M-Series Operator’s Manual
Model M1428-DV, Dual Voltage 14/28-Volt Mini-GPU
IMPORTANT DISCLAIMERS & LIABILITY LIMITATIONS
As a condition for use, Audio Authority Corp. authorizes this device for use ONLY by aviation
professionals, such as licensed pilots and maintenance technicians, knowledgeable about the
aircraft’s electrical system and batteries. The concepts, recommendations, and instructions in this
manual are necessarily general and make assumptions that may not apply to your aircraft. Therefore,
incorrect use of this device has the potential to damage the GPU and/or aircraft components.
The device is designed exclusively for aircraft either and a with a - 14 or 28 VDC electrical system
factory-installed external power receptacle for a 3- -pin oval AN2551 plug. (NATO) If your 14 volt
aircraft is experimental and does not have an external power receptacle, a wiring kit and matching
output cable are available at additional cost. Call our factory for assistance.
It is the operator’s sole responsibility to read completely and fully understand this manual, plus all
available documentation on their aircraft’s electrical system design, to properly determine the
appropriate use of this, or any, external power source. If you cannot do this, do not use this
product. Instead, consult a qualified technician familiar with your specific aircraft type and
configuration before connecting the GPU to your aircraft, or return it to the seller before using.
M- - - 3 2 Series M1428 DV GPU Manual P/N 752 79 , Rev 20220801
General Description and Application
The M1428 Mini- DV - - y GPU is a specialized switching mode power suppl designed to provide pilots and
aviation maintenance professionals with a portable, affordable source of stable, high current, noise- -free
DC power that replicates the in-flight electrical environment. It contains discrete outputs for either 14 or
28- volts DC, selectable by a front panel switch. It only provides one output voltage switchat a time, -
selected and indicated by the front panel voltmeter display. The GPU’s intended purpose is to energize
an aircraft’s main electrical bus without using the ship’s battery or engine. It will safely provide
continuous power for the most delicate electronics and airframe systems up to its full rated output.
Typical Uses
● power avionics for flight planning, familiarization, and training
● update flight deck database and software
● troubleshooting and maintenance
FRONT PANEL VIEW REAR PANEL VIEW
Special Features
● Color- - . coded, keyed SB 50 type output connection to prevent accidental voltage mismatch
( YELLOW designates 12/14 volt compatibility, RED designates 24/28 volt compatibility)
● Dual digital output meters for voltage and amperage (load)
● Front panel status indicator LED
● Programmable auto- shutdown timer and dual USB power ports for mobile device charging
● QuietFiltered™ output for interference-free COM radio operation
● Auto protection/recovery from short circuit, reverse polarity, over voltage/load/temperature
Operating Conditions and Limitations
The M1428- -DV is internally fan cooled and relies on unobstructed ventilation access for proper
operation. The GPU should operate on a clean, hard surface so that debris cannot be ingested. Its
design assumes a dry operating environment. If used outdoors, it is the operator’s responsibility to
ensure that the unit is not exposed to moisture.
The M1428- DV is designed to provide airframe power only. It is not a battery charger. It does not
monitor the state- -of charge of the aircraft battery. It is not suitable for engine starting.
