SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED

Download the complete instruction manual http://

docs.whirlpool.eu or call the phone number

shown on the warranty booklet

Before using the appliance, read these safety

instructions. Keep them nearby for future

reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all

times. The manufacturer declines any liability for

failure to observe these safety instructions, for

inappropriate use of the appliance or incorrect

setting of controls.

These instructions are valid if the country

symbol appears on the appliance. If the symbol

doesn't appear on the appliance, it is necessary to

refer to the technical instructions which will

provide the necessary instructions concerning

modication of the appliance to the conditions of

use of the country.

CAUTION : The use of the gas cooking appliance

results in the production of heat, moisture and

products of combustion in the room in which it is

installed. Ensure that the kitchen is well ventilated

especially when the appliance is in use: keep

natural ventilation holes open or install a

mechanical ventilation device (mechanical

extractor hood). Prolonged intensive use of the

appliance may call for additional ventilation, for

example opening of the window, or more eective

ventilation,increasing the level of mechanical

ventilation where present.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to

avoid touching heating elements. Children less

than 8 years of age must be kept away unless

continuously supervised.

WARNING : If the hob surface is cracked, don’t

use the appliance – risk of electrical shock.

WARNING : Danger of re : Do not store items on

the cooking surfaces.

CAUTION : The cooking process has to be

supervised. A short cooking process has to be

supervised continuously.

WARNING : Unattended cooking on a hob with

fat or oil can be dangerous – risk of re. NEVER try

to extinguish a re with water, but switch o the

appliance and then cover ame e.g. with a lid or a

re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away

from the appliance, until all the components have

cooled down completely – risk of re.

If the information in this manual is not followed

exactly, a re or explosion , may result causing

property damage or injury.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8 years)

should be kept away from the appliance unless

continuously supervised. Children from 8 years old

and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge can use this appliance only if they

are supervised or have been given instructions on

safe use and understand the hazards involved.

Children must not play with the appliance.

Cleaning and user maintenance must not be

carried out by children without supervision.

CAUTION : In case of hotplate glass breakage:-

shut immediately o all burners and any electrical

heating element and isolate the appliance from the

power supply; - do not touch the appliance surface;

-do not use the appliance.

The glass lid can break in if it is heated up. Turn o

all the burners and the electric plates before

closing the lid. Do not shout down lid when burner

alight.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled

system.

This appliance is intended to be used in

household and similar applications such as: sta

kitchen areas in shops, oces and other working

environments; farm houses; by clients in hotels,

motels, bed & breakfast and other residential

environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not

use the appliance outdoors.

Use pots and pans with bottoms the same width

as that of the burners or slightly larger (see specic

table). Make sure pots on the grates do not

protrude beyond the edge of the hob.

Improper use of the grids can result in damage

to the hob: do not position the grids upside down

or slide them across the hob.

Do not let the burner ame extend beyond the edge of the pan.

Do not use : Cast iron griddles, ollar stones, terracotta pots and pans.

Heat diusers such as metal mesh, or any other types. Two burners

simultaneously for one receptacle (e.g. Fish kettle).

Should particular local conditions of the delivered gas make the ignition

of burner dicult, it is advisable to repeat the operation with the knob

turned to small ame setting.

In case of installation of a hood above the cooktop, please refer to the

hood instructions for the correct distance.

The protective rubber feet on the grids represent a chocking hazard for

young children. After removing the grids, please ensure that all the feet

are correctly tted.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

Installation, including water supply (if any) and

electrical connections, and repairs must be carried

out by a qualied technician. Do not repair or

replace any part of the appliance unless specically

stated in the user manual. Keep children away from

the installation site. After unpacking the appliance,

make sure that it has not been damaged during

transport. In the event of problems, contact the

dealer or your nearest After-sales Service. Once

installed, packaging waste (plastic, styrofoam parts

etc.) must be stored out of reach of children - risk of

suocation. The appliance must be disconnected

from the power supply before any installation

operation - risk of electrical shock. During

installation, make sure the appliance does not

damage the power cable - risk of re or electrical

shock. Only activate the appliance when the

installation has been completed.

The electrical and gas connections must comply

with local regulation.

WARNING : Modication of the appliance and its

method of installation are essential in order to use

the appliance safely and correctly in all the

additional countries.

Use pressure regulators suitable for the gas

pressure indicated in the instruction.

The room must be equipped with an air

extraction system that expels any combustion

fumes.

The room must also allow proper air circulation,

as air is needed for combustion to occur normally.

The ow of air must not be less than 2 m3/h per kW

of installed power.

The air circulation system may take air directly

from the outside by means of a pipe with an inner

cross section of at least 100 cm2; the opening must

not be vulnerable to any type of blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms

tted with air circulation tubes as described above.

However, these rooms must not be communal

rooms, bedrooms or rooms that may present a re

hazard.

Liquid petroleum gas sinks to the oor as it is

heavier than air. Therefore, rooms containing LPG

cylinders must also be equipped with vents to

allow gas to escape in the event of a leak. As a

result LPG cylinders, whether partially or

completely full, must not be installed or stored in

rooms or storage areas that are below ground level

(cellars, etc.). It is advisable to keep only the cylinder

being used in the room, positioned so that it is not

subject to heat produced by external sources

(ovens, replaces, stoves, etc. ) which could raise

the temperature of the cylinder above 50°C.

Carry out all cabinet cutting works before tting

the appliance in the furniture and remove all wood

chips and sawdust.

If the appliance is Not installed above an oven, a

separator panel (not included) must be installed in

the compartment under the appliance.

Should you experience diculty in turning the burners knobs, please

contact After Sales Service for replacement of the burner tap if found to

be faulty.

The openings used for the ventilation and dispersion of heat must never

be covered.

GAS CONNECTION

WARNING : Prior to installation, ensure that the

local distribution conditions (nature of gas and gas

pressure) and the adjustment of the appliance are

compatible.

Check that the pressure of the gas supply is

consistent with the values indicated in Table 1

(“Burner and nozzle specications”).

WARNING : The adjustment conditions for this

appliance are stated on the label (or data plate).

WARNING : This appliance is not connected to a

combustion products evacuation device. It shall be

installed and connected in accordance with current

installation regulations. Particular attention shall be

given to the relevant requirements regarding

ventilation.

If the appliances is connected to liquid gas, the

regulation screw must be fastened as tightly as

possible.

IMPORTANT : When gas cylinder is adopted, the

gas cylinder or gas container must be properly

settled (vertical orientation).

WARNING : This operation must be performed

by a qualied technician

Use only exible or rigid metal hose for gas

connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried out

in such a way as not to place any strain of any kind

on the appliance. There is an adjustable L-shaped

pipe tting on the appliance supply ramp and this

is tted with a seal in order to prevent leaks. The

seal must always be replaced after rotating the

pipe tting (the seal is provided with the

appliance). The gas supply pipe tting is a threaded

1/2 gas cylindrical male attachment.

Connecting a exible jointless stainless steel

pipe to a threaded attachment The gas supply pipe

tting is a threaded 1/2 gas cylindrical male

attachment. These pipes must be installed so that

they are never longer than 2000 mm when fully

extended. Once connection has been carried out,

make sure that the exible metal pipe does not

touch any moving parts and is not compressed.

Only use pipes and seals that comply with current

National regulations.

IMPORTANT : If a stainless steel hose is used, it

must be installed so as not touch any mobile part

of the furniture (e.g. drawer). It must pass through

an area where there are no obstructions and where

it is possible to inspect it on all its length.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Komfur
Model:	GMA 6421/IXL
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	590 mm
Dybde:	510 mm
Højde:	47 mm
Vægt:	7500 g
Produktfarve:	Rustfrit stål
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Pakkevægt:	8000 g
Pakkedybde:	595 mm
Pakkebredde:	680 mm
Pakkehøjde:	160 mm
Placering af apparat:	Indbygget
Komfurtype:	Gaskomfur
Overfladetype:	Rustfrit stål
Antal kogeplader / madlavningsområde:	4
Blus/kogeplade zone 1 strøm:	1750 W
Blus/kogeplade zone 2 strøm:	3500 W
Blus/kogeplade zone 1 type:	Regelmæssig
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre front
Blus/kogeplade zone 1 strømkilde:	Gas
Blus/kogeplade zone 2 type:	Stor
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre bagende
Blus/kogeplade zone 2 strømkilde:	Gas
Kontrolposition:	Øverst til højre
Blus/kogeplade zone 3 type:	Regelmæssig
Blus/kogeplade zone 4 type:	Simre
Blus/kogeplade zone 4 strømkilde:	Gas
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Gas
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Højre bagende
Blus/kogeplade zone 4 position:	Højre forside
Antal gasbrændere:	4
Blus/kogeplade zone 4 strøm:	1000 W
Blus/kogeplade zone 3 strøm:	1750 W
Elektronisk tænding:	Ja
Almindelig kogeplade/kogezone, diameter:	75 mm
Simre kogeplade/kogezone, diameter:	50 mm
Simre kogeplade / madlavningsområde:	1000 W
Almindelige kogeplade / madlavningsområde:	1650 W
Stor kogeplade / madlavningsområde:	3500 W
Wokbrænder:	Ja
Tændblussikring:	Ja
Stor kogeplade/kogezone, diameter:	130 mm
Wokbrændeposition:	Venstre front
