Side 1/32
EN
Quick Guide
1
4 5 6 7 8 9 10 13 14 1511 12 16 17 18 191 2 3 20 21 22
1. ON-OFF/Reset button with indicator light
2. Eco program button with indicator light
3. Auto Intensive program button with indicator light
4. Auto Mixed program button with indicator light
5. Auto Fast program button with indicator light
6. Rapid program button with indicator light
7. Crystals program button with indicator light/ Self-Clean program -
3sec. press
8. Prewash program button with indicator light
9. Salt reservoir empty indicator light
10. Rinse Aid reservoir empty indicator light
11. Display
12. Program number and remaining time indicator
13. Closed water tap indicator light
14. DESCALE indicator light
15. Power Clean® option button with indicator light
16. Half Load option button with indicator light
17. Extra Dry option button with indicator light/ Settings - 3 sec. press
18. Silent option button with indicator light
19. Sani Rinse option button with indicator light
20. Turbo option button with indicator light
21. Delay option button with indicator light
22. START/Pause button with indicator light
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF button.
2. Hold the Settings (Extra Dry ) button for 3 seconds, until you hear
abeep and the display shows „SEt”.
3. After one second the rst available setting (letter „ ”) will be displayed.
4. Press Prewash prograam / Power Clean® option buttons to scroll
through the list of available settings (see table below), then press START/
Pause to view or change the value of currently selected setting.
5. Press Prewash program / Power Clean® option buttons to
change the value, then press START/Pause to save the new value.
6. To change another setting, repeat points 2 and 5.
7. Press ON-OFF or wait 30 seconds to exit the menu.
LETTER
SETTING
VALUES
(Default - in bold)*
Cycle Counter - number of washing cycles
carried out by the dishwasher.
Eg. 25 cycles: 25;
Eg. 13.947 cycles:
13_947
(scrolling
for 3 times)
Water Hardness Level (see “SETTING THE WA-
TER HARDNESS” and “WATER HARDNESS TABLE”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “ADJUSTING THE DOSAGE OF RINSE AID”)
0 | 1 | 2 | 3 | 4 | 5
NaturalDry (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Time on the oor (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Sound
“1” = On, “0” = O
1 | 0
Internal Lights (see “OPTIONS AND
FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Factory Settings - press START/Pause to re-
store to the factory default all the values of the
settings included in the settings menu.
-
*) The default value does not apply to the Cycle Counter.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on
the dishes and on the machine’s functional components.
The salt reservoir is located in the lower part of the dish-
washer (under the lower rack on the left side).
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
• Salt must be lled when the SALT REFILL indicator light on the control
panel is lit.
1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir right up to its
edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.
3. Only the rst time you do this: ll the salt reservoir with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Run aprogram every time as soon as you completed relling the salt
reservoir to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
ciency. This system regenerates itself with salt, therefore it is required
to rell the salt container when empty.
The frequency of regeneration depends on the water hardness level setting
- regeneration takes place once per 4-6 Eco cycles with the water hardness
level set to 3. During runs with regeneration, additional water manage-
ment system ll will happen. The regeneration and water management
process occurs at the beginning of the cycle with additional fresh water.
• Single regeneration consumes ~7.5 L of water;
• Takes up to 15 additional minutes for the cycle;
• Consumes below 0.065kWh of energy.
A
B
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dis-
penser Ashould be lled when the RINSE AID REFILL
indicator light in the control panel is lit.
1. Open the dispenser B by pressing and pulling up
the tab on the lid.
2. Pour in the rinse aid (max. 110 ml), making sure it
does not overow from the dispenser. If this hap-
pens, clean the spill immediately with adry cloth.
3. Press the lid down until you hear aclick to close it.
NEVER pour the rinse aid directly into the appli-
ance tub.
D
C
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening
device C. Introduce the detergent into the dry dis-
penser D only. Place the amount of detergent for
pre-washing directly inside the tub.
1. When measuring out the detergent refer to the
mentioned earlier information to add the proper
quantity. Inside the dispenser D, there are indications to help the deter-
gent dosing.
2. Remove detergent residues from the edges of the dispenser and close
the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing
device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program. Usage of detergent not designed for dishwashers
may cause malfunction or damage to the appliance.
CONTROL PANEL
FIRST TIME USE
More information in the Daily Reference Guide on website.
THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.whirlpool.eu/register
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
1
3
2
1. Delay Time on the oor - indicator of the time left
to the start of the cycle, when the Delay option is set
2. Salt reservoir empty - indicator light on the oor
3. Remaining Time on the oor - indicator of the time
left to the end of the cycle
DISPLAY ON THE FLOOR
EN
Quick Guide
2
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration by up to 20 min.
Program
Programs description
Drying
phase
NaturalDry
Available
options
*)
Duration
of wash
program
(h: min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
Eco 50°- program is suitable to clean normally soiled ta-
bleware, that for this use, it is the most ecient program
in terms of its combined energy and water consump-
tion, and that it is used to assess compliance with the EU
Ecodesign legislation.
5:45 9.5 0.50
Auto Intensive 65° - Automatic
program for heavily soiled dishes
and pans.
Senses the level of
soiling on the dish-
es and adjusts the
program according-
ly. When the sensor
is detecting the soil
level an animation
appears in the dis-
play and the cycle
duration is updated.
2:25 - 3:10 15.5 - 24.5 1.30 - 1.70
Auto Mixed 55° - Automatic pro-
gram for normally soiled dishes
with dried food residues.
1:20 - 3:00 7.5 - 19.5 0.75 - 1.20
Auto Fast 50° - Automatic program
for normally and lightly soiled dish-
es. The everyday cycle that ensures
optimal cleaning and drying perfor-
mance in shorter time.
1:00 - 1:50 7.5 - 15.5 0.70 - 1.10
Rapid 45° - Program is recommended for limited amount
of lightly-soiled dishes with no dried food residues. Does
not include the drying phase.
-
0:30 - 0:40 10.0 - 12.0 0.55 - 0.65
Crystals 45° - Program for delicate items, which are more
sensitive to high temperatures, for example glasses and cups.
1:40 - 1:50 12.5 - 16.5 0.95 - 1.20
Prewash - Use to refresh crockery planned to be washed
later. No detergent is to be used with this program.
-
0:12 4.5 0.10
Self-Clean 65° -
Program to be used to perform mainte-
nance of the dishwasher and water management system,
to be carried out only when the dishwasher is EMPTY using
specic detergents designed for dishwasher maintenance.
-
-
1:40 11.0 1.10
POWER CLEAN® - Thanks to the additional power jets this option
provides a more intensive and powerful wash in the lower rack, in the
specific area. This option is recommended for washing pots and casseroles
(Please refer to the Power Clean® loading section.
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allow improved drying. The EXTRA DRY option
results in the lengthening of the wash cycle.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a program has been started.
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed.
NaturalDry - It is aconvection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying perfor-
mance every day. Door opens at the temperature that is safe to your kitch-
en furniture, thus door will not be opened when the option of SANI RINSE
is on. As additional steam protection, special designed protection foil is
added together with the dishwasher.
SILENT - Suitable for night-time operation of the appliance. This option
can be used to limit noise emission during wash phases. It will increase
cycle time depending on base cycle selection.
SANI RINSE - This option can be used to sanitize washed dishes. It will
increase the nal rinse temperature and add antibacterial wash to the
selected program. Ideal to clean crockery and feeding bottles. The dishwasher
door must be kept shut for the entire duration of the program in order to
guarantee reduction of germs. WARNING: the crockery and plates could
be extremely hot at the end of the cycle.
TURBO - Thanks to the Turbo option you can reduce time up to 40%
depending on the selected based program. Energy and water
consumption are increased.
HALF LOAD - If there are not many dishes to be washed, HALF LOAD is
used to save water, electricity or time, depending on the selected
program. Remember to halve the amount of detergent.
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator
lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-
idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
DESCALE – Alarm - Limescale accumulation was detected on the
internal components of the appliance. Check if the Water Hardness
Setting is at the correct value and salt is present in the salt container (see
FIRST TIME USE), then use a descaling product (WPro brand is recommended)
with Self-Clean program. After a successful descaling, the icon will stop
being displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain
number of cycles to be started (indicated during «dES» alarm display)
and then will be BLOCKED to prevent component damage, with only
the Self-Clean program available. Performing a full descaling will unblock
the product. In the case of extremely high amounts of limescale, descaling
may have to be performed twice to be ecient.
PROGRAMS TABLE
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
TIME ON THE FLOOR - A LED light projected on the oor indicates the
time left to the end of the cycle. The light goes o every time the door
is opened. The light goes o at the end of a cycle.This feature is active
by default, but it is possible to deactivate it in the “SETTINGS MENU”.

Produkt Specifikationer

Mærke: Whirlpool
Kategori: Opvaskemaskine
Model: WH8IA115B2M3TUS0

Har du brug for hjælp?

Hvis du har brug for hjælp til Whirlpool WH8IA115B2M3TUS0 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Opvaskemaskine Whirlpool Manualer

Whirlpool

Whirlpool WH4FD11CS7A0X Manual

18 Juli 2025
Whirlpool

Whirlpool WH8IA115B2M3TUS0 Manual

18 Juli 2025
Whirlpool

Whirlpool ADFS2524RW Manual

15 Juli 2025
Whirlpool

Whirlpool ADFS2524RS Manual

15 Juli 2025
Whirlpool

Whirlpool ADPU 8783 A++ PC TR 6S IX Manual

14 Juli 2025
Whirlpool

Whirlpool WH7IA15AM3L Manual

10 Juli 2025
Whirlpool

Whirlpool WH7IA15AM6L0 Manual

9 Juli 2025
Whirlpool

Whirlpool WH7PA15AM60 Manual

30 Juni 2025
Whirlpool

Whirlpool WH7PC15B4M60 Manual

30 Juni 2025
Whirlpool

Whirlpool WH3UC10BS7A0X Manual

29 Juni 2025

Opvaskemaskine Manualer

Nyeste Opvaskemaskine Manualer

Privileg

Privileg P0I ECO D551 S Manual

18 Juli 2025
Privileg

Privileg P0I ECO D541 S Manual

18 Juli 2025
Bosch

Bosch SGV43C53UC Manual

18 Juli 2025
Bellini

Bellini BDW612X-F Manual

18 Juli 2025
Bosch

Bosch SGS46M52EE Manual

17 Juli 2025
Hisense

Hisense HV693A60UVADUK Manual

17 Juli 2025
Haier

Haier XI1C2TB4LPCFB Manual

17 Juli 2025
Bosch

Bosch SGS44E42 Manual

17 Juli 2025
Bosch

Bosch SGD45M22 Manual

17 Juli 2025
Hisense

Hisense HV673A61UK Manual

17 Juli 2025
