INSTALLATION INSTRUCTIONS
Sensor Modules
SMAUD01, SMVID01, SMMAG01, SMLIT01, SMCC01, SMVLT01
DESCRIPTION
The Xantech Sensor Module product line provides several sensing solutions for a wide variety of
automation needs. Used in conjunction with Xantech’s award winning MRC platform*, source
management and control is easy and reliable. Also, the sensor modules can be used with the
CBCSM1 connecting block to provide a simple interface solution. The CBCSM1 can provide positive
and negative logic through its PULL UP and PULL DOWN connections.
(* MRC44, MRAUDIO4X4, MRC88, MRAUDIO8X8)
The Xantech Sensor Module product line is composed of six complete, easy to install packages.
SMAUD01 Audio Sensor Module
SMVID01 Video Sensor Module
SMMAG01 Magnetic and Current Sensor Module
SMLIT01 LED and Light Sensor Module
SMCC01 Contact Closure Sensor Module
SMVLT01 AC\DC Voltage Sensor Module
Each module comes with double-sided foam tape and mounting screws. Also, built into the sensor is
a convenient LED light that turns ‘on’ to indicate the sensor is in an ‘on’ condition.
SPECIFICATIONS
Delay: Adjustable between 0 and 15 seconds.
+12VDC, <50mA.
1/8” (3.5mm) mini-plug, Tip: +12VDC, Ring: Signal, Sleeve: Ground.
Sensor Module Dimensions: 3/4” W x 3 3/4” L x 3/4” H.
Control Cable Length: Approx. 6 feet
Sensor Cable** Length: 6.5’ SMAUD01, SMVID01
Sensor Cable** Length: 5.0’ SMMAG01, SMLIT01
(** not applicable on the SMCC01, SMVLT01)
