ZAGRZEB

stereo four

pole vc filter

Model of 1979

operator’s manual rev. 1979/1.1

SALUT

Thank you for purchasing this Xaoc Devices

product. Zagrzeb  is a stereo multi-

mode 4-pole (24dB/oct) state variable volt-

      

distinct frequency responses, three of which are

available simultaneously. Zagrzeb is designed

to sound smooth and clean unless it is overdriv-

en with a hot signal—however, it does not lack

character! We believe it will be appreciated by

fans of old Japanese synthesizers but bear in

mind that Zagrzeb is not a clone of any existing

design. The four-pole state variable structure

is a new development and offers unique sonic

characteristics. While Zagrzeb is designed for

    

oscillators like Xaoc Odessa), it can easily han-

dle mono signals and is capable of creating a

faux stereo pair thanks to a special phase shift-

ing network at the input.

INSTALLATION

The module requires 8hp worth of free space in

the Eurorack cabinet. Always turn the power

off before plugging the module to the bus board

using the supplied ribbon cable paying close at-

tention to power cable pinout and orientation.

The red stripe indicates the negative rail and

should match the dot or mark on the bus –12V

board as well as the unit. Zagrzeb is internally

secured against reversed power connection,

may cause

serious damage to other components of your

system, because it will short circuit the +12V

and +5V power lines. Always pay particularly

close attention to the proper orientation of

your ribbon cable on both sides! The module

should be fastened by mounting the supplied

screws before powering up.

To better understand the device, we strongly

advise the user to read through the entire man-

ual before use.

MODULE OVERVIEW

       

stereo pair of and signal left/mono right

inputs

is AC-coupled and accepts all Eu-

rorack signal levels (up to 20Vpp), however, a

conservative 10Vpp level is recommended as



increased amplitude thus causing distortion.

With a mono signal patched into the left/

mono jack the module automatically creates

a stereo signal. The three pairs of jacks below

the inputs are the high pass 24

, band

pass

, and low pass 24

outputs of

bp config switch

near the

band pass outputs offers three variants of this

middle type of response. The big cutoff freq

knob below

controls the cutoff frequency of

    

resonance slider

controls the degree of

resonance. The illuminated slider shaft indi-

cates how much the peaks of the output signal

exceed the peaks of the input signal (mostly

due to the resonant ringing around the cut-

off frequency). The fm 1

and fm 2

inputs at the bottom of the panel control the

cutoff frequency. The sensitivity of the fm 1

input is controlled by the small attenuverter

knob

from –2 oct/V through 0 to +2 oct/V.

The fm 2-

ed). The CV input spread

allows the user

to animate the stereo image by moving the left



directions.

FREQUENCY RESPONSE

        -

     

offer –12dB/oct low pass, +6/–6dB band pass,

and +12dB/oct high pass responses. Zagrzeb’s

4-pole structure gives the user as many as

    

low pass up to +24dB/oct high pass with all

three possible combinations of 6dB/oct slopes

that sum up to 24 in between. These interme-

module

explained
