AKP 290 PRODUCT SHEET

IT AT FR NL BE SE NO DK FI PL CZ SK HU RU BG RO

5019 310 56638

1. Control panel

2. Cooling fan (not visible)

3. Upper heating element

4. Grill heating element

5. Rear oven lamp

6. Circular heating element (not visible)

7. Fan

8. Lower heating element (hidden)

9. Oven cool door

ACCESSORIES

CONTROL PANEL

1. Function selector knob

2. Analog clock

3. Thermostat knob

4. Red thermostat led

ANALOG CLOCK

The analog clock allows:

1) Viewing the time of the day. To adjust the time of the day, press the button (B)

and turn it anticlockwise to set the time.

2) Programming the cooking start time. The maximum programmed cooking start time is 12 hours.

Programming the cooking time. Select the cooking time (available with any function) to turn the oven on for a

specified period of time. At the end of the specified time the oven will switch off automatically. The minimum

programmed cooking time is 5 minutes and the maximum programmed cooking time is 180 minutes.

a) MANUAL COOKING

1) Turn the button (B) anticlockwise (without pressing), until the symbol is displayed in the window .

2) Press the button (A) and turn it anticlockwise until the triangle (D) points to the time shown on the clock (hour hand).

The button clicks when turned to the proper position.

3) Turn the selector knob to the required symbol. The oven light switches on.

4) Turn the thermostat knob clockwise to the required temperature. The red thermostat indicator light switches on.

5) At the end of cooking, turn the knobs to OFF (0 - •) because in manual mode the oven will NOT switch off automatically.

Bottom

To p

shelf

Drip tray: Wire shelve:

b) MANUAL COOKING WITH COOKING START TIME

1) Turn the button (B) anticlockwise (without pressing), until the symbol is displayed in the window .

2) Press the button (A) and turn it anticlockwise until the triangle (D) points to the time at which cooking is to start (e.g. in figure: 11.30).

3) Turn the selector knob to the required symbol.

4) Turn the thermostat knob clockwise to the required temperature.

5) At the end of cooking, turn the knobs to OFF (0 - •) because in manual mode the oven will NOT switch off automatically.

c) PROGRAMMED COOKING WITH COOKING START TIME AND COOKING DURATION

1) Turn the button (B) anticlockwise (without pressing) until the required cooking duration is displayed in the window (C) (5 - 180 min.).

2) Press the button (A) and turn it anticlockwise until the triangle (D) points to the time at which cooking is to start (e.g. in figure: 11.30).

3) Turn the selector knob to the required symbol.

4) Turn the thermostat knob clockwise to the required temperature.

5) At the end of the set cooking time an acoustic signal will sound and the oven will switch off automatically. To exclude the acoustic

signal, turn button (B) anticlockwise (without pressing) until the symbol is displayed in the window.

6) At the end of the set cooking time, cooking may be prolonged by following the instructions given above, or by using the

manual cooking procedure.

d) PROGRAMMED COOKING WITH COOKING DURATION

1) Turn the button (B) anticlockwise (without pressing) until the required cooking duration is displayed in the window (C) (5 - 180 min.).

2) Press the button (A) and turn it anticlockwise until the triangle (D) points to the time shown on the clock (hour hand). The

button clicks when turned to the proper position.

3) Turn the selector knob to the required symbol. The oven light switches on.

4) Turn the thermostat knob clockwise to the required temperature. The red thermostat indicator light switches on.

5) At the end of the set cooking time an acoustic signal will sound and the oven will switch off automatically. To exclude the acoustic

signal, turn button (B) anticlockwise (without pressing) until the symbol is displayed in the window.

At the end of the set cooking time, cooking may be prolonged by following the instructions given above, or by using the

manual cooking procedure

HOW TO OPERATE THE OVEN

• Turn the selector knob to the required function. The oven light switches on.

• Turn the thermostat knob clockwise to the required temperature. The red thermostat led lights up, switching off again when the oven

reaches the selected temperature.

At the end of cooking time:

• Turn the knob to “0”.

Oven function chart

Function

Description of function

0OVEN OFF

LAMP

• To switch on the oven light.

STATIC

• To cook meat, fish and chicken on the same level.

• Preheat the oven to the required cooking temperature and place the food

inside as soon as the red thermostat L.E.D. switches off.

• Ideally, the second or third shelf level should be used.

PASTRY/FAN

• To cook on up to two different shelf levels.

• If necessary, switch the positions of the dishes to cook food more evenly.

• It is not necessary to preheat the oven (except for pizzas and focaccias).

GRILL

• To grill steak, kebabs and sausages, to cook vegetables au gratin and to toast

bread.

• Preheat the oven for 3 - 5 min.

• The oven door must be kept closed during the cooking cycle.

• When cooking meat, pour a little water into the drip tray (on the bottom level) to

reduce smoke and fat spatters.

• Ideally the meat should be turned during cooking.

TURBO GRILL

• To grill large joints of meat (roast beef and other roast meats).

• The oven door must be kept closed during the cooking cycle.

• When cooking meat, to avoid spatters of fat and smoke, pour a little water into

the drip tray.

• Turn the meat during grilling.

DEFROSTING

• Ideal for thawing frozen food at room temperature.

• The food should be placed in the oven in its wrapping to prevent it from drying

out.

TURBOFAN

• To cook on one level (e.g.: fruit, cakes, timbales, vegetables, pizza, poultry).

FAN/THERMOVENTILATED

• To cook (without preheating) foods that require the same cooking temperature

on one or more levels (e.g.: fish, vegetables, sweets), without transferring

odours from one foodstuff to the other

BOTTOM HEATING ELEMENT

• To finish cooking fruit or cheese cakes or to thicken sauce.

• Use this function for the last 10/15 minutes of cooking.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Komfur
Model:	AKP 290 IX
Justerbar termostat:	Ja
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	564 mm
Højde:	595 mm
Vægt:	34000 g
Produktfarve:	Rustfrit stål
Strøm:	3200 W
Pakkevægt:	36400 g
Indvendig belysning:	Ja
Grill:	2500 W
Selvrensende:	Ja
Timer type:	Mekanisk
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	51 L
Ovn termostatinterval:	0 - 250 °C
Autosluk timer tilbereder mad sikkert:	Ja
Energiforbrug:	1.1 kWh
Automatiske programmer, antal:	8
Dimensioner på installationsrummet (BxDxH):	560 x 550 x 600 mm
