Quick Guide

SETTING MENU

1. Switch on the appliance by pressing the ON-OFF button.

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „h”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value and return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press ON-OFF or wait 30 seconds to exit the menu.

LETTER

SETTING

VALUES

(Default - in bold)*

Cycle Counter - number of washing cycles

carried out by the dishwasher.

Eg. 25 cycles: 25;

Eg. 13.947 cycles:

13_947

(scrolling

for 3 times)

Water Hardness Level

(see “SETTING THE WATER HARDNESS”

and “WATER HARDNESS TABLE”)

1 | 2 | 3 | 4 | 5

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

NaturalDry

(see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings - press START/Pause to re-

store to the factory default all the values of the

settings included in the settings menu.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

The salt reservoir is located in the lower part of the dishwasher (under the

lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the control

panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 0,5 kg); it is not un-

usual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Run aprogram every time as soon as you completed relling the salt

reservoir to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty.

The frequency of regeneration depends on the water hardness level setting

- regeneration takes place once per 4-6 Eco cycles with the water hardness

level set to 3. The regeneration process occurs at the beginning of the cycle

with additional fresh water.

• Single regeneration consumes ~3 L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dis-

penser Ashould be lled when the RINSE AID REFILL

indicator light in the control panel is lit.

1. Open the dispenser B by pressing and pulling up

the tab on the lid.

2. Pour in the rinse aid (max. 110 ml), making sure it

does not overow from the dispenser. If this hap-

pens, clean the spill immediately with adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appli-

ance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening

device C. Introduce the detergent into the dry dis-

penser D only. Place the amount of detergent for

pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser D, there are indica-

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the dispenser and close

the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

CONTROL PANEL

FIRST TIME USE

More information in the Daily Reference Guide on website.

1. ON-OFF/Reset button with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE program button

with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Display

10. Program number and remaining time indicator

11. Power Clean® option button with indicator light

12. Half Load option button with indicator light/ Settings - 3 sec. press

13. Extra Dry option button with indicator light

14. Delay option button with indicator light

15. START/Pause button with indicator light

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.

In order to receive amore complete assistance, please

W11553946 panel 2023-01-17

W11572189 button R 2021-10-01

W11572083 button L 2022-02-15

W11569647 display 2023-02-17

1 2 3 4 5 6 7 8 9 10

11 12 13

3 sec.

65°

3 4 5 6 7 8 9 10

50 °

Eco

65°

55°

50°

45°

65°

SELF CLEAN

Quick Guide

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

PROGRAMS TABLE

Program Programs description

Drying

phase

NaturalDry

Available options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined

energy and water consumption, and that it is used to assess compli-

ance with the EU Ecodesign legislation.

3:30 9.5 0.76

Auto Intensive 65° - Automatic program for

heavily soiled dishes and pans.

Senses the level of soil-

ing on the dishes and

adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration

is updated.

2:25-3:10 17.0-25,0 1.30-1.70

Auto Mixed 55° - Automatic program for nor-

mally soiled dishes with dried food residues.

1:20-3:20 7.5-20.5 0.75-1.20

Auto Fast 50° - Automatic program for nor-

mally and lightly soiled dishes. The everyday

cycle that ensures optimal cleaning and dry-

ing performance in a shorter time.

1:00-1:50 8.0-16.0 0.70-1.10

Rapid 45° - Program is recommended for limited amount of lightly-soiled

dishes with no dried food residues. Does not include the drying phase.

0:30-0:40 10.5-15.0 0.55-0.65

Crystals 45° - Program for delicate items, which are more sensitive to

high temperatures, for example, glasses and cups.

1:40-1:50 12.5-17.0 0.95-1.20

Silent 55° - Suitable for night-time operation of the appliance. Ensures

optimal cleaning and drying performance with the lowest noise emission.

3:50-4:10 10.5-14.5 0.80-1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:55-2:10 12.0-19.0 1.40-1.80

Prewash - Used to refresh crockery planned to be washed later. Node-

tergent is to be used with this program.

0:12 4.5 0.10

P10

Self Clean 65° - Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY us-

ing specic detergents designed for dishwasher maintenance.

1:15 12.7 1.10

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between 0:30 and 24 hours.

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is aconvection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying perfor-

mance every day. Door opens at the temperature that is safe to your kitch-

en furniture. As additional steam protection, special designed protection

foil is added together with the dishwasher.

SENSING - When the sensor is detecting the soil level an animation

appears in the display (around 20 min.) and the cycle duration is

updated. SENSING is for the level of soiling on the dishes and is

present for all cycles (excepting Eco) adjusting the program accordingly.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

DESCALE – Alarm - Limescale accumulation was detected on the

internal components of the appliance. Check if the Water Hardness

Setting is at the correct value and salt is present in the salt container (see

FIRST TIME USE), then use a descaling product (WPro brand is recommended)

with Self-Clean program. After a successful descaling, the icon will stop

being displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and «dES» alarm will appear on the

display. If still no action is taken, the appliance will only allow a certain

number of cycles to be started (indicated during «dES» alarm display) and

then will be BLOCKED to prevent component damage, with only the Self-

Clean program available. Performing a full descaling will unblock the

product. In the case of extremely high amounts of limescale, descaling may

have to be performed twice to be ecient..

OPTIONS AND FUNCTIONS

Please scan the QR code on your product in order to have more detailed information.

FAVOURITE PROGRAM  The FAVOURITE program may be saved and

will be easily accessible. Find the program using PREVIOUS/NEXT, and

then press the FAVOURITE program button for 3 seconds..

CYCLE COUNTER - This feature shows the number of cycles the

dishwasher has performed.

For the number of cycles from 0-999, a xed number will be displayed.

Example for 25 cycles.

When the cycle number is higher than 1000, the number will scroll in

the display. The “_” represents the “

”, as for instance: 1.000 = 1_000,

13.947= 13_947 (the number will scroll for 3 times).

Example for

13.947 cycles:

After the cycle visualization, the display will return to visualize

„ ”

NOTE: The dishwasher may have already performed about 30 cycles.

This is due to the extended quality process carried out during

production. It guarantees higher product quality.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WH7IPC15BM60

Har du brug for hjælp?

Hvis du har brug for hjælp til Whirlpool WH7IPC15BM60 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Opvaskemaskine Whirlpool Manualer

Whirlpool WH7IPC15BM60 Manual

30 August 2025

Whirlpool W7U HS41 X Manual

28 August 2025

Whirlpool WIC 3C33 PFE Manual

28 August 2025

Whirlpool W0B D851A X Manual

28 August 2025

Whirlpool W7F HS51 Manual

28 August 2025

Whirlpool WFO 3T133 PF X Manual

28 August 2025

Whirlpool W3F D634 X Manual

28 August 2025

Whirlpool W0I D751A X Manual

28 August 2025

Whirlpool WH7IPA15BM6L0 Manual

28 August 2025

Whirlpool WH6IA10BS7L0 Manual

27 August 2025

Opvaskemaskine Manualer

Nyeste Opvaskemaskine Manualer

Privileg RUO 3T133 A F X Manual

31 August 2025

Privileg P2F HD624 A Manual

31 August 2025

Gram OM 6020-90 Manual

31 August 2025

Edesa EDW-6230 X Manual

31 August 2025

Exquisit GSP8314-030DB Manual

31 August 2025

Bosch SMS4ITW00X Manual

31 August 2025

Tisira TDW14X Manual

31 August 2025

Rangemaster RDW6012D22 Manual

31 August 2025

Hoover HDIH 2D949-80 Manual

31 August 2025

Candy CF 3C7L1S Manual

31 August 2025
