WHERE TO USE

12~18 in

Allow 12 ~ 18 in. of space between TVs, radios,

and other electronics

Electromagnetic interference from certain

electronics may cause product malfunction.

Place indoors away from direct sunlight

Direct exposure may cause product

malfunction or failure.

Only place on hard, flat surfaces

Flimsy or slanted surfaces may result in

abnormal noise and vibrations.

Allow at least 12 ~ 18 in. from walls for maximum

air flow

True HEPA Filter

Activated Carbon Filter

PlasmaWave

Pre-Filter

4-STAGE AIR PURIFICATION

FRONT

PACKAGE CONTENTS

BACK

Alexa Setup Guide /

Wi-Fi Setup Guide

User

Manual

Control Panel

Front Panel

Air Outlet

Vent

Handle

Power Plug

(1) Pre-Filter

(4) Activated Carbon Filters

(1) True HEPA Filters

Unit

MODEL PART DIAGRAM

07 08 09 11 12

01 03 04 05 0602

01. Air Quality Indicator

Color coded LED light indicates one of three levels

of Air Quality: Red (poor), Amber (fair), and Blue

(good).

02. Auto Mode Indicator

The LED "Auto" light will indicate when Auto Mode

is activated.

03. Fan Speed Indicator

Indicates the current fan speed.

Low Medium High Turbo

04. Sleep Mode Indicator

The LED "Sleep" light will indicate when Sleep

Mode is activated.

05. Filter Replacement Indicator/

Filter Reset Button

• Indicator : LED light indicates when it is time to

change the filter.

• Button : After replacing the True HEPA Filter,

press the Filter Reset button for at least 5

seconds until the Filter Replacement Indicator

turns off.

06. Wi-Fi Indicator

• Enables or disables the Wi-Fi feature.

• When in the pairing state, the Wi-Fi LED

flashes.

• When paired successfully, the Wi-Fi LED will be

a solid white light.

07. Smart Sensor

Detects the amount of odorous gas in the

environment. When in Auto mode, the fan speed

adjusts according to the detected amount of gas.

08. Power Button

Turns the unit on or off. During the first 30 seconds

CONTROL PANEL

INITIAL OPERATION

1. Remove the front panel by grasping its

upper edge and gently pulling forward.

2. Remove the Pre-Filter, then the bag of

filters behind it.

3. After removing the packing vinyl of the

filter, insert the Activated Carbon Filter

into the Pre-Filter.

4. Install the filters until they fit securely in place.

02. True HEPA Filter (back)

01. Pre-Filter (With Carbon Filter) (front)

5. After filters are installed, close the front

panel.

6. Insert the power cord into an electrical

outlet.

Latch

When to Replace Filters

Filter Indicator Light When to Service When to Replace

Pre-Filter

none

Clean once every

14 days

Permanent

Activated Carbon

Filter

none

Can NOT be WASHED

Replace every

3 months

True HEPA Filter

Lasts Approx.

12 months

• When the Check Filter Indicator LED is flickering, it is time to replace the Filter.

• Intervals between filter replacement may vary depending on environment.

MAINTENANCE

CLEANING CARE

Cleaning the Filters:

Use a vacuum cleaner or soft brush to clean the

Pre-Filter

• If it is excessively soiled, rinse in room

temperature water.

• Do not use detergent or soap.

• Allow the filter to dry for 24 hours or more

before using.

• Intervals between filter cleaning may vary

depending on the air quality.

• Do not use hot water over 104

F or volatile

fluids such as paint thinner.

Cleaning the Exterior & Interior:

Wipe with a soft damp cloth using room

temperature water.

• Afterwards, wipe it down with a clean, dry cloth.

Open the front panel and clean the interior with a

vacuum cleaner.

• For optimal performance, clean every 1-2 months.

NOTICE

• When cleaning the unit, always unplug the

power cord first and then wait until the unit has

cooled down.

• Never disassemble, repair, or modify the unit

yourself.

• Do not use flammable sprays or liquid detergents.

• Do not allow children to clean or maintain the unit.

• Before cleaning or maintaining, ensure unit is

unplugged.

• Do not use benzene, alcohol, or other

volatile fluids, which may cause damage or

discoloration.

SPECIFICATIONS

Model 9800

Voltage AC 120 V / 60 Hz

Power Rate 95W

Verified

Room Size

500sq.ft.

Dimensions

16.5in(W) × 11.8in(D)

× 23.2in(H)

Weight 18.7 lbs

Replacement

Filter

Filter A / SKU: 115115

The exterior, design, and product specifications

may be changed without prior notice to improve

product performance.

of powering up, the Air Quality Indicator will cycle

through Blue, Amber and Red colors.

• Odor Sensor takes approximately 4 minutes to

detect the air quality in the environment before

normal operation begins.

09-1. Fan Speed/Auto/Sleep Buttons

Use the Fan Speed arrow buttons to set the

desired fan speed. Fan Speeds cycle over in

this sequence: Auto, Low, Medium, High, Turbo,

Sleep, Auto.

• Auto Mode:

- Auto Mode automatically adjusts fan

speeds according to your indoor air

quality. The fan speed will adjust to low

when air quality is good, medium when

fair, and to high when poor.

• Sleep Mode:

When Sleep Mode is activated, the Air Quality

Indicator LED light is disabled.

- Fan speed will automatically set to

minimum speed (lower than 'Low') which

will be nearly silent.

- When Sleep Mode is active, PlasmaWave

will be disabled, but it can be turned back

on.

09-2. PlasmaWave

Button Press and hold the two arrow

buttons

+ for 3 seconds

Press the Plasmawave

button when the unit is

on to enable or disable this feature. By default,

PlasmaWave

is enabled whenever the unit

is powered on. "When the unit is running, you

may hear a chirping or buzzing sound. The

sound is from large particles passing through

PlasmaWave

, it is normal and does not signify

product failure."

10. PlasmaWave

Indicator

Indicates whether PlasmaWave

is enabled or

disabled.

11. Wi-Fi Button

• Press for 3 seconds to activate pairing mode.

• When Wi-Fi is paired, press the button to turn

Wi-Fi off or back on.

12. Light Sensor

Detects the amount of ambient light in the

environment. When in Auto Mode, the light sensor

detects when to put the unit into Sleep Mode.

Winix Smart Wi-Fi Setup

Before you begin, make sure you have a wireless router

that is 2.4Ghz or newer and have a Smartphone that is

Android5.0 and later or iOS10.0 and later. Reference the

Winix Smart Wi-Fi Set Up Guide for more details.

• Latest Phone Operating System requirements are

subject to change based on future phone technology

and app version updates.

• Make sure to disable any VPN networks before

connecting your unit.

Download the Winix Smart app on your device.

• available via Google Play store or iTunes App

store.

Run the app and follow the setup guide to connect

your device to the unit.

①

Select "New Unit" and choose 9800 to connect

to this model.

②

Read the notice and select "OK".

③

Enter the password to your Wi-Fi network.

④

Press and hold the Wi-Fi button on the unit's

control panel until it beeps.

• The Wi-Fi strength indicator will begin to

blink.

⑤

Connect to the Winix Smart network via your

device's network menu.

⑥

Selecting "Next" will connect your unit to your

device.

⑦

Define the unit settings (Name and Location).

⑧

When set up is complete, the Winix Smart

Indicator will light up.

Resetting Filter Life:

After replacing your True HEPA Filter, place the Pre-Filter back in and close the Front

Panel. While the unit is on, hold the Filter Reset Button for at least 5 seconds until

you hear the beep. After the beep, the Filter Replacement Indicator will disappear.

Your Winix True HEPA is now reset.

REPLACING FILTERS

115115

Air Purification means it

removes inanimate particles
