Whirlpool ART 9910/A+ SF Manual

Whirlpool Køleskab ART 9910/A+ SF

Læs gratis den danske manual til Whirlpool ART 9910/A+ SF (4 sider) i kategorien Køleskab. Denne vejledning er vurderet som hjælpsom af 21 personer og har en gennemsnitlig bedømmelse på 4.1 stjerner ud af 11 anmeldelser. Har du et spørgsmål om Whirlpool ART 9910/A+ SF, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance. Position the antibacterial anti-odour lter in the fan as

demonstrated in the lter packaging (if available). If the audible signal

sounds, it means that the temperature alarm has intervened: press the

button to switch o the acoustic alarms.

CONTROL PANEL

1. 2.

1. On/stand-by

2. Refrigerator temperature - Fast cool

6TH SENSE FRESH CONTROL

The appliance is automatically able to quickly reach the optimal

internal preservation temperature. The function enables to control also

the humidity of the appliance. In order for it to function correctly, the

fan must also be turned on. It is possible to turn the function on/o

(see Fan description).

FAN*

The Fan improves temperature distribution inside the product,

allowing better preservation of stored food and reduction of excess

humidity. The fan is switched on by default and can be activate/

deactivate manually. The fan operating mode is adjusted based on

product condition. You can turn the fan on/o by pressing the

and “On/Stand-by” buttons at the same time for 3 seconds. The

lit 6thSense FreshControl symbol indicates that the fan is on and

therefore the 6thSense FreshControl function is on. If the ambient

temperature exceeds 27°C, or if drops of water are present on the

glass shelves, it is essential that the fan is on to ensure the proper

preservation of the food. Deactivation of the fan allows energy

consumption to be optimised.

Note: the fan restarts automatically after a power cut or after turning o

the appliance. Do not obstruct the air intake area with food items.

ANTIBACTERIAL FILTER*

Remove it from the box placed in the Fruit and vegetable drawer and

insert into the cover of fan. The replacement procedure is included in

the lter box.

ON/STAND-BY

Press the button for 3 seconds to turn the appliance o. In

Stand-by mode the light in the refrigerator compartment does not turn

on. Press the button again briey to reactivate the appliance.

Note: this does not disconnect the appliance from the power supply.

REFRIGERATOR COMPARTMENT TEMPERATURE

It is possible to set a dierent temperature with the button.

There are ve possible controls.

• From a less cold temperature (left)

• to a colder temperature (right).

FAST COOL

Press the button for 3 seconds to quickly cool the

refrigerator compartment or 6 hours before putting large quantities of

food to be frozen in the freezing zone. When the function is turned on

the icon lights up.

The function automatically turns o after 30 hours, or manually by

pressing the button again for 3 seconds.

Note: avoid a direct contact between the fresh food and the food that is

already frozen To optimise the freezing speed, drawers can be removed

and the food can be placed directly on the bottom of the compartment.

* Available only on certain models

“0° ZONE” COMPARTMENT*

The “ ” compartment is specically designed to maintain a low 0°ZONE

temperature and the correct humidity to preserve fresh food for longer

(for example, meat, sh, fruits and winter vegetables).

Humidity control technology coupled with Active0 provides the best

food preservation when the food is not completely packed.

TURNING ON AND TURNING OFF THE COMPARTMENT

The internal temperature of the compartment is approximately 0°

when the compartment is turned on.

To turn on the compartment, press the button (1) for more than one

second until the symbol (2) lights up. The lit symbol (2) means that the

compartment is working. Press the button (1) again for more than one

second to turn o the compartment. The temperature inside depends

on the general temperature of the refrigerator.

For the correct functioning of the “ ” compartment, it is 0°ZONE

necessary that:

• the appliance is turned on;

• the fridge temperature is between +2°C and +6°C;

• the “0°ZONE” compartment is turned on

• Vacation Mode and Stand by are not selected

Note:

-if the symbol does not light up when you turn on the compartment,

check that the drawer is properly inserted; if the problem persists

contact the authorised Technical Assistance Service;

-when the “0°ZONE” compartment is inserted in the appliance you

may hear a faint noise, which you should consider as normal;

Important: be careful when positioning food and containers that are

small in size on the upper shelf of the “ “ compartment in order 0°ZONE

to prevent them accidentally falling between the shelf and the back

wall of the refrigerator compartment.

REMOVING THE “0° ZONE“ COMPARTMENT

Carry out the following steps:

1. To make it easier to remove the compartment, we recommend

that you empty (and possibly remove) the lower door shelves.

2. Remove the compartment by rotating it upwards.

3. Remove the white plastic shelf under the compartment.

Note: it is not possible to remove the upper shelf and side supports.

To use the “0° ZONE“ compartment again, carefully reposition the

white plastic shelf under the compartment before inserting the drawer

and turning the function back on.

To have a larger refrigerator volume and to reduce energy

consumption, it is recommended to remove the “ “ 0°ZONE

compartment.

Clean the compartment and its components occasionally using a cloth

and a solution of warm water (taking care not to submerge the white

plastic shelf under the drawer) and neutral cleaning agents specically

for cleaning the inside of the refrigerator. Do not use abrasive cleaning

agents.

Before cleaning the compartment (also externally) it is necessary

to remove the drawer to disconnect the electrical supply.

STOP FROST SYSTEM*

The STOP FROST SYSTEM facilitates the defrost procedure for the

freezer compartment.

The STOP FROST accessory is designed to collect some of the frost

that forms in the freezer compartment and it is easy to remove and

clean, therefore reducing the time needed to defrost the freezer

compartment.

To remove the frost on the STOP FROST accessory follow the cleaning

procedure demonstrated below.

PROCEDURE TO CLEAN THE STOP FROST ACCESSORY

1. Open the freezer compartment door and remove the upper

drawer.

2. Unfasten the STOP FROST accessory and remove it, taking care not

to drop it on the glass shelf below.

Note: if the accessory is jammed or dicult to remove, do not keep

trying to remove it, but proceed with the complete defrost of the freezer

compartment.

3. Close the door of the freezer compartment.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	ART 9910/A+ SF
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	540 mm
Dybde:	545 mm
Højde:	1935 mm
Vægt:	55200 g
Produktfarve:	Rustfrit stål
Kontroltype:	Berøring
Lampe type:	LED
Indbygget skærm:	Ja
Strøm:	16 A
Ledningslængde:	1.4 m
Pakkevægt:	57000 g
Pakkedybde:	608 mm
Pakkebredde:	580 mm
Pakkehøjde:	2000 mm
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	310 kWh
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Installationsrum bredde:	560 mm
Installationsrum dybde:	560 mm
Installationsrum højde:	1940 mm
Tilsluttet belastning:	140 W
Støjniveau:	35 dB
Vendbare døre:	Ja
Fryser, netto rumindhold:	79 L
Frysekapacitet:	3.5 kg/24t
Opbevaringstid under strømafbrydelse:	19 t
Klimaklasse:	SN-T
Brugerdefineret panel klar:	Ingen
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Køleskabsdøre:	4
Køleskab, netto rumindhold:	222 L
Total netto kapacitet:	301 L
Understøtter VPN:	307 L
No Frost (køleskab):	Ja
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Hylder, materiale:	Hærdet glas
Køleskab, brutto rumindhold:	228 L
Flaskeholder:	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Super Cool funktion:	Ja
Frisk zone, aflukke:	Ja
Automatisk afrimning (køleskab):	Ja
Minimal driftstemperatur:	10 °C
Maksimal driftstemperatur:	43 °C
Antal aftagelige hylder:	3
Antal kompressorer:	1
Kølesystem:	Ventileret
