W11508799B

Freestanding Gas Range with Double Ovens Quick Start Guide

OPERATING INSTRUCTIONS

WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY

INSTRUCTIONS, located in your appliance's Owner's Manual, before operating this appliance.

Using Your Oven

Step 1. Choose an oven, and then select oven function

Step 2. Set the temperature

Step 3. Press Start

Step 4. Place food inside the oven once set temperature is reached. Close the oven door.

Step 5. (Optional) Enter time to cook

Step 6. The Cancel button can be use to cancel the function during or after cook time.

NOTE: For more detailed instructions on specific functions, see the online Control Guide.

Using Your Range

WARNING

Fire Hazard

Do not let the burner flame extend beyond

the edge of the pan.

Turn off all controls when not cooking.

Failure to follow these instructions can result

in death or fire.

Electric igniters automatically light the surface burners

when control knobs are turned to IGNITE.

Before setting a control knob, place filled cookware on

the grate. Do not operate a burner using empty cookware

or without cookware on the grate.

The flame should be adjusted so it does not

extend beyond the edge of the pan.

NOTE: Visually check that the burner has lit. If

the burner does not ignite, listen for a clicking

sound. If you do not hear the igniter click, turn the

burner off. Check for a tripped circuit breaker or

blown household fuse.

Check that the control knob is pressed

completely down on the valve shaft. If the spark

igniter still does not operate, call a trained repair

specialist.

To Set:

1. Push in and turn knob counterclockwise to

IGNITE.

All surface burners will click. Only the burner

with the control knob turned to IGNITE will

produce a flame.

2. Turn knob to anywhere between Hi and Lo.

REMEMBER: When range is in use or (on some

models) during the Self-Cleaning cycle, the entire

cooktop area may become hot.

POWER FAILURE

In case of a prolonged power failure, the surface burners cannot be lit manually. No attempt should be made to

operate the appliance during a power failure.

ALUMINUM FOIL

IMPORTANT: To avoid permanent damage to the oven bottom finish, do not line the oven bottom with any type

of foil or liner.

For best cooking results, do not cover entire oven rack with foil because air must be able to move freely.

POSITIONING RACKS AND BAKEWARE

IMPORTANT: To avoid permanent damage to the porcelain finish,

do not place food or bakeware directly on the oven door or bottom.

Racks

�Position racks before turning on the oven.

�Do not position racks with bakeware on them.

�Make sure racks are level.

�Place food so it will not rise into the broil element. Allow at least

1/2" (1.3 cm) between pans and the broil element.

To move a rack, pull it out to the stop position, raise the front edge,

and then lift it out. Use the following illustrations as a guide for

positioning racks.

For hamburger patties to have a well-seared exterior and a rare interior in the lower oven, use a flat rack in rack

position 5. Side 1 should cook for approximately 2

to 3

minutes. Side 2 should cook for approximately 4 to

5 minutes. Expect a moderate degree of smoke when broiling.

Baking Layer Cakes on 2 Racks

For best results when baking cakes on 2 racks, use rack

positions 2 and 4 with the Convection Bake function. Place

the cakes on the racks as shown.

Baking Cookies on 2 Racks

For best results when baking cookies on 2 racks, use rack

positions 2 and 4 with the Bake function.

BURNER SIZE

Select a burner that best fits your cookware. Burner positions will vary based on the model of your range. See

the following illustration and chart.

Burner Size Recommended Use

Small

�Low-heat cooking

�Melting chocolate or butter

Large

�For large cookware

Extra-Large

�For large cookware

�Most powerful burner

Oval

�For longer dishes

OVEN VENTS

The oven vents release hot air and moisture from

the ovens and should not be blocked or covered.

Blocking or covering the vents will cause poor air

circulation, affecting cooking and cleaning results.

Do not set plastics, paper, or other items that

could melt or burn near the oven vents.

A. Upper oven vent

B. Lower oven vent

OVEN LIGHT

The oven light is a 40 W halogen bulb. Before replacing, make sure the oven and cooktop are cool and the

control knobs are in the Off position.

To Replace:

1. Disconnect power.

2. Turn the glass bulb cover in the back of the oven counterclockwise to remove.

3. Remove bulb from socket.

4. Replace bulb, using tissue or wearing cotton gloves to handle bulb. To avoid damage to or decreasing the

life of the new bulb, do not touch bulb with bare fingers.

5. Replace bulb cover by turning clockwise.

6. Reconnect power.

IMPORTANT: Do not use lamps rated higher than 40 W.

SABBATH MODE:

The Sabbath Mode sets the oven to remain on in a bake setting until disabled.

For guidance on usage and a complete list of models with Sabbath Mode, visit www.star-k.org or contact us as

per the information given below.

Online Ordering Information

For detailed installation instruction and maintenance tips, information, winter storage, and transportation please

see the Owner’s Manual included with your machine.

For following information on any of the items, guide, a full cycle warranty, detailed product dimensions, or for

complete , Canada instructions for use and installation, please visit https://www.whirlpool.com/owners or in

https://www.whirlpool.ca/owners. call. This may save you the cost of a service

However, if you need to contact us, use the information listed below for the appropriate region.

Canada:

1–800–807–6777

Whirlpool Brand Home Appliances

Customer eXperience Centre

200–6750 Century Ave.

Mississauga, Ontario L5N 0B7

United States:

1–866–698–2538

Whirlpool Brand Home Appliances

Customer eXperience Center

553 Benson Road

Benton Harbor, MI 49022–2692

IMPORTANT: Retain this guide for future use.
