ENQuick Guide

CONTROL PANEL

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid

dispenser A should be lled when the RINSE AID

REFILL indicator light in the control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

1 2 3 4 5 6 7 8 9 10

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

8. Power Clean® indicator light

9. Power Clean® button

10. Delay button

11. START/Pause button with indicator light /

Tablet (Tab)

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

Program

Programs description

Drying

phase

Natural

Dry

Available

options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that for

this use, it is the most ecient programme in terms of its combined ener-

gy and water consumption, and that it is used to assess compliance with

the EU Ecodesign legislation.

3:35

8.7 0.63

Intensive 65° - Program recommended for heavily soiled crockery, espe-

cially suitable for pans and saucepans (not to be used for delicate items).

2:45 17.5 1.60

Sense® 50-60°- For normally soiled dishes with dried food residues.

Senses the level of soiling on the dishes and adjusts the program accord-

ingly.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

Fast Wash&Dry 50°

- Normally soiled crockery. Everyday cycle, that ensures

optimal cleaning and drying performance in shorter time.

1:25 11.5 1.10

Half Load 55° - Ideal for washing a half load of lightly or normally soiled

crockery.

1:20 11.0 1.00

Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes

with no dried food residues. Without drying.

0:30 9.0 0.50

Silent

50° - Suitable for night-time operation of the appliance. With the

lowest noise.

3:30 16.0 1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:50 12.0 1.30

Prewash - Use to refresh crockery planned to be washed later.

No detergent to be used with this program.

- -

0:10

4.5 0.01

PROGRAMS TABLE

FIRST TIME USE

More information in the Daily Reference Guide on website.

Quick Guide

CLEANING AND MAINTENANCE

More information in the Daily Reference Guide on website.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1 2 3

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

CUTLERY RACK

(loading

example for the

cutlery rack)

The third rack

was designed

to house the

cutlery.

UPPER RACK

(loading

example for the

upper rack)

Load delicate and light

dishes: glasses, cups, sau-

cers, low salad bowls.

The upper rack has tip-up

supports which can be

used in a vertical position

when arranging tea/ des-

sert saucers or in a lower

position to load bowls

and food containers.

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

(loading

example for the

lower rack)

For pots, lids, plates, salad bowls,

cutlery etc. Large plates and lids

should ideally be placed at the

sides to avoid interferences with

the spray arm.

The lower rack has tip-up supports

which can be used in a vertical

position when arranging plates or

in a horizontal position (lower) to

load pans and salad bowls easily.

POWER CLEAN®

Power Clean® uses the special water jets in the rear of cavity to wash

more intensively the high dirty items. The lower rack has a Space

Zone, a special pull-out support in the rear of the rack that can be

used to support frying pans or baking pans in upright position, thus

taking up less space. Placing the pots/casseroles faced to the Power

Clean® component please activate the POWER CLEAN on the panel.

LOADING THE RACKS

CAPACITY: 11 standard place-settings

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address:

dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specic area. This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPTIONS AND FUNCTIONS
