Side 1/6

www.whirlwindusa.com

MCT-7

Multiple Cable Test System

INTRODUCTION:

The MCT-7 Cable Tester is a versatile unit that allows the user to test almost any

pre-made and custom made leads or cables used in a typical audio/visual set up.

Leads fitted with any combination of the following connectors may be checked:

• Male or female XLR

• Speakon (4 pole)

• Stereo or mono 1/4” (6.3 mm) jack

• Stereo or mono 1/8” (3.5 mm) mini jack

• Phono RCA

• BNC

• Midi (180 degrees DIN)

The MCT-7 Cable Tester allows you to test for the following conditions:

• Positive Continuity

• Cross Wiring

• Loose Contact

• Open Circuit

• Leakage Between Wires (up to 10KΩ)

• Short Between Wires

• Short to Ground (female XLR & MIDI)

Please read the following instructions carefully before using the MCT-7 Cable

Tester.

Warning: The leads to be tested must be fully disconnected from any other

equipment or electrical source. Failure to do so could result in electrical shock and

permanent damage to the MCT-7 Cable Tester unit, for which the manufacturer

and suppliers can accept no liability.

The MCT-7 Cable Tester comes fitted with a 9 Volt type battery. Under normal

usage this will allow several hundred hours of operation. We advise that before

commencing testing, you check battery status (See section “Testing and Replacing

Battery “).

TEST PROCEDURE:

The MCT-7 Cable Tester is simple to operate. A schematic diagram of the

connectors and their pin assignments is shown on the front panel of the unit. Light

Emitting Diodes (LEDs) give a clear visual representation of the connections.

YELLOW LEDs 1-5 refer to the pins of connectors on the left side (INPUT) of the

unit. Green LEDs 1-5 refer to the pins of connectors on the right side (OUTPUT) of the

unit.

Checking the status of connections is made using the Pin Selector Switch. Until

you become familiar with the connectors, pin wiring and switch selector positions, you

may wish to refer to the data shown in Table 1.

Table 1

Connector

Pin Assigned Position

Speakon NL4

1 2

-1 1

2 4

-2 3

Phono/RCA

Center

Ring

BNC / Video

Center

Ring

MIDI 5 DIN

1 1

2 2

3 3

4 4

5 5

Jack 3.5mm (1/8”)

Tip 2

Ring 3

Sleeve

Jack 6.3mm (1/4”)

Tip 2

Ring 3

Sleeve

Male or female XLR

1 1

2 2

3 3

1. Plug one end of the lead to be tested into the corresponding connector on the

INPUT (left) side of the unit.
