-on food.

X 11.0 0.80 30

Eco

50°C

Delay

Normally soiled crockery.

Energy-saving program.

X 12.0 1.05 165

Intensive 70°C

Delay

Recommended program for

heavily soiled crockery,

especially suitable for pans

and saucepans.

X 14.0 1.55 155

Half Load 50°C

Delay

Ideal for washing a half load

of lightly or normally soiled

crockery.

X 10.0 1.04 145

5019 396 01927ADG 5820

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ

THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

SALT INDICATOR

When lit (at the end of the

cycle), the salt reservoir

needs to be refilled.

DELAYED START

BUTTON

The wash cycle can be

programmed to start

after 2, 4 or 8 hours.

Then press the Start

button. The wash

program will start after

the set time.

RINSE AID INDICATOR

When lit (at the end of the

cycle), the rinse aid

dispenser needs to be

refilled.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING

ANY BUTTON EXCEPT CANCEL/OFF BUTTON.

FOR ENERGY SAVING THE CONTROL PANEL DEACTIVATES

AUTOMATICALLY AFTER 30 SECONDS IF NO CYCLE HAS STARTED.

TABLET SETTING

This setting allows to optimize the cycle performances

according the type of detergent used.

Push the Tablet button for 3 seconds (until the indicator

lights up) if you are using the combined detergents in

tablet (rinse aid, salt and deteregent in 1 dose).

If you are using powder detergent or liquid detergent,

the Tablet indicator on the control panel has to be off.

Quick reference guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG 5820 IX
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	570 mm
Højde:	820 mm
Vægt:	43000 g
Strøm:	10 A
Ledningslængde:	1.5 m
Energieffektivitetsklasse (gammel):	A
Årligt energiforbrug:	327 kWh
Placering af apparat:	Delvist indbygget
Støjniveau:	48 dB
Tilløbsslange, længde:	1.5 m
Antal vaskeprogrammer:	5
Forsinket start-timer:	Ja
Dør farve:	Ikke anvendelig
Balje materiale:	Rustfrit stål
Vaskeklasse:	A
Vandforbrug pr. cyklus:	- L
Farve på kontrolpanel:	Black, Stainless steel
Antal kuverter:	12 kuverter
Forsinket start (maks.):	8 t
Opvaskeprogrammer:	Eco, Intensive, Quick
Tørringsklasse:	A
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	- kWh
Udøsslange længde:	2 m
Saltindikator:	Ja
