Side 1/4

Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance. Position the antibacterial anti-odour lter in the fan as

demonstrated in the lter packaging (if available). If the audible signal

sounds, it means that the temperture alarm has intervened: press the

button to switch o the acoustic alarms.

CONTROL PANEL

4.6.8. 7.

3.1. 1. Freezer and refrigerator compartment

temperature indicator

2. Fast cool

3. 6th Sense Fresh Control and Fan indicator

4. On/stand-by

5. Alarm indicator

6. Turning o the sound alarm

7. Black out alarm indicator

8. Temperature button

6TH SENSE FRESH CONTROL

The appliance is automatically able to quickly reach the optimal

internal preservation temperature. The 6th Sense Fresh Control function

enables to control also the humidity of the appliance. In order for it to

function correctly, the fan must also be turned on. It is possible to turn

the function on/o (see Fan description).

FAN*

The Fan improves temperature distribution inside the product,

allowing better preservation of stored food and reduction of excess

humidity. By default, the fan is switched on. You can turn the fan on/

o by pressing for 3 seconds Stand by and Fast Cooling

buttons. The lit 6th Sense Fresh Control symbol indicates that the fan

is on and therefore the 6th Sense Fresh Control function is on. If the

ambient temperature exceeds 27°C, or if drops of water are present

on the glass shelves, it is essential that the fan is on to ensure the

proper preservation of the food. Deactivation of the fan allows energy

consumption to be optimised.

Note: the fan restarts automatically after a power cut or after turning o

the appliance. Do not obstruct the air intake area with food items.

ANTIBACTERIAL FILTER*

Remove it from the box placed in the Fruit and vegetable drawer and

insert into the cover of fan. The replacement procedure is included in

the lter box.

ON/STAND-BY

Press the button for 3 seconds to turn the appliance o (the

control panel and the light will remain turned o). Press the button

again briey to reactivate the appliance.

Note: This does not disconnect the appliance from the power supply.

FREEZER AND REFRIGERATOR

COMPARTMENT TEMPERATURE

It is possible to set a dierent temperature of the appliance by pressing

the "Temp." button.

LEDs lit Set temperature

Low High

High (less cold)

Medium-high

Medium

Medium-low

Low (colder)

FAST COOL

Press the button for 3 seconds to quickly cool the

refrigerator compartment or 6 hours before putting large quantities

of food to freeze in the freezer compartment. When the function is

turned on the icon lights up. The function turns o automatically after

36 hours, or manually by pressing the button again for 3 seconds.

Note: Avoid a direct contact between the fresh food and the food that is

already frozen.

TURNING OFF THE SOUND ALARM

To turn o the sound alarm, briey press the button.

* Available only on certain models

STOP FROST SYSTEM*

The STOP FROST SYSTEM facilitates the defrost procedure for the

freezer compartment.

The STOP FROST accessory is designed to collect some of the frost

that forms in the freezer compartment and it is easy to remove and

clean, therefore reducing the time needed to defrost the freezer

compartment.

To remove the frost on the STOP FROST accessory follow the cleaning

procedure demonstrated below.

PROCEDURE TO CLEAN THE STOP FROST ACCESSORY

1. Open the freezer compartment door and remove the upper

drawer.

2. Unfasten the STOP FROST accessory and remove it, taking care not

to drop it on the glass shelf below.

Note: if the accessory is jammed or dicult to remove, do not keep

trying to remove it, but proceed with the complete defrost of the

freezer compartment.

3. Close the door of the freezer compartment.

4. Remove the frost on the accessory by rinsing it under running (not

hot) water.

5. Let the accessory drip dry and dry the plastic parts with a soft

cloth.

6. Reinsert the accessory by placing the back part on the projections

shown in gure, then refasten the handle of the accessory to the

clasps above.

7. Reinsert the upper drawer and close the door of the freezer

compartment.

It is possible to clean the STOP FROST accessory on its own without

completely defrosting the freezer compartment.

Cleaning the STOP FROST accessory regularly helps to reduce the need

to completely defrost the freezer compartment.

Note: the product specications, including volume and energy, are

calculated without the STOP FROST accessory.

HOW TO STORE FOOD AND BEVERAGE

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drink, eggs,

sauces, pickles, butter, jam

COOL ZONE

Suggested for storage of chese, milk, daily food,

delicatessen, yogurt

COOLEST AREA

Suggested for storage of cold cuts, desserts, meat and

sh

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh/cooked food

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	SP40 800 EU
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	690 mm
Dybde:	545 mm
Højde:	1935 mm
Vægt:	74000 g
Produktfarve:	Hvid
Kontroltype:	Berøring
Lampe type:	LED
Strøm:	16 A
Ledningslængde:	2.45 m
Pakkevægt:	76000 g
Pakkedybde:	606 mm
Pakkebredde:	732 mm
Pakkehøjde:	2014 mm
Energieffektivitetsklasse (gammel):	A+
Årligt energiforbrug:	328 kWh
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Installationsrum bredde:	710 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	140 W
Støjniveau:	35 dB
Justerbare fødder:	Ingen
Vendbare døre:	Ja
Fryser, netto rumindhold:	101 L
Fryser, brutto rumindhold:	101 L
Frysekapacitet:	4.5 kg/24t
Opbevaringstid under strømafbrydelse:	26 t
Klimaklasse:	SN-T
Brugerdefineret panel klar:	Ingen
Køleskab antal hylder/kurve:	5
Antal grøntsagsskuffer:	1
Køleskabsdøre:	4
Køleskab, netto rumindhold:	299 L
Total netto kapacitet:	400 L
Understøtter VPN:	401 L
No Frost (køleskab):	Ingen
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ingen
Kølemedium:	R600a
Hylder, materiale:	Hærdet glas
Ismaskine:	Ingen
Køleskab, brutto rumindhold:	300 L
Flaskeholder:	Ingen
No Frost (fryser):	Ingen
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Super Cool funktion:	Ja
Isterning bakke:	Ja
Frisk zone, aflukke:	Ja
Automatisk afrimning (køleskab):	Ja
Temperaturalarm:	Ja
Antal aftagelige hylder:	4
Antal kompressorer:	1
