Daily Reference Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

1. ON-OFF/Reset button

with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Key lock indicator light

10. Program number and remaining time indicator

11. Display

FIRST TIME USE

1 2 3 4

7 8

13 14

12. Power Clean® option button with indicator light

13. Half Load option button with indicator light/ Settings - 3 sec. press

14. Extra Dry Option button with indicator light/ Keylock - 3 sec. press

15. Delay option button with indicator light

16. START/Pause button with indicator light

Before using the appliance carefully read

Safety and Installation Instructions. More information about your

product available on website: docs.whirlpool.eu

After installation, please remember to remove all transport protection

parts from the dishwasher.

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings

(Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS

/NEXT to scroll through the list of available settings

(see table below), then press START/Pause

to view and change the

value of the currently selected setting.

5. Press PREVIOUS

/NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press ON-OFF

or wait 30 seconds to exit the menu.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light

on the con-

trol panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 0,5 kg); it is not un-

usual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Run a program every time as soon as you completed relling the salt

reservoir to avoid corrosion.

Setting the water hardness

To allow the water softener to work in a perfect way, it is essential that the water

hardness setting is based on the actual water hardness in your house. This infor-

mation can be obtained from your local water supplier. The factory setting is “3”.

See „WATER HARDNESS TABLE”

To change, follow instructions in section “SETTING MENU”.

Only use salt that has been specically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL indicator

light switches o.

If the salt container is not lled, the water softener and the heating

element may be damaged as a result of limescale accumulation.

Use of salt is recommended with any type of dishwasher detergent.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning

eciency. This system regenerates itself with salt, therefore it is re-

quired to rell the salt container when empty. The frequency of regen-

eration depends on the water hardness level setting - regeneration takes

place once per 4-6 Eco cycles with the water hardness level set to 3. The

regeneration process occurs at the beginning of the cycle with additional

fresh water.

• Single regeneration consumes: ~3L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be

lled when the RINSE AID REFILL indicator light

in the control panel is lit.

1. Open the dispenser B by

pressing and pulling up the

tab on the lid.

2. Pour in the rinse aid (max.110

ml), making sure it does not

overow from the dispenser.

If this happens, clean the spill

immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the appliance tub..

Adjusting the dosage of rinse aid

If you are not completely satised with the drying results, you can adjust

the quantity of rinse aid used.

To change, follow the instructions in the section “SETTING MENU”.

If the rinse aid level is set to ZERO, no rinse aid will be supplied. The LOW

RINSE AID indicator light will not be lit if you run out of rinse aid.

A maximum of 6 levels can be set according to the dishwasher model.

• If you see bluish streaks on the dishes, set a low number (0-3).

• If there are drops of water or limescale marks on the dishes, set

a mid-range number (4-5).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce

the detergent into the dry dispenser D only. Place the amount of

detergent for pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser D, there are indica-

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the

dispenser and close the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling

it up until the closing device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

LETTER SETTING

VALUES

(Default - in bold)

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

NaturalDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings

Press START/Pause to restore to the factory

default all the values of the settings included in

the settings menu.

Water Hardness Table

Level

°dH

German degrees

°fH

French degrees

°Clark

English degrees

1 (soft) 0 - 6 0 - 10 0 - 7

2 (medium) 7 - 11 11 - 20 8 - 14

3 (average) 12 - 16 21 - 29 15 - 20

4 (hard) 17 - 34 30 - 60 21 - 42

5 (very hard) 35 - 50 61 - 90 43 - 62

CONTROL PANEL

1. CHECK WATER CONNECTION

Check that the dishwasher is connected to the water supply and that

the tap is open.

2. SWITCH ON THE DISHWASHER

Press the ON/OFF button.

3. LOAD THE RACKS (see LOADING THE RACKS).

4. FILL THE DETERGENT DISPENSER

5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE

Select the most appropriate program in accordance with the type of

crockery and its soiling level (see PROGRAMS DESCRIPTION) by pressing

the PREVIOUS/NEXT buttons.

Select the desired options (see OPTIONS AND FUNCTIONS). Not all

options are compatible with all programs.

6. START

Start the wash cycle by closing the door and pressing START/Pause

button (led is lit). When the program starts you hear a single beep.

7. END OF WASH CYCLE

The end of the wash cycle is indicated by sound and the display shows

END. Switch o the appliance by pressing the ON/OFF button and

opening the door.

Wait for a few minutes before removing the crockery - to avoid burns.

Unload the racks, beginning with the lower one.

MODIFYING A RUNNING PROGRAM

If a wrong program was selected, it is possible to change it, provided that

it has only just begun. RESET the machine: press and hold the ON/OFF

button for more than 3. sec., and the machine will switch o. The dashboard

will show “0:01”. Wait until drain cycle ends (around 1 minute). Switch the

machine back on using the ON/OFF button and select the new wash cycle

and any desired options. Start the cycle by pressing the START/Pause button.

ADDING EXTRA CROCKERY

Without switching o the machine, open the door rst slightly to avoid wa-

ter splashing out (START/Pause led starts blinking) (Caution!: Hot steam!)

and place the crockery inside the dishwasher. Close the door and press the

START/Pause button, the cycle will resume from the point at which it was

interrupted.

ACCIDENTAL INTERRUPTIONS

If the door is opened during the wash cycle, or if there is a power cut, the

cycle stops. Close the door and ONLY IF YOU PRESS the START/Pause

button the cycle will resume from the point at which it was interrupted.

TIPS

Before loading the baskets, remove all food residues from the crockery

and

empty the glasses. You do not need to rinse beforehand under running

water.

Arrange the crockery so that it is held in place rmly and does not tip over;

and arrange the containers with the openings facing downwards and the

concave/convex parts placed obliquely, thus allowing the water to reach

every surface and ow freely.

Warning: lids, handles, trays and frying pans should not prevent the

sprayer arms from rotating.

Place any small items in the cutlery basket.

Very soiled dishes and pans should be placed in the lower basket because

in this sector the water sprays are stronger and allow a higher washing

performance.

After loading the appliance, make sure that the sprayer arms can rotate

freely.

UNSUITABLE CROCKERY

• Wooden crockery and cutlery.

• Delicately decorated glasses, artistic handicrafts and antique crockery.

Their decorations are not resistant.

• Parts in synthetic material which do not withstand high temperatures.

• Copper and tin crockery.

• Crockery soiled with ash, wax, lubricating grease or ink.

The colours of glass decorations and aluminium/silver pieces can change

and fade during the washing process. Some types of glass (e.g. crystal

objects) can become opaque after a number of wash cycles too.

DAMAGE TO GLASS AND CROCKERY

• Only use glasses and porcelain guaranteed by the manufacturer as

dishwasher safe.

• Use a delicate detergent suitable for crockery

• Collect glasses and cutlery from the dishwasher as soon as the wash

cycle is over.

TIPS ON ENERGY SAVING

• When the household dishwasher is used according to the manufactur-

er’s instructions, washing tableware in a dishwasher usually con-

sumes less energy and water than hand dishwashing.

• In order to maximize dishwasher eciency, it is recommended to

initiate the wash cycle once the dishwasher is fully loaded. Loading

the household dishwasher up to the capacity indicated by the manu-

facturer will contribute to energy and water savings. Information on the

correct loading of tableware can be found in the Loading chapter.

In case of partial loading, it is recommended to use a dedicated wash op-

tions if available (Half load/ Zone Wash/ Multizone), lling up only select-

ed racks. Incorrect loading or overloading of the dishwasher may increase

resources usage (such as water, energy and time, as well as increase noise

level), reducing cleaning and drying performance.

• Manual pre-rinsing of tableware items leads to increased water and

energy consumption and is not recommended.

HYGIENE

To avoid odour and sediment which can be accumulated in the dishwash-

er please run a high-temperature program at least once a month.

Use a teaspoon of detergent and run it without loading to clean your

appliance.

RESISTANCE TO FROST

If the appliance is placed in surroundings exposed to the risk of frost, it

must be drained completely. Turn o the water tap, remove the inlet and

outlet hoses, and let all the water drain away. Make sure that the water

softener is full of dissolved regeneration salt in the salt container, to

protect the appliance from temperatures of up to -20°C.

If the appliance was stored in frost conditions the appliance must remain at

an ambient temperature of min. 5°C for at least 24 hours before the rst run.

ADVICE AND TIPS

DAILY USE

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	W7F HP33 X
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	600 mm
Dybde:	595 mm
Højde:	850 mm
Vægt:	47000 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Skærmtype:	LED
Strøm:	13 A
Ledningslængde:	1.3 m
Pakkevægt:	49000 g
Pakkedybde:	590 mm
Pakkebredde:	625 mm
Pakkehøjde:	910 mm
Bluetooth:	Ingen
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Indvendig belysning:	Ingen
Tilsluttet belastning:	1900 W
Støjniveau:	43 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Børnesikring:	Ja
Justerbare fødder:	Ja
Dør farve:	Rustfrit stål
Balje materiale:	Rustfrit stål
Vandforbrug pr. cyklus:	9.5 L
Indbygget vandblødgører:	Ja
Bestik rum type:	Skuffe
Farve på kontrolpanel:	Sort
Antal kuverter:	15 kuverter
Cyklustid:	210 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Auto, Crystal 45°C, Eco, Intensive 65°C, Mixed, Pre-wash, Quick 45min, Silent 50°C
Halv belastning:	Ja
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.861 kWh
Energieffektivitetsskala:	A til G
Selvrensende:	Ja
Antal temperaturindstillinger:	3
AquaSensor funktion:	Ingen
AquaStop funktion:	Ja
Glasbeskyttelse:	Ja
Indikator for resterende tid:	Ja
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Integreret timer:	Ja
Wi-Fi kontrolleret:	Ingen
Vandpåfyldning:	Cold, Hot
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	86 kWh
Brugerdefineret panel klar:	Ingen
Temperatur (maks):	70 °C
Cyklustid (hurtigt vaskeprogram):	30 min.
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Strømforbrug (fortsat-tændt):	6 W
Tørresystem:	Naturlig
Ekstra tørt:	Ja
Belastningsensor:	Ja
Antal kurve:	2 kurv(e)
Strømstiktype:	Type G
Automatisk døråbning:	Ja
Maksimal varmtvandsforsyning temperatur:	60 °C
Varighed af tilstanden fortsat-tændt:	12 min.
Selvbalancerende hængsel:	Ja
Gulvindikatorlys:	Ingen
Automatiske programmer:	Ja
Quick Time-funktion:	Ja
Whirlpool-teknologier (opvaskemaskine):	6TH SENSE
