Side 1/36

Quick guide

* Available only on certain models

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

FIRST TIME USE

After installation, wait at least two hours before connecting the

appliance to the power supply. Once connected, it will start working

automatically. The ideal temperature settings are preset from the

factory.

After turning the appliance on, wait 4-6 hours for it to reach the correct

food storage temperature.

CONTROL PANEL

1. On/o

2. Fast Cool button

3. Fridge temperature setting

4. Refrigerator temperature display

5. Alarm

6. Freezer temperature display

7. Freezer temperature setting

8. Fast Freeze

9. ECO / ECOPlus

10. Good Night

ON/OFF

To switch on/switch o the product press on/o on the display.

FAST COOL FUNCTION

You can enable or disable the Fast Cool feature (quick cooling of

both fresh and just cooked food) by pressing the Fast Cool key on the

display. The Fast Cool led turns on when activated. The function is

automatically disabled after 12 hours, or can be manually disabled by

pressing the Fast Cool button.

FRIDGE TEMPERATURE SETTING

Used to modify the temperature setting of the refrigerator. Conrmation

corresponding to the selected temperature appears on the display.

Recommended setting for the refrigerator compartment is +4°C.

ALARM

An alarm situation has been detected in the product (see alarm table).

REFRIGERATOR TEMPERATURE DISPLAY

Shows the set temperature for the refrigerator compartment.

FREEZER TEMPERATURE DISPLAY

Shows the set temperature for the freezer compartment.

FREEZER TEMPERATURE SETTING

Used to modify the temperature setting of the freezer. Conrmation

corresponding to the selected temperature appears on the display.

Recommended setting for the freezer compartment is -18°C.

FAST FREEZE FUNCTION

This function is recommended for freezing fresh food. Fresh food

should be frozen as quickly as possible, for the best possible

preservation and for keeping its nutritional value. Press the Fast Freeze

key when you need to freeze fresh food, the Fast Freeze indicator will

come on. We recommend you press the Fast Freeze key 24 hours before

putting the food in, in order to prepare the freezer compartment for the

best possible freezing conditions. We recommend you use the bottom

drawer to maximize the freezing capacity. The Fast Freeze function is

automatically deactivated after 48 hours, or you can disable it manually

by pressing the Fast Freeze key.

ECO

You can use this function to optimize energy consumption of the

product. Activate or deactivate the ECO function by pressing the ECO

key on the display. The light of the ECO on the display is on when

activated. The temperature values +5°C and -18°C appear on the

refrigerator and freezer displays respectively.

Note: The ECO key can enable ECOPlus function.

ECOPLUS

You can use this function to decrease energy consumption of the

product by blanking the control panel when no interaction is needed. To

activate the ECOPlus function press and hold the ECO key for 8 seconds.

After 5 seconds from activation all the digits and LED light switch o,

except for the ECO light that keeps blinking. You can press any key to

wake up the display and make your adjustments. 5 seconds after no

GOOD NIGHT

The Good Night function makes it possible to minimize any noise, at

the same time ensuring suitable storage performance.

The compressor will be working at the minimum speed that can be

set. When you start the function, the display enters into standby mode

and the relevant Good Night icon lights up. The Good Night function

can automatically stop either after maximum 6 hours or after the

performance of the product with the function ON can no longer be

ensured owing to a number of dierent reasons.

To stop the function manually press the button again or switch o the

device - we recommend starting the function in the night hours or

minimizing any interaction with the fridge to prevent the function from

stopping automatically.

LED LIGHT

This product contains a light source of energy eciency class F.

If the LED light system does not work, please contact the Service to

replace it.

HOW TO STORE FRESH FOOD AND BEVERAGES

a) b)

* The number and type of door balconies depends on the model

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily

food, delicatessen, yogurt

COOLEST AREA

a) Suggested for storage of cold cuts, desserts, meat

and sh

b) Suggested for storage of meat and sh.

The drawer available only on certain model

FRUIT & VEGETABLE DRAWER

FREEZER DRAWERS

(One drawer in models lower than 1,7m)

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh / cooked food

REFRIGERATION COMPARTMENT

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator compartment

indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

Fresh Box 0°C drawer *

The Fresh Box 0°C it is a drawer (b) ideal to store meat and sh. By

decreasing/increasing the fridge temperature, you impact the Fresh

Box 0°C compartment temperature as well. Keep in mind that this

compartment is a mechanical feature operating all the time and it

cannot be switched o.

Humidity Control*

Turn on the humidity regulator (position B) if you want to store food

in a less humid environment, like fruit, or turn it o (position A) if you

want to store food in a more humid environment, like vegetables.

Foldable shelf*

This shelf can be used in three dierent ways:

1. Full-depth, to use the entire surface.

Half-depth, to use the rear part and at the same time create space

for taller items (like bottles and jugs) on the shelf below. To adjust

the shelf to half-depth, slightly raise the front part then pull it in.

Flipped up if you need to make space for tall or bulky items on the

shelf below. To ip the shelf up, rst adjust it to the halfway

position from half-depth. Flip the shelf down to go back to using it

in half-depth and full-depth.

* Available only on certain models

Important: The refrigerator compartment light switches on when

the refrigerator door is opened. If the door is kept open for more than

8 minutes the light will be automatically switched o.

6th SENSE

This function automatically works to ensure the optimal conditions

to preserve the stored food. The “6th Sense” function is automatically

activated when:

• a large amount of food is loaded into the refrigerator

• the refrigerator door is left open for a long time

• a prolonged power failure takes place, causing the internal

temperature of the appliance to increase to values that cannot

guarantee safe storage of food.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	W7X 83T MX
Bredde:	596 mm
Dybde:	678 mm
Højde:	1912 mm
Vægt:	73000 g
Produktfarve:	Rustfrit stål
Kontroltype:	Berøring
Lampe type:	LED
Indbygget skærm:	Ja
Ledningslængde:	1.6 m
Pakkevægt:	76000 g
Pakkedybde:	760 mm
Pakkebredde:	640 mm
Pakkehøjde:	1960 mm
Årligt energiforbrug:	201 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	160 W
Støjniveau:	34 dB
Justerbare fødder:	Ja
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Vendbare døre:	Ja
Fryser, netto rumindhold:	104 L
Frysekapacitet:	11 kg/24t
Opbevaringstid under strømafbrydelse:	11 t
Klimaklasse:	SN-T
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Køleskabsdøre:	4
Køleskab, netto rumindhold:	231 L
Total netto kapacitet:	335 L
No Frost (køleskab):	Ja
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ja
Skærmplacering:	På døren
Hylder, materiale:	Glas
Ismaskine:	Ingen
Multi-Airflow-system (køleskab):	Ja
Flaskeholder:	Ja
No Frost (fryser):	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Super Cool funktion:	Ja
Frisk zone, aflukke:	Ja
Feriefunktion:	Ingen
Automatisk afrimning (køleskab):	Ja
Temperaturalarm:	Ja
Minimal driftstemperatur:	10 °C
Maksimal driftstemperatur:	43 °C
Antal aftagelige hylder:	2
Antal kompressorer:	1
Fejlalarm:	Ja
Vandbeholder:	Ja
Antal døre:	2 dør(e)
Kølesystem:	Dynamisk (blæserassisteret)
Ventilation:	Ingen
Forsænket håndtag:	Ja
Antibakterielt rum:	Ingen
Midterste rum:	Ingen
Garantiperiode:	2 År
