QUICK START GUIDE

6th Sense

(Sixth Sense Function)

This activates automatically to signal that the appliance is working to

reach optimal storage conditions.

Water filter (where provided)

The colour of the symbol indicates the condition of

the filter.

Green: new filter

Blue: filter in good condition

Red (fixed): filter running out

Red (blinking): filter needs replacing.

After replacing the filter, press the "Reset

filter/alarm" button until the symbol becomes green.

For Europe only

00800-40088400 - www.whirlpool.eu/myfridge

Freezer compartment temperature

Press the "Freezer temp" button to change the

temperature setting..

Refrigerator compartment temperature

Press the "Fridge temp" button to change the

temperature setting.

Anti-bacterial filter

(where provided)

Change the filter when the symbol blinks.

After replacing the filter, press the "Reset

filter/alarm" button until the symbol remains

permanently on.

For Europe only

00800-40088400 - www.whirlpool.eu/myfridge

Freezer compartment door open

Malfunction Alarm

See section "What to do if...".

Filter Alarm Reset

(Acoustic alarm mute

button)

Press the "Reset

Filter/Alarm" button to

stop the acoustic alarm.

Blackout Alarm

See section "What to do if...".

Fast freezing

(Fast Freeze Function)

To be activated several hours before the food to be

frozen is placed in the freezer compartment (24

hours before freezing large quantities of food).

To activate this function, press the "Fast freezing"

button: the symbol will appear on the display.

The function disables automatically after 24 hours or

can be switched off manually by pressing the button

again.

Ice Mode

(Type of ice)

Press the "Ice mode" button to select the desired

type of ice and to enable/disable the automatic ice

maker.

- = ice cubes

- = crushed ice

- no symbol displayed = automatic ice maker

disabled

Important: if the appliance is not connected to the

water supply, the automatic ice maker must be

disabled.

Water

Water delivery is always available and the symbol is

always displayed.

Vacation Mode

(Vacation Function)

This function can be used during extended absences.

Press the "Vacation mode" button to enable/disable

the function. When the function is enabled, the

related symbol lights up and the refrigerator

compartment becomes much less cold. After

activating this function, remove all perishable

foodstuffs from the compartment and leave the door

closed: the refrigerator will maintain the right

temperature to prevent odours from forming.

The freezer compartment remains enabled: it is

therefore possible to continue to use it as usual.

Water dispenser extraction

(on some models only)

The water dispenser features a swivel spout for easy

filling of bottles, jugs and other large receptacles.

Extract the spout with a simple click (press and

release) as shown in figure A. To return the spout to

the initial position, manually rotate the swivel as

shown in figure B.

Refrigerator compartment door open

Child Lock

(Child Safety)

To lock/unlock the buttons on the control panel and the water/ice

dispenser, press the "Reset filter/alarm" and "Vacation mode"

buttons at the same time until the symbol is displayed and the acoustic

signal sounds.

Eco mode

This function enables you to save energy. To enable/disable the function,

press the "Reset filter/alarm" and "Ice mode" buttons at the same

time for 5 seconds until the acoustic signal sounds. When the function is

enabled, the display only lights up when you use the appliance or the

control panel, otherwise only the symbol is shown.

Remember that this operation does not disconnect the appliance from

the power supply.

Freezer Compartment

P. Automatic ice maker

Q. Inside light

R. Glass shelves / racks (depending on the model)

S. Drawer / top basket (depending on the model)

T. Drawer / bottom basket (depending on the model)

U. Ice bucket

V. Door trays

Refrigerator Compartment

A. Inside light

B. Shelves

C. Shelf - drawer lid

D. Snack drawer (depending on the model)

E. Crisper drawer

F. Crisper drawer moisture control (where provided)

G. Meat / crisper drawer

H. Meat / crisper drawer temperature control (where

provided)

I. Rating plate

J. Dairy compartment

K. Door trays

L. Fresh control and Nature fresh compartment

(where provided)

M. 2 litre door tray with bottle holder (if supplied)

N. 0.75 litre door tray

O. Water filter (depending on the model)













훽훾

훿

























Specifications, technical data and images may vary

from model to model.

Connect the appliance to the water supply and power

supply (see Installation manual).

Read the user handbook carefully before using the

appliance.

GB I ROBGRUSHSKCZPLFINDKNSGRPENLFD

Figure A Figure B

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	WSC 5555 A+X
Bredde:	911 mm
Dybde:	801 mm
Højde:	1772 mm
Vægt:	112000 g
Produktfarve:	Rustfrit stål
Indbygget skærm:	LCD
Pakkevægt:	116000 g
Årligt energiforbrug:	431 kWh
Placering af apparat:	Fritstående
Støjniveau:	45 dB
Børnesikring:	Ja
Fryser, netto rumindhold:	180 L
Opbevaringstid under strømafbrydelse:	5 t
Klimaklasse:	T
Frostfri system:	Ja
Køleskab antal hylder/kurve:	4
Køleskab, netto rumindhold:	325 L
Total netto kapacitet:	505 L
Stjernebedømmelse:	4*
Hurtig frys funktion:	Ja
Åben dør alarm:	Ja
Energiforbrug:	1.18 kWh/24t
Indbygget fryser:	Ja
Anti-bakteriel funktion:	Ja
