Winix Luftrenser A230

Læs gratis den danske manual til Winix A230 (2 sider) i kategorien Luftrenser. Denne vejledning er vurderet som hjælpsom af 18 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 9.5 anmeldelser. Har du et spørgsmål om Winix A230, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

WHERE TO USE

12~18 in

Allow 12 ~ 18 in. of space between TVs, radios, and other electronics

Electromagnetic interference from certain electronics may cause

product malfunction.

Place indoors away from direct sunlight

Direct exposure may cause product malfunction or failure.

Only place on hard, flat surfaces

Flimsy or slanted surfaces may result in abnormal noise and

vibrations.

Allow 12 ~ 18 in. from walls

For maximum air flow.

FRONT BACK

PACKAGE CONTENTS

Smart Sensor

Air Outlet Vent

Power Plug

Control Panel

Front Panel

Unit

360º All-in-One

True HEPA Filter

User

Manual

MODEL PART DIAGRAM

01. Filter Replacement Indicator

LED light indicates when it is time to change the

filter.

02. Filter Reset Button

After replacing the 360º All-in-One True HEPA

Filter, use a small object such as a paper clip, to

press and hold the Filter Reset Button for at least

5 seconds until the Filter Replacement Indicator

turns off.

03. Auto Mode Button

The unit will default to Auto with PlasmaWave

enabled when first powered on.

• Auto Mode automatically adjusts fan speeds

according to your indoor air quality. The fan

speed will adjust to low when air quality is good,

medium when fair, and to high when poor.

04. Air Quality Indicator

Color coded LED light indicates one of three levels

of Air Quality:

Red (poor), Amber (fair), and Blue (good).

05. Sleep Mode Button

When Sleep Mode is activated, the Air Quality

Indicator LED light is disabled.

• Fan speed will automatically set to minimum

speed (lower than 'Low') which will be nearly

silent.

• When Sleep Mode is active, PlasmaWave

will be

disabled, but it can be turned back on.

CONTROL PANEL

INITIAL OPERATION

1. Turn the product upside down.

2. Grab the handle at the bottom of the

product, turn counter-clockwise, and pull

out the filter cover.

3. Remove the protective vinyl from the filter

installed inside the product.

4. Install the filter top side down into the

bottom of unit until it is fully inserted. The

top of the filter shows the opening and the

bottom of the filter is solid.

5. After installing the filter, turn the handle

clockwise to close the filter cover.

6. Return the product to an upright position

and resume normal operation.

When to Replace Filters

Filter Indicator Light When to Service When to Replace

360º All-in-One

True HEPA Filter

Clean once every 14 days

Lasts Approx. 12 months

• When the Check Filter indicator LED is on, it is time to replace the All-in-One True HEPA Filter.

• Intervals between filter replacement may vary depending on environment.

MAINTENANCE

1712-0110-00

FILTER

REPLACING FILTERS

Resetting Filter Life:

After replacing the 360º All-in-One True HEPA Filter, use a small object such as a

paper clip, to press and hold the Filter Reset Button for at least 5 seconds until the

Filter Replacement Indicator turns off.

CLEANING CARE

Cleaning the Filters:

Clean with a vacuum or a soft brush.

• Only clean the Pre-Filter.

• This filter CAN NOT be washed.

• Intervals between filter cleaning may vary

depending on the air quality.

Cleaning the Exterior & Interior:

Wipe with a soft damp cloth using room

temperature water. Afterwards, wipe it down with

a clean dry cloth.

After turning the product upside down, remove the

filter cover and clean the interior with a vacuum

cleaner.

• For optimal performance, clean every 14 days.

NOTICE

• When cleaning the unit, always unplug the power cord first and then wait until the unit has cooled

down.

• Never disassemble, repair, or modify this unit yourself.

• Do not use flammable sprays or liquid detergents.

• Do not allow children to clean or maintain the unit.

• Before cleaning or maintaining, ensure unit is unplugged.

• Do not use benzene, alcohol, or other volatile fluids, which may cause damage or discoloration.

06. PlasmaWave

Button

Enables or disables PlasmaWave

"When the unit is running, you may hear a chirping

or buzzing sound. The sound is from large

particles passing through PlasmaWave

, it is

normal and does not signify product failure."

Press the PlasmaWave

Technology button when

the unit is on to enable or disable this feature.

07. Fan Speed Indicator Buttons

Indicates the current fan speed.

• Use the Fan Speed arrow buttons to set the

desired fan speed. Fan speeds cycle over in this

sequence: Auto, Low, Medium, High, Auto.

Low Medium High

08. Power Button

Turns the unit on or off. During the first 30

seconds of power, the Air Quality Indicator will

cycle through Blue, Amber and Red colors.

• Smart Sensor takes approximately 4 minutes to

detect the air quality in the environment before

normal operation begins.

UNIT SPECIFICATIONS

Model Name A231 / A230 Dimensions

9.5 in(W) x 9.5 in(D) x 14.6 in(H)

Power Voltage

AC 120 V / 60 Hz

Weight 6.75lbs

Power Rate 55W

Replacement

Filter

FILTER O/SKU: 1712-0110-00

Verified Room Size 230sq.ft.

The exterior, design, and product specifications may be changed without prior notice to improve product performance.

Contact Winix for product related inquiries and customer service

• Dedicated Call Center:

☎

(877) 699-4649

• Website: www.winixamerica.com

To expedite service, please specify the model name and number, the nature of the problem,

your contact information, and your address.

4-STAGE

AIR PURIFICATION

Activated Carbon Filter

Fine Mesh Pre-Filter

True HEPA Filter

PlasmaWave

Air Purification means it

removes inanimate particles
