ENQuick Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

1 2 3 4 5 6 7 8 9 10 11

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Only the rst time you do this: ll the salt reservoir

with water.

3. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Whenever you need to add salt, it is mandatory to complete the pro-

cedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently prevent-

ing scale buildup on heater, contributing also to better cleaning eciency.

This system regenerates itself with salt, therefore it is required to rell

salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the appli-

ance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub. If all-in-one detergents are used, we

recommend using the TABLET button, because it adjusts the program so

that the best washing and drying results are always achieved.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

Program

Programs description

Drying

phase

Natural

Dry

Available

options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that for

this use, it is the most ecient programme in terms of its combined en-

ergy and water consumption, and that it is used to assess compliance

with the EU Ecodesign legislation.

3:35 8.7 0.59

Intensive 65° - Program recommended for heavily soiled crockery, es-

pecially suitable for pans and saucepans.

2:45 17.5 1.60

Sense® 50-60°- For normally soiled dishes with dried food residues. Sens-

es the level of soiling on the dishes and adjusts the program accordingly.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

Fast Wash&Dry 50°

- Normally soiled crockery. Everyday cycle, that en-

sures optimal cleaning and drying performance in shorter time.

1:25 11.5 1.10

Crystals 45° - Program for delicate items, which are more sensitive to

high temperatures, for example glasses and cups.

1:40 12.0 1.20

Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes

with no dried food residues. Without drying.

0:30 9.0 0.50

Silent

50° - Suitable for night-time operation of the appliance. With the

lowest noise.

3:30 16.0 1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:50 12.0 1.30

Prewash - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

- -

0:10 4.5 0.01

8. Multizone indicator

lights

9. Multizone button

10. Delay button

11. START/Pause button

with indicator light /

Tablet (Tab)

CONTROL PANEL

FIRST TIME USE

More information in the Daily Reference Guide on website.

PROGRAMS TABLE

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address:

dw_test_support@europeanappliances.com

Quick Guide

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the

dishwasher and reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it

After having carried out the verication and cleaning, turn o and turn

on the dishwasher and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: 15 and

On/O LED is blinking

rapidly

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLA-

TION).Check for siphoning into home sewage system, install air admit-

tance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Detergent leaks.

Depends on the liquid detergent used and can be

emphasized in case of delay option is activated.

Small leaks will not cause machine malfunction and can be avoided by

changing liquid detergent type or using tablets.

TROUBLESHOOTING

Please scan the QR code on your product in order to have more detailed information.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent.

Bydefault the appliance washes dishes in all racks.

OPERATION INDICATOR -

A LED light projected on the oor indicates

that the dishwasher is working.

One of the following operating modes can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

NaturalDry

is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furniture.

LOADING THE RACKS

CAPACITY: 10 standard place-settings

UPPER RACK

(loading example

for the upper rack

Load delicate and light

dishes: glasses, cups, sa-

ucers, low salad bowls.

The upper rack has tip-

up supports which can

be used in a vertical

position when arrang-

ing tea/ dessert saucers

or in a lower position

to load bowls and food

containers.

FOLDABLE

FLAPS WITH

ADJUSTABLE

SITION

LOWER RACK

(loading example

for the lower rack)

For pots, lids, plates, salad

bowls, cutlery etc. Large

plates and lids should ide-

ally be placed at the sides

to avoid interferences with

the spray arm.

The lower rack has tip-up

supports which can be

used in a vertical position

when arranging plates or

in a horizontal position

(lower) to load pans and

salad bowls easily

CUTLERY BASKET

The basket is equipped

with top grilles for im-

proved cutlery arrange-

ment. The cutlery basket

should be positioned

only at the front of the

lower rack.

Knives and other

utensils with sharp edges must be

placed in the cutlery basket with the

points facing downwards or they must

be positioned horizontally in the tip-

up compartments on the upper rack.

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1 2 3

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in

aclockwise direction.

The lower spray arm may be

removed by pulling it upwards.

CARE AND MAINTENANCE
