Side 1/12

ENQuick Guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

CONTROL PANEL

FIRST TIME USE

1. ON-OFF/Reset button with indicator light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time indicator

6. Tablet indicator light

7. Display

8. Multizone indicator lights

9. Multizone button

10. Delay button

11. Turbo button with indicator light

12. Power Clean button with

indicator light

13. START/Pause button with

indicator light / Tab

Before using the appliance carefully read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR

APPLIANCE IN ORDER TO HAVE MORE

DETAILED INFORMATION

1 2 3 4 5 6 7 8 9 10

11 12 13

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into

the container during the wash program (this could damage the water

softener beyond repair).

Whenever you need to add salt, it is mandatory to complete the proce-

dure before the beginning of the washing cycle to avoid corrosion.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser A should be lled when the RINSE

AID REFILL indicator light in the control

panel is lit.

NEVER pour the rinse aid directly into the appliance

tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device C. Introduce the

detergent into the dry dispenser D only. Place the amount of detergent for

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause

malfunction or damage to the appliance.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

Program Programs description

Drying

phase

NaturalDry

Available

options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware,

that for this use, it is the most ecient programme in terms of

its combined energy and water consumption, and that it is used

to assess compliance with the EU Ecodesign legislation.

3:10 9.5 0.85

Sense® 50°- 60°- For normally soiled dishes with dried food

residues. Senses the level of soiling on the dishes and adjusts

the program accordingly.

1:25 - 3:00 7.0 - 14.0 0.90 - 1.40

Intensive 65° - Program recommended for heavily soiled crock-

ery, especially suitable for pans and saucepans.

2:50 16.0 1.60

Mixed 60°- Mixed soil. For normally soiled dishes with dried food

residues.

2:30 16.0 1.30

Fast Wash&Dry 50° - Normally soiled crockery. Everyday cy-

cle, that ensures optimal cleaning and drying performance in

shorter time.

1:25 11.5 1.10

Crystals 45° - Program for delicate items, which are more sensi-

tive to high temperatures, for example glasses and cups.

1:40 11.5 1.20

Rapid 30’ 50° - Program to be used for half load of lightly-soiled

dishes with no dried food residues. Without drying.

- -

0:30 9.0 0.50

Silent 50° - Suitable for night-time operation of the appliance.

With the lowest noise.

3:30 15.0 1.15

Sanitizing 65°- Normally or heavily soiled crockery, with addi-

tional antibacterial wash. Can be used to perform maintenance

of the dishwasher

1:40 10.0 1.30

PROGRAMS TABLE

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WIS 7030 PEL
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	598 mm
Dybde:	555 mm
Højde:	820 mm
Vægt:	35500 g
Kontroltype:	Knapper
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.3 m
Pakkevægt:	37500 g
Strømforbrug (slukket):	0 W
Placering af apparat:	Fuldt indbygget
Installationsrum bredde:	600 mm
Installationsrum dybde:	560 mm
Tilsluttet belastning:	1900 W
Støjniveau:	43 dB
Tilløbsslange, længde:	1.55 m
Antal vaskeprogrammer:	11
Forsinket start-timer:	Ja
Justerbare fødder:	Ja
Dør farve:	Rustfrit stål
Balje materiale:	Rustfrit stål
Vandforbrug pr. cyklus:	9.5 L
Farve på kontrolpanel:	Rustfrit stål
Antal kuverter:	14 kuverter
Cyklustid:	190 min.
Forsinket start (maks.):	12 t
Indikator for afspændingsmiddel:	Ja
Energiforbrug pr. cyklus:	9.5 kWh
Energieffektivitetsskala:	A til G
Installationsrum højde (min.):	820 mm
Installationsrum højde (maks.):	900 mm
Udøsslange længde:	1.5 m
Produktstørrelse:	Fuld størrelse (60 cm)
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	B
Energieffektivitetsklasse:	D
Energiforbrug pr. 100 cyklusser:	85 kWh
Temperatur (maks):	60 °C
Saltindikator:	Ja
Øverste kurv indstillelig højde:	Ja
Strømforbrug (fortsat-tændt):	0.5 W
Tørresystem:	Naturlig
Strømstiktype:	Type F (CEE 7/4)
Lydalarm:	Ja
Automatiske programmer:	Ja
Quick Time-funktion:	Ja
