Side 1/19
EN
Quick guide
1. On/Standby Indicator and Button
2. Black Out Alarm Long Black-Out
Alarm ndicator I
(see the below Alarm Table)
3. Freezer Temperature / Fast
Freeze button
4. Freezer Temperature Led
5. Stop Alarm Button
(see the below Alarm Table)
6. 6th Sense Indicator
7. Party Mode
8. Fridge Temperature Led
9. Fridge Temperature / Fast Cool
button
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
APPLIANCE
CONTROL PANEL
1. Fruit and vegetable compartment*
2. Food Care Zone 0°C/
Safe Defrost*
3. Freezer and storage compartment
4. Dairy Shelf*
5. Movable shelves*
6. Temperature Indicator*
7. Bottle rack*
8. Bottle shelf*
9. Levelling feet
* Varies by number and/or position,
available only on certain models.
3
6
7
8
9
2
4
5
1
8
5
6
4
7
1
2
3
9
* Available only on certain models
1
1
ACCESSORIES
EASY ICE BOTTLE RACK
FIRST TIME USE
HOW TO START THE APPLIANCE
After plugging the appliance to the mains, it starts the
operation automatically. After starting the appliance, wait at
least 4-6 hours before placing food into the fridge and into
the freezer compartment.
When the appliance is connected to the power supply, the
display lights up and all the icons appear on the display for
approximately 1 second. The default (factory) values of the
fridge - freezer compartment settings light-up.
DAILY USE
FUNCTIONS
ON/STANDBY INDICATOR /BUTTON
To put the product in Stand-by, press and hold for 3 seconds.
All the icons turn o except:
FRIDGE TEMPERATURE
To adjust the Fridge Temperature, press the Fridge °C
button. The Fridge Temperature can be adjusted between
+2°C and + 8°C, as shown by the Fridge Temperature LEDs.
FAST COOL
Using Fast Cool function it is possible to increase the cooling
in the refrigerator compartment. The use of this function is
recommended when placing a very high quantity of food
in the refrigerator compartment. Press & hold for 3 sec.
the Fridge °C button to activate Fast Cool function. When
activated, the Fast Cool indication will be displayed by the
Fridge Temperature LEDs as shown in the beside sequence.
The function is automatically disabled after 6 hours, or can be
manually disabled by pressing Fridge °C button.
FREEZER TEMPERATURE
To adjust the Freezer Temperature, press the Freezer °C
button. The Freezer Temperature can be adjusted between
-16°C and -24°C, as shown by the Freezer Temperature LEDs.
FAST FREEZE
The use of this function is recommended when placing a very
high quantity of food to be frozen in the freezer compartment.
24 hours before freezing fresh food, press & hold for 3 sec.
the Freezer button to activate the Fast Freeze function. When
activated, the Fast Freeze indication will be displayed by the
Freezer Temperature LEDs as shown in beside sequence.
After 24 hours place the food to be frozen in the upper
basket of freezer compartment. The function is automatically
disabled after 48 hours, or can be manually disabled by
pressing Freezer °C button.
PARTY MODE
Use this function to chill drinks inside the freezer
compartment. Press the Party Mode button to activate/
deactivate this function. Once the Party mode has been
activated, after 30 minutes an acoustic alarm will remind you
to remove drink/bottle from the freezer compartment. To
mute the alarm press the Stop alarm button, or deactivate the
function pressing the Party mode button.
Important: do not leave the bottle inside the freezer
compartment longer than the function is active (30 minutes).
6TH SENSE INDICATOR
6th Sense technology automatically works to ensure the
optimal conditions to preserve the stored food.
SMART DISPLAY
This optional function can be used to save energy. To activate
the Smart Display, press Fridge °C and Freezer °C buttons
at the same time for 3 seconds until an audible signal sounds.
To deactivate this function repeat the same procedure.
See Use and Care Guide for more details on functions / see last
page for information on how to obtain the Use and Care Guide
* Available only on certain models
2
