Side 1/12
ENQuick Guide
1
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
CONTROL PANEL
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
Program Programs description
Drying
phase
Natu-
ralDry
Available
options
*)
Duration
ofwash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1.
Eco 50°- Program is suitable to clean normally soiled tableware,
that for this use, it is the most ecient programme in terms of its
combined energy and water consumption, and that it is used to
assess compliance with the EU Ecodesign legislation.
3:10 9.5 0.85
2.
6
th
Sense® 50°- 60°- For normally soiled dishes with dried food
residues. Senses the level of soiling on the dishes and adjusts the
program accordingly.
1:25 - 3:00 7.0 - 14.0 0.90 - 1.40
3.
Intensive 65° - Program recommended for heavily soiled crockery,
especially suitable for pans and saucepans.
2:50 14.0 1.50
4.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that
ensures optimal cleaning and drying performance in shorter time.
1:25 11.5 1.10
5.
Crystals 45° - Program for delicate items, which are more sensitive
to high temperatures, for example glasses and cups.
1:40 11.5 1.20
6.
Rapid 30’ 50° - Program to be used for half load of lightly-soiled
dishes with no dried food residues. Without drying.
- -
0:30 9.0 0.50
7.
Silent 50° - Suitable for night-time operation of the appliance.
With the lowest noise.
3:30 15.0 1.15
8.
Pre-Wash - Use to refresh crockery planned to be washed later.
No detergent to be used with this program.
- -
0:12 4.5 0.01
PROGRAMS TABLE
Before using the appliance carefully read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
3
1
2
8
13
1454 6 7 9 10 11 12
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
10. Rinse Aid rell indica-
tor light
11. Salt rell indicator
light
12. Power Clean® button
with indicator light /
Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the rst time you do this: ll the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water
softener beyond repair).
Whenever you need to add salt, it is mandatory to complete the proce-
dure before the beginning of the washing cycle to avoid corrosion.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse
aid dispenser A should be lled when the
RINSE AID REFILL indicator light in the
control panel is lit. NEVER pour the rinse aid
directly into the appliance tub.
A
C
D
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning e-
ciency. This system regenerates itself with salt, therefore it is required
to rell salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
2
Quick GuideEN
KEYLOCK - A long press (for 3 seconds) of MULTIZONE button, will
activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.
DELAY -The start of the program may be delayed for a period of time
between 0:30 and 24 hours
The DELAY function cannot be set once a wash cycle has been started.
POWER CLEAN - Thanks to the additional power jets this option provides
a more intensive and powerful wash in the lower rack, in the specic
area. This option is recommended for washing pots and casseroles.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
Bydefault the appliance washes dishes in all racks.
Please scan the QR code on your product in order to have more detailed information.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code indicated on the energy label. The label also includes the model
identier that can be used to consult the https://eprel.ec.europa.eu database portal.
IEC 436
:
LOADING THE RACKS
CAPACITY: 14 standard place-settings
NaturalDry it is a convection drying system which automatically opens
the door during/after the drying phase to ensure exceptional drying per-
formance every day. The door opens at a temperature that is safe to your
kitchen furniture.
UPPER RACK
(loading example for the
upper rack)
Load delicate and light dish-
es: glasses, cups, saucers,
low salad bowls.
LOWER RACK
(loading example for the lower rack)
For pots, lids, plates, salad bowls, cut-
lery etc. Large plates and lids should
ideally be placed at the sides to avoid
interferences with the spray arm.
The lower rack has tip-up supports
which can be used in a vertical po-
sition when arranging plates or in
ahorizontal position (lower) to load
pans and salad bowls easily.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
CUTLERY BASKET
It is tted with top grids for improved cutlery
arrangement. It must only be positioned at
the front of the lower rack.
Knives and other utensils with sharp
edges must be placed in the cutlery
basket with the points facing down-
wards or they must be positioned hori-
zontally in the tip-up compartments on
the upper rack.
POWER CLEAN®
Power Clean® uses the special water jets in
the rear of cavity to wash more intensively
the high dirty items. The lower rack has a
Space Zone, a special pull-out support in
the rear of the rack that can be used to
support frying pans or baking pans in upright position, thus
taking up less space.
Placing the pots/casseroles faced to the Power Clean® compo-
nent please activate the POWER CLEAN® on the panel.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher does
not ll the water. Display
shows: and F6, both
On/O and START/Pause
LEDs are blinking rapidly.
No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) repro-
gram the dishwasher and reboot.
The sieve in the water inlet hose is clogged; it is nec-
essary to clean it.
After having carried out the verication and cleaning, turn o
and turn on the dishwasher and restart a new program.
Dishwasher nishes the cycle
prematurely.
Display shows: F15 and both
On/O and START/Pause
LEDs are blinking rapidly.
Drain hose positioned too low or siphoning into
home sewage system.
Check if end of drain hose is placed at correct height (see INSTAL-
LATION).Check for siphoning into home sewage system, install air
admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
Please scan the QR code on your product in order to have more detailed information.
More information in the Daily Reference Guide on website.
CLEANING AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may be
removed by pulling it up-
wards.
TROUBLESHOOTING

Produkt Specifikationer

Mærke: Whirlpool
Kategori: Opvaskemaskine
Model: W3F D634 X

Har du brug for hjælp?

Hvis du har brug for hjælp til Whirlpool W3F D634 X stil et spørgsmål nedenfor, og andre brugere vil svare dig


Opvaskemaskine Whirlpool Manualer

Whirlpool

Whirlpool W7U HS41 X Manual

28 August 2025
Whirlpool

Whirlpool WIC 3C33 PFE Manual

28 August 2025
Whirlpool

Whirlpool W0B D851A X Manual

28 August 2025
Whirlpool

Whirlpool W7F HS51 Manual

28 August 2025
Whirlpool

Whirlpool WFO 3T133 PF X Manual

28 August 2025
Whirlpool

Whirlpool W3F D634 X Manual

28 August 2025
Whirlpool

Whirlpool W0I D751A X Manual

28 August 2025
Whirlpool

Whirlpool WH7IPA15BM6L0 Manual

28 August 2025
Whirlpool

Whirlpool WH6IA10BS7L0 Manual

27 August 2025
Whirlpool

Whirlpool WFO 3O33 PL X Manual

27 August 2025

Opvaskemaskine Manualer

Nyeste Opvaskemaskine Manualer

KKT Kolbe

KKT Kolbe DW401W Manual

28 August 2025
KKT Kolbe

KKT Kolbe DW4505VI Manual

28 August 2025
KKT Kolbe

KKT Kolbe DW601VI Manual

28 August 2025
Siemens

Siemens SN15ZS01CS Manual

28 August 2025
Siemens

Siemens SN23EW04MG Manual

28 August 2025
Bosch

Bosch SPU4HMS10E Manual

28 August 2025
Grundig

Grundig GNLP4620W Manual

28 August 2025
Siemens

Siemens SN13EC04CS Manual

28 August 2025
Siemens

Siemens SX73HX01CE Manual

28 August 2025
Profilo

Profilo BMS612V5 Manual

28 August 2025
