M-Series Operator’s Manual
Model M2850, 28-Volt 50-Amp Mini-GPU
IMPORTANT DISCLAIMERS & LIABILITY LIMITATIONS
As a condition for use, Audio Authority Corp. authorizes this device for use ONLY by aviation
professionals, such as licensed pilots and maintenance technicians, knowledgeable about the
aircraft’s electrical system and batteries. The concepts, recommendations, and instructions in this
manual are necessarily general and make assumptions that may not apply to your aircraft. Therefore,
incorrect use of this device has the potential to damage the GPU and/or aircraft components.
The device is designed exclusively for aircraft with a 28VDC electrical system, a 24V battery, and a
factory-installed external power receptacle for a 3- pin oval AN2551 plug. (NATO)
It is the operator’s sole responsibility to read completely and fully understand this manual, plus all
available documentation on their aircraft’s electrical system design, to properly determine the
appropriate use of this, or any, external power source. If you cannot do this, do not use this
product. Instead, consult a qualified technician familiar with your specific aircraft type and
configuration before connecting the GPU to your aircraft, or return it to the seller before using.
M- - 2 Series M2850 GPU Manual P/N 752 794 20801, Rev 202
General Description and Application
The M2850 - - y Mini GPU is a specialized switching mode power suppl designed to provide pilots and
aviation maintenance professionals with a portable, affordable source of stable, high current, noise- -free
DC power that replicates the in- Iflight electrical environment. ts rated output is 28- -volts up to 50 amps
(approximately 1500 watts). The GPU’s intended purpose is to energize an aircraft’s main electrical bus
without using the ship’s battery or engine. It will safely provide continuous power for the most delicate
electronics and airframe systems up to its full rated output.
Typical Uses
● power avionics for flight planning, familiarization, and training
● update flight deck database and software
● troubleshooting and maintenance
FRONT PANEL VIEW REAR PANEL VIEW
Special Features
● Color- - – coded, keyed SB 50 type output connection to prevent accidental voltage mismatch
RED . designates 24/28 volt compatibility
● Dual digital output meters for voltage and amperage (load)
● Front panel status indicator LED
● Programmable auto- shutdown timer and dual USB power ports for mobile device charging
● QuietFiltered™ output for interference-free COM radio operation
● Auto protection/recovery from short circuit, reverse polarity, over voltage/load/temperature
Operating Conditions and Limitations
The M2850 is internally fan-cooled and relies on unobstructed ventilation access for proper operation.
The GPU should operate on a clean, hard surface so that debris cannot be ingested. Its design assumes
a dry operating environment. If used outdoors, it is the operator’s responsibility to ensure that the unit is
not exposed to moisture.
The M2850 is designed to provide airframe power only. It is not a battery charger. It does not monitor
the state- -of charge of the aircraft battery. It is not suitable for engine starting.
