Side 1/8

DAILY REFERENCE

GUIDE

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

www.whirlpool.eu/register

You can download the Safety Instructions and the Use

and Care Guide, by visiting our website

http://docs.whirlpool.eu and following the Instructions

on the back of this booklet.

Before using the appliance carefully read Health and Safety guide.

PRODUCT DESCRIPTION

APPLIANCE

1.Upper rack

2.Foldable flaps

3.Upper rack height adjuster

4.Upper spray arm

5.Lower rack

6.Cutlery basket

7.Lower spray arm

8.Filter Assembly

9.Salt reservoir

10.Detergent and Rinse Aid dispensers

11.Rating plate

12.Control panel

0000 000 00000

Service:

CONTROL PANEL

1. On-Off/Reset button with indicator light

2. Program selection button

3. Salt refill indicator light

4. Rinse Aid refill indicator light

5. Program indicator lights

1 2 3 4 5

FIRST TIME USE

SALT, RINSE AID AND DETERGENT

ADVICE REGARDING THE FIRST TIME USE

After installation, remove the stoppers from the racks and the retaining

elastic elements from the upper rack.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and

on the machine’s functional components.

• It is important that the salt reservoir be never empty (except when

the water hardness is set to - 1 “Soft”).

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher (see

PROGRAMS DESCRIPTION) and should be filled when the SALT REFILL

indicator light in the control panel is lit.

1.Remove the lower rack and unscrew the

reservoir cap (anticlockwise).

2.Position the funnel

(see figure)

and fill the salt

reservoir right up to its edge (approximately 1 kg);

it is not unusual for a little water to leak out.

3.Remove the funnel and wipe any salt residue

away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get

into the container during the wash program (this could damage the

water softener beyond repair).

Whenever you need to add salt, we recommend carrying out the

procedure before the washing cycle is started.

SETTING THE WATER HARDNESS

To allow the water softener to work in a perfect way, it is essential that

the water hardness setting is based on the actual water hardness in

your house. This information can be obtained from your local water

supplier.

The factory setting is for average (3) water hardness.

1. Switch on the appliance by pressing the

ON/OFF

button.

2. Switch off the appliance by pressing the

ON/OFF

button.

3. Hold down button

for 5 seconds, until you hear a beep.

4. Switch on the appliance by pressing the

ON/OFF

button.

5. The program indicator light of the current set level flashes.

6. Press button

to select the desired hardness level

(see Water

Hardness Table).

7. Switch off the appliance by pressing the

ON/OFF

button.

Setting is complete!

As soon as this procedure is complete, run a program without loading.

Only use salt that has been specifically designed for dishwashers.

After the salt has been poured into the machine, the SALT REFILL

indicator light switches off.

If the salt container is not filled, the water softener and the heating

element may be damaged as a result (except when the water

hardness is set to - 1 “Soft”).

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dispenser A should be

filled when the RINSE AID REFILL indicator light on the panel is lit.

1. Open the dispenser

by pressing and pulling up the tab on the lid.

2. Carefully introduce the rinse aid as far as the maximum (110 ml)

reference notch of the filling space - avoid spilling it. If this happens,

clean the spill immediately with a dry cloth.

3. Press the lid down until you hear a click to close it.

NEVER pour the rinse aid directly into the tub.

ADJUSTING THE DOSAGE OF RINSE AID

If you are not completely satisfied with the drying results, you can ad-

just the quantity of rinse aid used.

• Switch the dishwasher on using the ON/OFF button.

• Switch it off using the ON/OFF button.

• Press button P three times - a beep will be heard.

• Switch it on using the ON/OFF button.

• The current selection level number and rinse aid indicator light

flash.

• Press button P to select the level of rinse aid quantity to be

supplied.

• Switch it off using the ON/OFF button

Setting is complete!

If the rinse aid level is set to ZERO (ECO), no rinse aid will be supplied.

The LOW RINSE AID indicator light will not be lit if you run out of rinse

aid.

A maximum of 4 levels can be set according to the dishwasher model.

The factory setting is for a medium level.

• If you see bluish streaks on the dishes, set a low number (1-2).

• If there are drops of water or limescale marks on the dishes, set a

high number (3-4).

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the

opening device A

Introduce the

detergent into the dry dispenser B only.

Place the amount of detergent for pre-

washing directly inside the tub.

1.When measuring out the detergent refer

to the

(see PROGRAMS TABLE)

to add the

proper quantity. Compartment

comprises

a level showing the maximum quantity of

liquid or powder detergent that can be

added to each cycle.

2. Remove detergent residues from the edges of the dispenser and close

the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time according to

the program. If all-in-one detergents are used, we recommend using the

TABLET

button, because it adjusts the program so that the best washing and

drying results are always achieved.

Water Hardness Table Salt

needed

Level °dH

German degrees

°fH

French degrees

1 Soft 0 - 6 0 - 10 NO

2 Medium 7 - 11 11 - 20

YES

3 Average 12 - 17 21 - 30

4 Hard 17 - 34 31 - 60

5 Very hard 35 - 50 61 - 90

MAX

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WIE 2B19
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	570 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Buttons, Sensor
Indbygget skærm:	Ingen
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Pakkedybde:	675 mm
Pakkebredde:	650 mm
Pakkehøjde:	910 mm
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fuldt indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Installationsrum højde:	820 mm
Tilsluttet belastning:	5 W
Støjniveau:	49 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	6
Forsinket start-timer:	Ingen
Justerbare fødder:	Ja
Dør farve:	Ikke anvendelig
Vandforbrug pr. cyklus:	12 L
Bestik rum type:	Kurv
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	13 kuverter
Cyklustid:	190 min.
Opvaskeprogrammer:	Glass/delicate, Intensive, Pre-wash, Quick
Halv belastning:	Ja
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	- kWh
Energieffektivitetsskala:	A til G
Antal temperaturindstillinger:	3
Udøsslange længde:	1.5 m
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	C
Energieffektivitetsklasse:	F
Energiforbrug pr. 100 cyklusser:	104 kWh
Temperatur (maks):	60 °C
Saltindikator:	Ja
Kurves indstillelige placering:	Lower, Upper
Tørresystem:	Statisk
