A= Anton Bauer
B= Hyperdeck Shuttle
C= IDX/Swit
D= Odyssey 7 (NOTE: Install M2.5
locating socket cap on plate
prior to installing 1/4-20 screw)
HOLE CHART
Included:
(5) 1/4-20x3/8 socket button
(3) 1/4-20x5/8 socket button
(4) M3x12mm Phillips pan head ( )Anton Bauer
(4) M3x10mm Phillips pan head ( )Hyperdeck Shuttle
(4) M3x8mm Phillips pan head ( )IDX/Swit
(1) M2.5x4mm socket cap screw ( )Odyssey 7
SIDE PLATE (BMSC)
© Wooden Camera, Inc. 2011-2014
1. For single PLATE PLATE attachment, select and three
. 1/4-20x3/8 SCREWS
2. Select CAMERA 1/4-20 HOLES, locate on right or left
side of and CAMERA BODY SIDE PLATE.
3. Align 1/4-20 HOLES CAMERA BODY SIDE on and
PLATE, select and tighten with 1/4-20x3/8 SCREWS
allen wrench.
SIDE PLATE
4. For multiple PLATE PLATES attachment, align to
as shown below, select and CAMERA BODY
tighten 1/4-20x5/8 SCREWS with allen wrench.
For attaching accessories find appropriate threaded holes by
using the below. Insert and tighten HOLE CHART PHILLIPS
PAN HEAD SCREWS 1/4-20 SCREWS or into corresponding
hole as shown on the on the next page.HOLE DIAGRAM
SIDE PLATE (BMSC)
© Wooden Camera, Inc. 2011-2014
= 1/4-20 Pass Through Holes = Wireless Audio Receiver = Side Plate Cable Clamp
Additional Attachment Holes:
