Whirlpool WB70I 952 X Manual

Whirlpool Køleskab WB70I 952 X

Læs gratis den danske manual til Whirlpool WB70I 952 X (72 sider) i kategorien Køleskab. Denne vejledning er vurderet som hjælpsom af 4 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 2.5 anmeldelser. Har du et spørgsmål om Whirlpool WB70I 952 X, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/72

Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Freezer Operation Button

2. Super Freeze Button

3. Super Freeze Blue Light

4. Freezer Temperature Yellow Light

5. Fridge Temperature Yellow Light

6. Speed Cool Blue Light

7. Speed Cool Button

8. Refrigerator Operation Button

APPLIANCE

CONTROL PANEL

1. Control panel*

2. Fruit and vegetable compartment*

3. Food Care Zone 0°C/

Safe Defrost*

4. Freezer and storage compartment

5. Movable shelves*

6. Temperature ındicator*

7. Bottle rack*

8. Bottle shelf*

9. Levelling feet

* Varies by number and/or position,

available only on certain models.

1234 5678

ACCESSORIES

EASY ICE BOTTLE RACK

FIRST TIME USE

HOW TO START THE APPLIANCE

After plugging the appliance to the mains, it starts the

operation automatically. After starting the appliance, wait at

least 4-6 hours before placing food into the fridge and into

the freezer compartment.

When the appliance is connected to the power supply, the

display lights up and all the icons appear on the display for

approximately 1 second. The default (factory) values of the

fridge - freezer compartment settings light-up.

DAILY USE

FUNCTIONS

FREEZER OPERATION BUTTON

To regulate the temperature the freezer compartment.

Button is used with SUPER FREEZE Button to switch on/

switch o the product by pressing both 3 seconds.

FREEZER TEMPERATURE

To adjust the Freezer Temperature, press the Freezer

Operation °C button. The Freezer Temperature can be

adjusted between -18°C and -26°C, as shown by the Freezer

Temperature LEDs.

SUPER FREEZE

The use of this function is recommended when placing a very

high quantity of food to be frozen in the freezer compartment.

Press the SUPER FREEZE button to enable or disable the

function. When the Super Freeze function activated, blue light

illuminates on the freezer display. After 24 hours place the

food to be frozen in the upper basket of freezer compartment.

The function is automatically disabled after 48 hours, or can be

manually disabled by pressing Super Freeze °C button.

FRIDGE TEMPERATURE

To adjust the Fridge Temperature, press the Fridge Operation

°C button. The Fridge Temperature can be adjusted between

+2°C and +8°C, as shown by the Fridge Temperature LEDs.

SPEED COOL

Using Speed Cool function it is possible to increase the

cooling in the refrigerator compartment. The use of this

function is recommended when placing a very high quantity

of food in the refrigerator compartment. Press the Speed cool

button to activate Speed Cool function. When speed cooling

function is activated, blue light illuminates on the refrigerator

display. The function is automatically disabled after 6 hours, or

can be manually disabled by pressing Speed cool button.

REFRIGERATOR LIGHT

The light system inside the refrigerator compartment uses

LEDs light, allowing a better lightning as well as a very low

energy consumption.If the LED light system does not work,

please contact the Service to replace it.

SENSE

Sense technology automatically works to ensure the

optimal conditions to preserve the stored food.

SMART DISPLAY

This optional function can be used to save energy. To activate

the Smart Display, press

Fridge °C and Freezer °C buttons

at the same time for 3 seconds until an audible signal sounds.

To deactivate this function repeat the same procedure.

Remember that this function does not disconnect the

appliance from the power supply, but only reduce the power

consumed by external display.

TEMPERATURE INDICATOR*

Temperature indicator informs you if the temperature in this

cavity is cold enough for storage with the word “OK”.

1. Check that OK appears clearly on the indicator light (see

the picture below).

If the word “OK” does not appear it means that the

temperature is too high: set a lower temperature and wait

approximately 10 hours until the temperature has been

stabilised.

See Use and Care Guide for more details on functions / see last

page for information on how to obtain the Use and Care Guide

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	WB70I 952 X
Justerbar termostat:	Ja
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	700 mm
Dybde:	755 mm
Højde:	1950 mm
Vægt:	84000 g
Produktfarve:	Rustfrit stål
Lampe type:	LED
Indbygget skærm:	Ingen
Strøm:	1.3 A
Ledningslængde:	2.17 m
Årligt energiforbrug:	291 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Inverter-teknologi:	Ja
Tilsluttet belastning:	- W
Støjniveau:	37 dB
Justerbare fødder:	Ja
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	C
Energieffektivitetsklasse:	E
Vendbare døre:	Ja
Fryser, netto rumindhold:	153 L
Fryser, brutto rumindhold:	162 L
Frysekapacitet:	18 kg/24t
Opbevaringstid under strømafbrydelse:	18 t
Klimaklasse:	SN-T
Køleskab antal hylder/kurve:	3
Antal grøntsagsskuffer:	2
Æggebakke:	Ja
Køleskabsdøre:	3
Dørpanel inkluderet:	Ingen
Køleskab, netto rumindhold:	309 L
Total netto kapacitet:	462 L
No Frost (køleskab):	Ja
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ja
Hylder, materiale:	Glas
Ismaskine:	Ingen
Køleskab, brutto rumindhold:	330 L
Flaskeholder:	Ja
No Frost (fryser):	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Super Cool funktion:	Ja
Isterning bakke:	Ja
Frisk zone, aflukke:	Ingen
Strømstiktype:	Type F (CEE 7/4)
Automatisk afrimning (køleskab):	Ja
Antal aftagelige hylder:	2
Antal kompressorer:	1
Fejlalarm:	Ingen
Fryser, indvendigt lys:	Ingen
Fejlindikation:	Ja
Ventilation:	Ingen
