GB AWE 8727 PROGRAMME CHART
5019 312 10588
Whirlpool is a registered trademark of Whirlpool USA
❉
: optional / Yes : dosing required
1)
For improved garment care, spin speed is restricted in these programmes.
2)
Do not use liquid detergent when activating the “Start Delay”.
3)
Do not use liquid detergent for the main wash when activating the “Prewash” option.
The wool and handwash cycles of this machine have been tested and approved by The Woolmark Company
for the washing of Woolmark garments labelled as “machine wash” or “hand wash” provided that the garments
are washed according to the instructions on the garment label and those issued in this programme chart.
M0703
Programme
Te mp e -
rature
Care
Labels
Max
Load
kg
Type of wash/Notes
- For temperature selection, respect the manufacturer’s
recommendations on the care label
Detergents and additives Special options
Max
Spin
Speed
rpm
Pre-
wash
Main
wash
Softener Eco
Eco
Easy
ironing
Anti-
froissage
Pre-
wash
Pré-
lavage
Start
delay
Départ
différé
Intensive
rinse
Rinçage
plus
Rinse
hold
Arrêt
cuve
pleine
Variable
spin
Essorage
White Cotton /
Antibacterial
Coton
70 - 95 °C
5.5
Normally to heavily soiled bed linen, table linen and underwear, towels,
shirts etc. made of cotton and linen.
At a temperature of 80°C or more, this programme eliminates bacteria,
ensuring sanitization of your laundry. The bacteria removal efficiency has
been tested following a similar methodology to the NF EN 13697
standard of Nov. 2001.
❉
Yes
3)
❉❉❉❉
❉
2)
❉❉❉
1200
Cotton Coton
20 - 60 °C
5.5
Synthetics Synthétique
20 - 60 °C
2.5
Normally soiled blouses, shirts, overalls etc. made of polyester (Diolen,
Trevira), polyamide (Perlon, Nylon) or blends with cotton.
❉
Yes
3)
❉❉❉❉
❉
2)
❉❉❉
1000
1)
Daily load
20 - 60 °C
3.0
Slightly to normally soiled textiles made of cotton and/or synthetics.
—
Yes
❉
—
❉
—
❉
2)
❉❉❉
1200
Quick wash
Chrono
20 - 30 °C
3.0
Shortly worn outer clothing made of cotton, polyester, polyamide and
blends with cotton.
—
Yes
❉
———
❉
2)
❉❉❉
1200
Delicates Délicat
20 - 40 °C
1.5
Curtains and delicate clothing, dresses skirts, shirts and blouses.
❉
Yes
3)
❉
——
❉
❉
2)
—
❉❉
1000
1)
Baby Baby
20 - 60 °C
5.5
Normally soiled baby clothes, baby quilts, beddings and blankets as well
as washable toys made of cotton and/or linen.
In this programme, the washing liquid is rinsed out particularly thoroughly
and thus helps to protect sensitive baby skin.
❉
Yes
3)
❉
——
❉
❉
2)
—
❉❉
1200
Lingerie Lingerie
20 - 30 °C
1.0
This cycle is particularly suitable to treat delicate lingerie (use of a
laundry net strongly recommended).
—
Yes
❉
———
❉
2)
—
❉❉
400
1)
Wool Laine
20 - 40 °C
1.0
Only woollens, labelled with the Woolmark and identified as machine
washable.
This programme (40°C) is tested and approved by The Woolmark
Company for machine washable wool.
—
Yes
❉
———
❉
2)
—
❉❉
1000
1)
Handwash Lavage main
20 - 40 °C
1.0
Textiles made of silk, linen, wool and viscose marked as “handwashable”.
This programme (40°C) is tested and approved by The Woolmark
Company for handwashable wool.
—
Yes
❉
———
❉
2)
—
❉❉
400
1)
Rinse & Spin Rinçage & Essorage
——
5.5
Same as the last rinse and the final spin in the “Cotton” programme.
——
❉
———
❉❉❉❉
1200
Spin Essorage
——
5.5
In this programme spinning is intensive. Same as the spin cycle in the
“Cotton” programme.
—— ————
❉
——
❉
1200
Gentle Spin Essorage doux
——
1.0
In this programme spinning is gentle. Same as the spin cycle in the “Wool”
programme.
—— ————
❉
——
❉
1000
1)
Drain Vidange
——
—
Drain only - no spinning. Alternative method of terminating programme after
“Rinse Hold”.
—— ————— — — — —
A. Programme selector
B. “Temperature” button
C. Temperature display
D. “Variable spin” button
E. “Start delay” button
F. Time display
G. “Start/Pause” button
H. Programme sequence indicator
I. “Door open” indication
J. “Reset” button
This washing machine is equipped with
automatic safety functions which detect and
diagnose faults at an early stage and react
appropriately, e.g.:
K. “Service” indication
L. “Water tap closed” indication
M. “Clean filter” indication
H
C
A
F
B DEG
{
M
L
K
I
J
5019 312 10588
Whirlpool is a registered trademark of Whirlpool USA
Add detergent as indicated on the front page and as
described in the chapter “Detergent and Additives”
in your Instructions for Use.
1. Turn the
programme selector
to the desired
programme. The display shows the programme
duration in hours and minutes as well as the
predefined temperature. The
“Start/Pause”
button flashes.
2. The
temperature
can be altered by pressing
the “Temperature” button.
3. The indication lamp of the predefined
spin speed
lights up; in case you want to set another spin
speed, press the “Variable spin” button.
Push the button(s) of any option(s) desired - the
respective indication lights up.
When the combination of programme and additional
option(s) is not possible, the indication lights switch off
automatically. Unsuitable combinations of options are
deselected automatically.
“Eco” button
• With a modified temperature profile and a slightly
prolonged washing duration, the optimum
combination of excellent washing result and even
lower energy consumption is achieved.
“Easy ironing” button
• Can be used together with “Cotton”,
“Synthetics” and “Daily load” programmes to
make ironing easier.
• Increases the water quantity and the clothes are
spun very gently.
“Prewash” button
• Only for heavily soiled loads (for example sand,
granular dirt) sensible. Increases the cycle time
by approximately 15 min.
• Do not use liquid detergent for the main wash
when activating the Prewash option.
“Intensive rinse” button
• More water is added and rinse cycle is prolonged.
• This option is particularly suitable for areas with
very soft water, for washing baby linen and
helping people with allergies.
“Rinse hold” button
• The laundry remains in the last rinse water
without progressing to the final spin cycle to avoid
creasing and prevent colours from changing.
• This option is particularly recommended for the
programmes “Synthetics”, “Daily load” and
“Delicates”.
• It is particularly useful if you want to postpone
spinning to a later time, or if you want to drain only.
• If you select “Rinse hold”, do not leave the laundry
to soak for too long.
Note:
The programme stops to “Rinse hold” at
the time the “Rinse hold” light in the programme
sequence indicator is on. The indication lamp
next to the
“Start/Pause”
button flashes.
Terminate the “Rinse hold” option:
• Press the
“Start/Pause”
button; the
programme will terminate automatically with the
final spin cycle for the present wash programme.
CONSUMPTION DATA
Programme
Temperature
(°C)
Load
(kg)
Water
(l)
Energy
(kWh)
Approx. Programme Duration
(hours : minutes)
*
White Cotton / Antibacterial 95 5.5 55
**
1.70 1:55
Cotton 60 5.5 49 1.02 2:25
Cotton with “Eco”
***
60 5.5 49 0.93 2:35
Cotton 40 5.5 53 0.55 2:00
Synthetics 60 2.5 53
**
0.85 1:30
Synthetics 40 2.5 47 0.50 1:15
Daily load 40 3.0 43 0.48 1:00
Quick wash 30 3.0 36 0.30 0:30
Delicates 40 1.5 51 0.50 0:45
Baby 40 5.5 73 0.55 2:15
Handwash 40 1.0 43 0.50 0:35
Wool 40 1.0 53 0.50 0:45
Lingerie 30 1.0 42 0.30 0:35
Consumption values were measured in normalized conditions in compliance with Standard IEC/EN 60 456. Consumption data in the home
may vary with respect to the values in the table in relation to the water supply pressure and temperature, the load and the type of wash.
*
The time indicated on the display can deviate from the values in the table, because it takes into account the household
conditions applicable at that time.
**
To reduce the water temperature, some cold water is added at the end of the main wash cycle, before the pump drains the water out.
***
Reference Programme for Energy Label.
ADD DETERGENTS, CLOSE THE LID AND
SELECT THE PROGRAMME
SELECT ANY DESIRED OPTION
• If you do not wish to spin the clothes, turn the
programme selector knob to the “Drain” programme
and press the
“Start/Pause”
button.
“Variable spin” button
• Every programme has a predefined spin speed.
• Press the button to set another spin speed.
• If spin speed “0” is selected, the final spinning is
cancelled but intermediate spin peaks remain
during rinse. The water is drained out only.
The “Start Delay” allows to run the machine at the
consumer’s convenience, for example at night when
electricity is cheaper. Do not use liquid detergent
when activating the “Start Delay”.
• Select programme, temperature and options.
• Press the “Start Delay” button to select the delay
time by 1 to 23 hours;
• Press the
“Start/Pause”
button.
The indication light over the “Start Delay”
button flashes and the countdown of the delay
time begins. The dot between hours and
minutes of the delay time indicated flashes.
• The time delay indication disappears when the
programme starts and it is replaced by the
remaining programme time.
• Once having pressed the
“Start/Pause”
button,
the number of hours preselected can be reduced
by pressing and holding the “Start Delay”
button. From 1 hour on, the delay time can also
be reduced in steps of 10 minutes.
To cancel the “Start Delay”
..before you press the “Start/Pause” button:
• Turn the programme selector to another
position or press the
“Reset”
button.
..after having pressed the “Start/Pause” button:
•Press the
“Reset”
button for at least 3 seconds - the
start delay time disappears from the time display.
Open the tap and press the
“Start/Pause”
button. The
indication lamp next to the
“Start/Pause”
button lights
up. The programme sequence indicator shows the
current programme phase, running from left to right
through Wash, Rinse, Spin/Drain.
The display shows the remaining programme time.
Due to variations in load and temperature of inlet
water, the remaining time is newly calculated in certain
programme phases. If this is the case,
an animation
appears on the time display
.
Before starting and after end of a programme, the
lamp lights to show that the lid can be opened. As
long as a wash programme is running, the lid
remains locked and must on no account be forced
open. In case you have an urgent need to open it
during a running programme, refer to “Cancel
(Reset) a running programme before the end”.
“Service”
Lighting up of the “Service” indication can be caused by
a fault in an electrical component. Refer to the
“Troubleshooting Guide” in your Instructions for Use; if
the fault persists, contact our After Sales Service.
“Water tap closed”
The appliance has no or insufficient water supply.
Open the water tap; if the indication still lights up,
refer to the “Troubleshooting Guide” in the
Instructions for Use.
“Clean filter”
Waste water is not pumped out. Check whether the
drain hose is kinked or the filter must be cleaned; in
the latter case refer to the Instructions for Use
(“Removing the Filter”).
• All the lights of the programme sequence
indicator are off, and the “Door open”
indication lights up.
1. Turn the programme selector to the “Off/O” position.
2. Close the water tap.
3. Open lid and drum and unload the machine.
4. Leave the lid open to allow the inside of the
machine to dry.
1. Press the
“Start/Pause”
button to pause the
programme. The light flashes.
2. Select the new programme, temperature, any
options and another spin speed if you want.
3. Press the
“Start/Pause”
button again. The new
programme continues at the same position
where the previous programme was interrupted.
Do not add detergent for this programme.
The
“Reset”
button cancels a programme before
the end.
•Press the
“Reset”
button for at least 3
seconds. Any existing water is drained out
before the lid can be opened.
START DELAY
PROGRAMME START
“DOOR OPEN” INDICATION
RED INDICATIONS
PROGRAMME END
CHANGE PROGRAMME AND/OR OPTIONS
AFTER PROGRAMME START
CANCEL (RESET) A RUNNING
PROGRAMME BEFORE THE END

Produkt Specifikationer

Mærke: Whirlpool
Kategori: Vaskemaskiner
Model: AWE 8727

Har du brug for hjælp?

Hvis du har brug for hjælp til Whirlpool AWE 8727 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Vaskemaskiner Whirlpool Manualer

Whirlpool

Whirlpool WAC 7200 Manual

13 Januar 2025
Whirlpool

Whirlpool WWDC 9614 Manual

12 Januar 2025
Whirlpool

Whirlpool W8 W846WR SPT Manual

12 Januar 2025
Whirlpool

Whirlpool AWT 4103 Manual

12 Januar 2025
Whirlpool

Whirlpool W7X W845WR SPT Manual

12 Januar 2025
Whirlpool

Whirlpool FFD 9448 SBSV EU Manual

12 Januar 2025
Whirlpool

Whirlpool FFB 8258 WV EE Manual

12 Januar 2025
Whirlpool

Whirlpool VAW558P Manual

15 Oktober 2024
Whirlpool

Whirlpool AWM 5063 Manual

14 Oktober 2024
Whirlpool

Whirlpool AWM 1203 Manual

13 Oktober 2024

Vaskemaskiner Manualer

Nyeste Vaskemaskiner Manualer

Bosch

Bosch WAQ28440EX Manual

15 Januar 2025
Siemens

Siemens WM14Q472DN Manual

15 Januar 2025
BEKO

BEKO WTV8740A1 Manual

15 Januar 2025
Hoover

Hoover DST 10166PG-80X Manual

15 Januar 2025
Asko

Asko 15605 Manual

15 Januar 2025
Hisense

Hisense WFPV9014EM Manual

15 Januar 2025
BEKO

BEKO WRE 6532 ZSBS Manual

14 Januar 2025
Miele

Miele V 9545 WPS Meteor Manual

14 Januar 2025
Zanussi

Zanussi ZWF 91483 WR LINDO 300 Manual

14 Januar 2025
Corbero

Corbero E-CLA5018W Manual

14 Januar 2025
