Side 1/80

Quick guide

SLIDING SHELVES AND SHELF GUIDES

Before using the oven remove the protective tape [a] and then

remove the protective foil [b] from the sliding runners.

REMOVING THE SLIDING RUNNERS [c]

Pull the lower part of the sliding runner to uncouple the lower

hooks (1) and pull the the sliding runners upwards, removing

them from the upper hooks (2).

REFITTING THE SLIDING RUNNERS [d]

Hook the upper hooks on the shelf guides (1) then press the

lower part of the sliding runners against the shelf guides, until

the lower hooks are clicking (2).

[c] [d]

REMOVING AND REFITTING THE SHELF GUIDES

1. To remove the shelf guides, rmly grip the external part of

the guide, and pull it towards you to extract the support and

the two internal pins from the lodging.

2. To reposition the shelf guides, position them near the cavity

and initially insert the two pins into their lodgings. Next,

position the external part near its lodging, insert the support,

and rmly press towards the wall of the cavity to make sure

the shelf guide is properly secured.

FIRST TIME USE

1. SETTING THE TIME

You will need to set the time when you switch on the

appliance for the rst time: Press until the icon and the

two digits for the hour start ashing on the display.

Use

or to set the hour and press to conrm. The

two digits for the minutes will start ashing. Use or to

set the minutes and press to conrm.

Please note: When the icon is ashing, for example following

lengthy power outages, you will need to reset the time.

2. SET THE POWER CONSUMPTION

By default the oven is programmed to work at a power

higher than 3 kW (Hi): To operate the oven at a power that is

compatible with a domestic power supply less than 2,9 kW

(Lo), you will need to change the settings.

To go to the change menu, turn the selection knob to

then turn it back to .

CONTROL PANEL DESCRIPTION

1 32 4 5

1. SELECTION KNOB

For switching the oven on by selecting

a function. Turn to the position to

switch the oven o.

2. LIGHT

With the oven switched on, press

to turn the oven compartment lamp on

or o.

3. SETTING THE TIME

For accessing the cooking time settings,

delayed start and timer.

For displaying the time when the oven

is o.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time settings.

6. THERMOSTAT KNOB

Turn to select the temperature you require

when activating manual functions.

Please note: The knobs are retractable.

Press the knobs in the middle and they

pop up.

THANK YOU FOR BUYING A WHIRLPOOL

PRODUCT

In order to receive a more complete

assistance, please register your product on

ww w . whirlpool . eu/register

Before using the appliance carefully read the Safety

Instruction.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Ovn
Model:	OAS KP8V1SW IX
Afrimningsfunktion:	Ingen
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Produktfarve:	Black, Stainless steel
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Ledningslængde:	1 m
Placering af apparat:	Indbygget
Urtype:	Elektronisk
Konvektion madlavning:	Ja
Selvrensende:	Ja
Wi-Fi kontrolleret:	Ingen
Rengøringstype:	Pyrolyse
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	71 L
Strøm for samtlige ovne:	3300 W
Antal ovne:	1
Ovn nettokapacitet:	71 L
Energiforbrug (konventionel):	0.89 kWh
Energiforbrug (tvungen konvektion):	0.69 kWh
Dør med blød lukning:	Ja
Mikroovn madlavning:	Ingen
