A. Refrigerator Compartment

2. Thermostat / light unit

3. Shelves / Shelf area

4. Cooler compartment

5. Rating plate with commercial name

7. Crisper divider

8. Reversibility kit

9. Egg tray

10. Separator

11. Door trays

B. Freezer Compartment

12. Storage baskets for frozen food items

12a “Eco green” basket (only in models with ECO GREEN function)

13. Ice tray and/or cold accumulator

14. Bottom basket (freezing zone)

16. The freezer door trays for pizza or other frozen products with a

short storage time (depending on the model)

Depending on the model the number and type of accesories may vary.

The freezer compartment can be used without the two upper

baskets to increase storage for large products. The lower basket

must not be removed. Place the food products directly on the racks.

After inserting food, ensure that the freezer compartment door

closes properly.

Anti-bacterial protection:

1. Filter in fan (depending on the model)

6. Crisper with antibacterial additives (depending on the

model)

15. Door seals

The crisper and the door seals are manufactured from materials

that inhibit bacterial growth.

Notes:

- In case of power failure the cold accumulator helps to

keep optimal storage temperature longer.

- All shelves and door trays are removable.

- The internal temperatures of the appliance depend on the

ambient temperature, frequency of opening the doors, as well as

location of the appliance. Temperature setting must consider

these factors.

- The appliance accessories are not suitable for washing in

dishwasher.

Fridge/Freezer compartment controls

A. Thermostat knob

B. Light button

C. Thermostat setting indicator

D. Light bulb (max 15W)

The thermostat adjusts temperature in both compartments.

Thermostat set to MIN: low cooling intensity

Thermostat set between MIN and MAX: cooling intensity can be

adjusted according to the preferences.

Thermostat set to MAX: maximum refrigeration intensity.

For best food conservation position is recommended.MED

Thermostat set to

•

:cooling and lighting off.

Thermostat set to ECO GREEN (depending on the model): ECO

function active.

Replacing the light bulb

Before replacing the bulb, remove the power plug from the mains

socket.

To remove the light bulb turn anticlockwise as shown in figure .

ECO GREEN function

This function gives best food preservation

performance with the smallest energy consumption possible

(around 5-10% less in comparison with the normal settings)

if there is lower amount of food to be preserved in the

appliance.

The best food preservation conditions when ECO function is

activated are in the ECO compartments:

- 2 "eco green" shelves in the fridge (with green frames)

- 1 "eco green" basket in freezer compartment

To select the function turn the ECO symbol on the knob of

the regulator.

Fan (depending on the model)

The fan gives more even temperature distribution inside the

refrigerator compartment, allowing better preservation of stored

food.

Important:

Do not obstruct the air intake area with food items.

The fan will run ONLY when the compressor is in operation.

Fan with a button

To switch on the fan press the button (1a). It is advisable to activate

the fan when the ambient air temperature is over 27 ÷ 28°C or if

you perceive drops of water on the glass shelves or in the severe

humidity conditions. Fan switched on improves cooling conditions. To

keep preferable appliances setting, having the fan switched on, there

may be a need to adjust the thermostat.

Important:

Remember to turn off the fan when there is a lower ambient

air temperature.

Fan without a button

An electric system automatically turn on and turn off the fan.

If the appliance has the fan it can be equipped with the filter.

Remove it from the box (found in the crisper drawer (item 6) and

insert into the cover of fan (item 1b).

The replacement procedure is attached with the filter.

Defrosting the freezer

compartment

The freezer should be defrosted once or

twice a year or when excessive frost is

present (3 mm thickness).

The formation of frost is normal.

The amount and rate at which frost

accumulates depends on room conditions

and how often the door is open.

To defrost the unit, switch off the freezer compartment or the whole

appliance, depending on the model, and remove all food products.

Leave the freezer door open to allow the frost to melt.

For appliances in figure only pull out the defrost water drain and

place a container under the drain.

When the operation is completed, put back the defrost water drain.

Clean the inside of the freezer. Rinse and dry thoroughly. Switch the

freezer compartment, or the whole appliance, back on and store the

food inside.

Defrosting the refrigerator compartment

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator

compartment indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected

in a container, where it evaporates.

PRODUCT SHEET

5019 637 01044/B

Printed in Poland 05/09

IGB FINDKNSGRPENLFD

501963701044BGB:Layout 1 8-05-2009 9:28 Pagina 1
