Before Using
Introduction
Features of this radio
144/430 MHz repeater is equipped with a standard C4FM digital communication modem capable of selecting the communications
mode automatically
Clear audio and data communication is achieved using the digital modem functions
Transmit power 50 watts with cooling fan
Full color 3.5-inch LCD, high luminance TFT touch panel controller
Intuitive, user touch panel operation
About the touch panel
● Precautions in using the touch panel
The touch panel of the controller is designed to work with the slightest touch of a finger.
The touch panel may not work when a protective film or sheet is affixed to the LCD.
Use of a pointed fingernail or pen to operate the touch panel, or pressing too hard may damage or scratch the screen.
Smart phone operations such as flicking, pinch in and pinch out are not possible.
● Maintaining the touch panel
To clean the touch panel, switch the power supply OFF before using a dry, soft cloth to wipe away dust and dirt from the touch panel.
When the touch panel is really dirty, wet a soft cloth and wring it out thoroughly before using it to wipe the touch panel.
When wiping the touch panel, be careful not to wipe too hard or scratch the surface with your nails.
When the touch panel is scratched, it may become difficult to see the display.
About registered trademarks and copyrights
Company and product names described in this manual are trademarks and registered trademarks of their respective companies.
Unauthorized reproduction or copying of a part or all of the copyrights owned by Yaesu Musen Co., Ltd. in any form whatsoever is
strictly prohibited.
How to read this manual
In this manual, controller operations are expressed as follows:
Touch [SQL] .......................................Indicates that the symbol on the touch panel screen is to be touched quickly.
Select [MODE] ...................................Indicates that the items are to be highlighted on the touch panel screen.
The following symbols are also used in this manual:
Caution
...Explains information to avoid incorrect operation.
Tip
...Explains operating hints and helpful advice.
Also note: the actual product may differ from the drawings shown in this manual.
