Side 1/40

ENQuick Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

CONTROL PANEL

FIRST TIME USE

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

8. Multizone indicator lights

9. Multizone button

10. Delay button

11. Turbo button with indicator light

12. Power Clean button with indicator light

13. START/Pause button with indicator light /

Tab

Program Programs description

Drying

phase

Natural-

Dry

Available

options

Duration of

wash program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled table-

ware, that for this use, it is the most ecient programme in

terms of its combined energy and water consumption, and

that it is used to assess compliance with the EU Ecodesign

legislation.

3:10 9.5 0.85

Sense® 50°- 60°- For normally soiled dishes with dried

food residues. Senses the level of soiling on the dishes and

adjusts the program accordingly.

1:25 - 3:00 7.0 - 14.0 0.90 - 1.40

Intensive 65° - Program recommended for heavily soiled

crockery, especially suitable for pans and saucepans.

2:50 16.0 1.60

Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle,

that ensures optimal cleaning and drying performance in

shorter time.

1:25 11.5 1.10

Crystals 45° - Program for delicate items, which are more sen-

sitive to high temperatures, for example glasses and cups.

1:40 11.5 1.20

Rapid 30’ 50° - Program to be used for half load of lightly-so-

iled dishes with no dried food residues. Without drying.

- -

0:30 9.0 0.50

Silent 50° - Suitable for night-time operation of the applian-

ce. With the lowest noise.

3:30 15.0 1.15

Prewash - Use to refresh crockery planned to be washed

later. No detergent to be used with this program.

- -

0:12 4.5 0.01

PROGRAMS TABLE

Before using the appliance carefully read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

1 2 3 4 5 6 7 8 9 10

11 12 13

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser A should be lled when the

RINSE AID REFILL indicator light in the

control panel is lit.

NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@whirlpool.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

TURBO - This option can be used to reduce the duration of the main

programs while maintaining the same washing and drying performance levels.

DELAY - The start time of the program may be delayed for a period of

time between 1 and 12 hours.

The DELAY function cannot be set once a wash cycle has been started.

POWER CLEAN - Thanks to the additional power jets this option provides

a more intensive and powerful wash in the lower rack, in the specic area.

This option is recommended for washing pots and casseroles.

TABLET (Tab)- If you use powder or liquid detergent, this option should be off.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

MULTIZONE - If there are not many dishes to be washed, a half loading

may be used in order to save water, electricity and detergent. By default the

appliance washes dishes in all racks.

OPERATION INDICATOR -

A LED light projected on the oor indicates

that the dishwasher is working.

One of the following operating modes can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

Please scan the QR code on your product in order to have more detailed information.

NaturalDry is a convection drying system which automatically opens the

door during/after drying phase to ensure exceptional drying performance

every day. Door opens at the temperature that is safe to your kitchen furni-

ture, thus door will not be opened when the option of TURBO is on.

As additional steam protection, special designed protection foil is added

to-

gether with the dishwasher. To see how to mount protection foil please re-

fer to (INSTALLATION GUIDE).

More information in the Daily Reference Guide on the website.

CLEANING AND MAINTENANCE

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in a

clockwise direction.

The lower spray arm may

be removed by pulling it

upwards.

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product’s identication plate.

The model information can be retrieved using the QR-Code indicated on the energy label. The label also includes the model identi-

er that can be used to consult the https://eprel.ec.europa.eu database portal.

IEC 436

CUTLERY RACK

(loading example for the

cutlery rack)

The third rack was desi-

gned to house the cutlery.

UPPER RACK

(loading example for the

upper rack)

Load delicate and light

dishes: glasses, cups, sa-

ucers, low salad bowls.

Foldable

aps with

adjustable

position

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc.

Large plates and lids should ideally be placed at

the sides to avoid interferences with the spray

arm.

The lower rack has tip-up supports which can

be used in a vertical position when arranging

plates or in a horizontal position (lower) to load

pans and salad bowls easily.

(loading example for the lower rack)

POWER CLEAN

Power Clean uses the special water jets in the rear of cavity to wash more in-

tensively the high dirty items. The lower rack has a Space Zone, a special pull-

-out support in the rear of the rack that can be used to support frying pans or

baking pans in upright position, thus taking up less space.

Placing the pots/casseroles faced to the Power Clean®

component please activate the POWER CLEAN on the

panel.

LOADING THE RACKS

CAPACITY: 14 standard place-settings

400011643461B

02/2023 dk - Xerox Fabriano

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does

not ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is

closed.

Make sure there is water in the water supply or the tap running.

The inlet hose is bent.

Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwa-

sher and reboot.

The sieve in the water inlet hose is clogged;

it is necessary to clean it

After having carried out the verication and cleaning, turn o and turn on the

dishwasher and restart a new program.

Dishwasher nishes

the cycle prematurely.

Display shows: 15

and On/

Off LED is blinking

rapidly

Drain hose positioned too low or siphoning

into home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check

for siphoning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

TROUBLESHOOTING

Please scan the QR code on your product in order to have more detailed information.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WIC 3C33 PFE
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Indbygget skærm:	Ja
Strøm:	13 A
Ledningslængde:	1.3 m
Placering af apparat:	Fuldt indbygget
Installationsrum dybde:	560 mm
Støjniveau:	43 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	8
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Sølv
Vandforbrug pr. cyklus:	9.5 L
Antal kuverter:	14 kuverter
Cyklustid:	190 min.
Forsinket start (maks.):	12 t
Opvaskeprogrammer:	Eco, Glass/delicate, Intensive 65°C, Pre-wash, Quick, Silent
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	0.848 kWh
Energieffektivitetsskala:	A til G
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	85 kWh
Temperatur (maks):	60 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Aftagelig overside:	Ingen
