These instructions are valid if the country symbol

appears on the appliance. If the symbol doesn’t appear

on the appliance, it is necessary to refer to the technical

instructions which will provide the necessary

instructions concerning modication of the appliance

to the conditions of use of the country.

CAUTION: The use of the gas cooking appliance

results in the production of heat, moisture and

products of combustion in the room in which it is

installed. Ensure that the kitchen is well ventilated

especially when the appliance is in use: keep natural

ventilation holes open or install a mechanical

ventilation device (mechanical extractor hood).

Prolonged intensive use of the appliance may call for

additional ventilation, such as opening a window, or

more eective ventilation, for example increasing the

level of mechanical ventilation (if possible).

Failure to follow the information in this manual

exactly may cause a re or explosion, resulting in

property damage or personal injury.

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate

use of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, don’t use

the appliance – risk of electrical shock.

WARNING: Danger of re: Do not store items on the

cooking surfaces.

CAUTION: The cooking process has to be supervised. A

short cooking process has to be supervised continuously.

WARNING: Unattended cooking on a hob with fat

or oil can be dangerous – risk of re. NEVER try to

extinguish a re with water, but switch o the

appliance and then cover ame e.g. with a lid or a re

blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away from

the appliance, until all the components have cooled

down completely – risk of re.

Very young children (0-3 years) should be kept away

from the appliance. Young children (3-8 years) should

be kept away from the appliance unless continuously

supervised. Children from 8 years old and above and

persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge can

use this appliance only if they are supervised or have

been given instructions on safe use and understand the

hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must not be

carried out by children without supervision.

CAUTION: In case of hotplate glass breakage: shut

immediately o all burners and any electrical heating

element and isolate the appliance from the power

supply; do not touch the appliance surface; do not use

the appliance.

The glass lid can break in if it is heated up. Turn o all

the burners and the electric plates before closing the

lid. Do not shout down lid when burner alight.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Children less than 8 years of

age must be kept away unless continuously supervised.

The food must not be left in or on the product for

more than one hour before or after cooking.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas in

shops, oces and other working environments; farm

houses; by clients in hotels, motels, bed & breakfast

and other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not

use the appliance outdoors.

Use pots and pans with bottoms the same width as

that of the burners or slightly larger (see specic table).

Make sure pots on the grates do not protrude beyond

the edge of the hob.

Improper use of the grids can result in damage to

the hob: do not position the grids upside down or slide

them across the hob.

Do not let the burner ame extend beyond the edge of the pan.

If the hob surface is in glass material, do not use the cast iron griddles, ollar

stones, terracotta pots and pans.

Do not use: heat diusers such as metal mesh, or any other types; two burners

simultaneously for one receptacle (e.g. Fish kettle).

Should particular local conditions of the delivered gas make the ignition of

burner dicult, it is advisable to repeat the operation with the knob turned to

small ame setting.

In case of installation of a hood above the cooktop, please refer to the hood

instructions for the correct distance.

The protective rubber feet on the grids represent a choking hazard for young

children. After removing the grids, please ensure that all the feet are correctly fitted.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

The electrical and gas connections must comply

with local regulation.

Installation, including water supply (if any) and

electrical connections, and repairs must be carried out by

a qualied technician. Do not repair or replace any part of

the appliance unless specically stated in the user manual.

Keep children away from the installation site. After

unpacking the appliance, make sure that it has not been

damaged during transport. In the event of problems,

contact the dealer or your nearest After-sales Service.

Once installed, packaging waste (plastic, styrofoam parts

etc.) must be stored out of reach of children - risk of

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

suocation. The appliance must be disconnected from

the power supply before any installation operation - risk

of electrical shock. During installation, make sure the

appliance does not damage the power cable - risk of re

or electrical shock. Only activate the appliance when the

installation has been completed.

WARNING: Modification of the appliance and its

method of installation are essential in order to use the

appliance safely and correctly in all the additional countries.

Use pressure regulators suitable for the gas pressure

indicated in the instruction.

The room must be equipped with an air extraction

system that expels any combustion fumes.

The room must also allow proper air circulation, as air is

needed for combustion to occur normally. The flow of air

must not be less than 2 m

/h per kW of installed power.

The air circulation system may take air directly from

the outside by means of a pipe with an inner cross

section of at least 100 cm

; the opening must not be

vulnerable to any type of blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms tted

with air circulation tubes as described above. However,

these rooms must not be communal rooms, bedrooms

or rooms that may present a re hazard.

Liquid petroleum gas sinks to the oor as it is heavier

than air. Therefore, rooms containing LPG cylinders

must also be equipped with vents to allow gas to

escape in the event of a leak. As a result LPG cylinders,

whether partially or completely full, must not be

installed or stored in rooms or storage areas that are

below ground level (cellars, etc.). It is advisable to keep

only the cylinder being used in the room, positioned so

that it is not subject to heat produced by external

sources (ovens, replaces, stoves, etc. ) which could

raise the temperature of the cylinder above 50°C.

Should you experience diculty in turning the burners knobs, please contact

After Sales Service for replacement of the burner tap if found to be faulty.

The openings used for the ventilation and dispersion of heat must never be covered.

Carry out all cabinet cutting works before tting the

appliance in the furniture and remove all wood chips

and sawdust.

If the appliance is not installed above an oven, a

separator panel (not included) must be installed in the

compartment under the appliance.

GAS CONNECTION

WARNING: Prior to installation, ensure that the local

distribution conditions (type of gas and gas pressure)

and the adjustment of the appliance are compatible.

Check that the pressure of the gas supply is

consistent with the values indicated in “Burner and

nozzle specications” table.

WARNING: The conguration conditions for this

appliance are stated on the label (or data plate).

WARNING: This appliance is not connected to a

combustion products evacuation device. It must be

installed and connected in accordance with current

installation regulations. Particular attention must be

paid to the relevant requirements regarding ventilation.

If the appliances is connected to liquid gas, the

regulation screw must be fasted as tightly as possible.

IMPORTANT: When the gas cylinder or gas container is

installed, it must be properly settled (vertical orientation).

WARNING: This operation must be performed by a

qualied technician.

Use only exible or rigid metal hose for gas

connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried out in

such a way as not to place any strain of any kind on the

appliance. There is an adjustable L-shaped pipe tting

on the appliance supply ramp and this is tted with a

seal in order to prevent leaks. The seal must always be

replaced after rotating the pipe tting (the seal is

provided with the appliance). The gas supply pipe

tting is a threaded 1/2 gas cylindrical male attachment.

Connecting a exible jointless stainless steel pipe to

a threaded attachment. The gas supply pipe tting is a

threaded 1/2 gas cylindrical male attachment. These

pipes must be installed so that they are never longer

than 2000 mm when fully extended. Once connection

has been carried out, make sure that the exible metal

pipe does not touch any moving parts and is not

compressed. Only use pipes and seals that comply

with current National regulations.

IMPORTANT: If a stainless steel hose is used, it must

be installed so as not touch any mobile part of the

furniture (e.g. drawer). It must pass through an area

where there are no obstructions and where it is

possible to inspect it on all its length.

The appliance should be connected to the main

gas supply or to gas cylinder in compliance with the

current national regulations. Before making the

connection, make sure that the appliance is compatible

with the gas supply you wish to use. If this is not the

case, follow the instructions indicated in the paragraph

“Adapting to dierent types of gas”.

After connection to the gas supply, check for leaks

with soapy water. Light up the burners and turn the

knobs from maximum position 1* to minimum

position 2* to check ame stability.

ADAPTING TO DIFFERENT TYPES OF GAS

(This operation needs to be carried out by a qualied

technician).

In order to adapt the appliance to a type of gas

other than the type for which it was manufactured

(indicated on the rating label), follow the dedicated

steps provided after installation drawings.

ELECTRICAL WARNINGS

IMPORTANT: Information about current and voltage

consumption is provided on the rating plate.

It must be possible to disconnect the appliance

from the power supply by unplugging it if plug is

accessible, or by a multi-pole switch installed upstream

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Komfur
Model:	GOFL 629/S
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50-60 Hz
Bredde:	590 mm
Dybde:	510 mm
Højde:	49 mm
Vægt:	12500 g
Produktfarve:	Sølv
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Strøm:	0.6 A
Ledningslængde:	0.85 m
Timer:	Ingen
Placering af apparat:	Indbygget
Installationsrum dybde:	490 mm
Installationsrum højde:	560 mm
Komfurtype:	Gaskomfur
Overfladetype:	Glas
Antal kogeplader / madlavningsområde:	4
Kontrolposition:	Front
Tilsluttet belastning (elektrisk):	0 W
Ovnbredde størrelse:	59 cm
Restvarmeindikator:	Ingen
Indbygget hætte:	Ingen
Tilsluttet belastning (gas):	7800 W
Antal gasbrændere:	4
Elektronisk tænding:	Ja
Komfurlåg:	Ingen
Strømstik:	Ingen
Elektronisk antændelsestype:	Tændingsknap
