Side 1/8

GB -1-

Chart

ON/OFF

BUTTON

PROGRAMME

AND DELAY

SELECTOR

KNOB

(see at right for

options description

and “Table of

programmes” below).

START BUTTON

The indicator lights up during operation, flashes when a fault occurs, and goes off

at the end of the programme.

START BUTTON RESET FUNCTION:

Press this button for at least 2 seconds; the selected programme and options will

be cancelled. Main failure displays (repeated flashing of the START indicator lamp)

can be cancelled by RESETTING. Detailed instructions are given in chapter

“What to do if...”.

1) Programme data obtained in conformity with European standard EN 50242, obtained under normal conditions (without additional

options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor programmes as a result of

the appliance’s automatic calibration system.

2) Reference programme for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on

the EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

Table of programmes

Deter-

gent

Consumption

PProgrammes Available

options Loading instructions Litres kWh Minutes 1)

1Pre-Wash cold Delay Crockery to be washed later. — 4.0 0.03 14

2Quickwash 40°C Delay Lightly soiled crockery, with no dried-on

food. * Use of tablets not recommended. X*10.0 0.65 30

3Eco 2) 50°C Delay Normally soiled crockery. Energy-saving

programme. X 12.0 1.05 165

4Antibacterial 3) Delay

Normally or heavily soiled crockery, with

additional antibacterial wash. Programme

interruption (e.g. due to door opening) can

compromise elimination of germs.

X 13.0 1.50 115

5Intensive 70°C Delay

Recommended programme for heavily soiled

crockery, especially suitable for pots and

pans.

X 14.0 1.55 155

Switch on the appliance

- press the ON/OFF button.

OK/Start lamp flashes.

Set the desired start delay (3-6-9h). The

selected start delay lamp (3-6-9h)

flashes.

Press the OK/Start button for

confirmation. After that the OK/Start

lamp switches off and the selected start

delay lamp lights up.

If you wish another time setting, press

OK/Start button again.

Turn the programme knob to your

desired programme position.

The OK/Start lamp flashes.

Press the OK/Start button for

confirmation.

After that the OK/Start lamp lights up.

The dishwasher starts immediately or

after the start delay selected.

For a Reset, press the OK/Start button at

a minimum of 2 seconds.

All settings are cancelled.

Indication: In the selection mode, all

described settings have to be selected

within 30 seconds, otherwise no settings

will be saved.

5019 396 01750ADP Space

Options and display description

BEFORE USING THE APPLIANCE FOR THE

FIRST TIME CAREFULLY READ THIS QUICK

REFERENCE GUIDE AND THE INSTALLATION

INSTRUCTIONS! THE GUARANTEE IS NOT

APPLICABLE IF FAULTS ARE CAUSED BY

INCORRECT USE OF THE APPLIANCE.

Programme settings

without start delay

Start delay and

programme settings

Quick reference guide

GB -2-

First time use

1- salt reservoir

2- rinse aid dispenser

3- detergent dispenser

4- racks system

5,6,7,8- available functions on the panel

9- filters

10- spray arms

In order to always ensure the best cleaning

results, you NEED to set:

DETERGENT type and WATER HARDNESS.

1. Select 3rd programme

(see Table of programmes

- page 1)

2. Press START button

for 7 seconds

3a. Check your

detergent type...

3b....and set it on your dishwasher

using the START button

(as per table below)

4. Remember to use salt and rinse

aid when needed (as indicated

below)

5. Switch off and switch on

again to save setting

Detergent

types

Dishwasher models

model without

display model with display

Powder or gel

(factory setting) no symbol add salt add rinse aid

Tablet 2 in 1 add salt

Tablet 3 in 1

Tablet All in 1

For models without “detergent type” option, the salt and rinse aid indicators will be lit when tablets are used.

3h 6h 9h

rinse aid

salt rinse aid

1. Ask your water supply company what the water hardness is... 2. ...enter this value on your

dishwasher Suggestions for detergent use

German

degrees °dH

French

degrees °fH

English

degrees °eH

Water

hardness

Dishwasher

with display:

insert value in

the display

Dishwasher

without

display: count

START button

led flashes

Gel or Powder

(rinse aid and

salt)

Tablets

0 - 5 0 - 9 0 - 6.3 Soft 1 1x

go to step 1

(see “Daily

check”)

if extra salt is

needed go to

step 1

(see “Daily

check”)

6 - 10 10 - 18 7 - 12.6 Medium 2 2x

11 - 15 19 - 27 13.3 - 18.9 Average 3 3x

16 - 21 28 - 37 19.6 - 25.9 Medium-hard 4 4x

22 - 28 38 - 50 26.6 - 35 Hard 5 5x

29 - 35 51 - 63 35.7 - 44.1 Very hard 6 6x

36 - 60 64 - 107 44.8 - 74.9 Extremely

hard 7 7x

How to set water hardness

only before the first wash or if the

water hardness has been changed

Switch on the appliance

- Select the 2nd programme “P2” - consult the table of programmes.

- Press the START button for at least 5 seconds until the START indicator lamp flashes.

- The water hardness setting is shown on the display (if present) or the START button flashes.

- With each successive touch of the START button the setting increases and when it reaches 7 it returns to 1 again.

- The appliance must be switched off to memorise the new setting.

Even if you use tablets which include salt,

you must still add salt since such

detergents are not effective enough at

softening hard water.

Water hardness level is factory set for

medium hard water (a number “4” is

shown on the display or the START

indicator lamp flashes 4 times).

How to set detergent type: powder/gel/tablet (if option is available)

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG SPACE IX
Vekselstrømsindgangsspænding:	220 - 230 V
Bredde:	597 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	50000 g
Placering af apparat:	Delvist indbygget
Støjniveau:	48 dB
Antal vaskeprogrammer:	5
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	12 L
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	- kuverter
Cyklustid:	165 min.
Tørringsklasse:	A
Energiforbrug pr. cyklus:	1.05 kWh
Pakkens dimensioner (BxDxH):	640 x 660 x 845 mm
