Side 1/28

Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance. Position the antibacterial antiodour lter in the fan as

demonstrated in the lter packaging (if available).

CONTROL PANEL

1. Indicator Leds

(to display the current temperature

setpoint or the Fast Cooling function)

2. Fast Cooling Button/ Temperature Button

FAST COOLING

The use of the Fast Cooling function is recommended to increase the

cooling capacity of the refrigerator compartment when placing a very

high quantity of food within it.

To activate the Fast Cooling function, press and hold for 3 seconds the

Temperature button on the control panel till all the 3 LEDs will turn on.

The function is automatically deactivated after 24 hours and return to

previous selected set point.

The function can be manually deactivated by pressing and holding for

3 seconds the Temperature button on the control panel.

Note: Fast Cooling function should be also switched ON before placing

fresh food to be frozen in the freezer compartment, in order to maximize

the freezing capacity.

TEMPERATURE SETTING

Press the Temperature button on the control panel to adjust the

temperature from the warmest through the lower to the coldest

level. Pressing the Temperature button, the temperature setting will

change cyclically. At rst plug-in of appliance temperature setpoint is

present at medium position (factory setting). Following table shows

temperature setpoints:

OFF ON

High temp.

Med-high temp.

Medium temp.

Med-low temp.

Low temp.

Fast Cooling

Note: Displayed set points correspond to the average temperature

throughout the whole refrigerator.

FAN*

The Fan improves temperature distribution inside the refrigerator

compartment, allowing better preservation of stored food.

If the appliance has the Fan it can be equipped with the antibacterial

lter.

Visit the website page or contact consumer service to purchase the

lter.

* Available only on certain models

REFRIGERATOR LIGHT

The light system inside the fridge compartment uses LEDs light,

allowing a better lightning as well as very low energy consumption.

If the LED light system does not work, please contact the Service to

replace it.

Important: The refrigerator compartment light switches on when the

refrigerator door is opened. If the door is kept open for more than 8

minutes the light will be automatically switched o.

SENSE

This function automatically works to ensure the optimal conditions

to preserve the stored food. The “6

Sense” function is automatically

activated when:

• a large amount of food is loaded into the refrigerator

• the refrigerator door is left open for a long time

• a prolonged power failure takes place, causing the internal

temperature of the appliance to increase to values that cannot

guarantee safe storage of food.

NO-FROST REFRIGERATOR COMPARTMENT

Refrigerator compartment defrosting is completely automatic.

Droplets of water on the rear wall inside the refrigerator compartment

indicate that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

NO-FROST FREEZER COMPARTMENT

No Frost freezers provide chilled air circulation around the storage

areas, and prevent the formation of ice, thereby completely eliminating

the need for defrosting.

Frozen items don’t stick to the walls, labeling stays legible and storage

space remains neat and clear.

HOW TO USE THE APPLIANCE

Legend

TEMPERATE ZONE

Suggested for the storage of tropical fruit, cans,

drinks, eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for storage of cheese, milk, dairy food,

delicatessen, yogurt

FRUIT & VEGETABLE DRAWER

FREEZING ZONE DRAWER

(MAX COOL ZONE)

Suggested to freeze fresh/cooked food.

FREEZER DRAWERS

ALARM TABLE

Alarm type Signal Cause Cure

Door open alarm. Refrigerator Light blinks. The door has remained open for

more than 3 minutes.

Close the door.

Door open alarm. Refrigerator Light OFF. The door has remained open for

more than 4 minutes.

Close the door.

Malfunction. Any temperature indicators

blinks.

Product malfunction. Contact the After-sales Service.

* Available only on certain models

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	WFNF 81E OX 1
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	655 mm
Højde:	1889 mm
Vægt:	67000 g
Produktfarve:	Rustfrit stål
Ledningslængde:	1.5 m
Årligt energiforbrug:	308 kWh
Placering af apparat:	Fritstående
Støjniveau:	42 dB
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	D
Energieffektivitetsklasse:	F
Vendbare døre:	Ja
Fryser, netto rumindhold:	97 L
Frysekapacitet:	9 kg/24t
Opbevaringstid under strømafbrydelse:	16 t
Klimaklasse:	SN-T
Fingeraftryk resistent:	Ja
Køleskab antal hylder/kurve:	4
Køleskab, netto rumindhold:	223 L
Total netto kapacitet:	320 L
No Frost (køleskab):	Ja
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	5*
Fryser position:	Bottom-placeret
Ismaskine:	Ja
Flaskeholder:	Ja
No Frost (fryser):	Ja
Fryser antal hylder/kurve:	3
