Whirlpool WBC 3C34 PF X Manual

Whirlpool Opvaskemaskine WBC 3C34 PF X

Læs gratis den danske manual til Whirlpool WBC 3C34 PF X (28 sider) i kategorien Opvaskemaskine. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 3.5 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Whirlpool WBC 3C34 PF X, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/28

ENQuick Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

CONTROL PANEL

FIRST TIME USE

1. On-O/Reset button with indicator light

2. Program selection button with indicator light

3. Multizone button with indicator light / Keylock

4. Eco program indicator light

5. Keylock indicator light

6. Display

7. Program number and remaining time

indicator

8. Tablet (Tab) indicator light

9. Closed water tap indicator light

10. Rinse Aid rell indicator light

11. Salt rell indicator light

12. Power Clean button with indicator light /

Tablet (Tab)

13. Delay button with indicator light

14. Start/Pause button with indicator light /

Drain out

Program Programs description

Drying

phase

Natural-

Dry

Available

options

Duration of

wash program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware,

that for this use, it is the most ecient programme in terms of

its combined energy and water consumption, and that it is used

to assess compliance with the EU Ecodesign legislation.

3:10 9.5 0.85

Sense® 50°- 60°- For normally soiled dishes with dried food

residues. Senses the level of soiling on the dishes and adjusts

the program accordingly.

1:25 - 3:00 7.0 - 14.0 0.90 - 1.40

Intensive 65° - Program recommended for heavily soiled croc-

kery, especially suitable for pans and saucepans.

2:50 16.0 1.60

Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that

ensures optimal cleaning and drying performance in shorter time.

1:25 11.5 1.10

Crystals 45° - Program for delicate items, which are more sensitive

to high temperatures, for example glasses and cups.

1:40 11.5 1.20

Rapid 30’ 50° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Without drying.

- -

0:30 9.0 0.50

Silent 50° - Suitable for night-time operation of the appliance.

With the lowest noise.

3:30 15.0 1.15

Prewash - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

- -

0:12 4.5 0.01

PROGRAMS TABLE

Before using the appliance carefully read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

7 11 12

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser A should be lled when the

RINSE AID REFILL indicator light in the

control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

KEYLOCK - A long press (for 3 seconds) of MULTIZONE button, will

activate the KEYLOCK function. To deactivate the KEYLOCK, long press again.

DELAY -The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN - Thanks to the additional power jets this option provides

a more intensive and powerful wash in the lower rack, in the specic area.

This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent. By default the

appliance washes dishes in all racks.

NaturalDry It is a convection drying system which automatically opens

the door during/after the drying phase to ensure exceptional drying

performance every day. The door opens at a temperature that is safe to

your kitchen furniture.

CLEANING AND MAINTENANCE

More information in the Daily Reference Guide on the website.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product’s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label.

The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

CUTLERY RACK

(loading example for the

cutlery rack)

The third rack was desi-

gned to house the cutlery.

UPPER RACK

(loading example for the

upper rack)

Load delicate and light

dishes: glasses, cups, sa-

ucers, low salad bowls.

FOLDABLE

FLAPS WITH

ADJU-

STABLE

POSITION

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc.

Large plates and lids should ideally be placed at

the sides to avoid interferences with the spray

arm.

The lower rack has tip-up supports which can

be used in a vertical position when arranging

plates or in a horizontal position (lower) to load

pans and salad bowls easily.

(loading example for the lower rack)

POWER CLEAN

Power Clean uses the special water jets in the rear of cavity to wash more in-

tensively the high dirty items. The lower rack has a Space Zone, a special pull-

-out support in the rear of the rack that can be used to support frying pans or

baking pans in upright position, thus taking up less space.

Placing the pots/casseroles faced to the Power Clean

component please activate the POWER CLEAN on the

panel.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

400011673396

03/2023 dk - Xerox Fabriano

TROUBLESHOOTING

Please scan the QR code on your product in order to have more detailed information.

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows:

and F6, both On/

O and START/Pause

LEDs are blinking

rapidly.

No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher and

reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it.

After having carried out the verication and cleaning, turn o and turn on the dishwasher

and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: F15

and both On/O and

START/Pause LEDs are

blinking rapidly.

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for siphoning

into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WBC 3C34 PF X
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Strømforbrug (slukket):	- W
Placering af apparat:	Fuldt indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	44 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Rustfrit stål
Vandforbrug pr. cyklus:	9.5 L
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	14 kuverter
Cyklustid:	180 min.
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Eco 50°C, Glass/delicate, Intensive 65°C, Pre-wash, Silent
Indikator for afspændingsmiddel:	Ja
Energieffektivitetsskala:	A til G
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	85 kWh
Temperatur (maks):	60 °C
Strømforbrug (fortsat-tændt):	0.5 W
Antal kurve:	2 kurv(e)
