Side 1/4

–12 +12

HIGH

BATT. TUNER

PICKUP MIX

BASS SIDE T REBLE SIDE

–12 +12

MID

MASTER

VOL.

LOW

0 10

0 10 0 10

Thank you for choosing a Yamaha electric-acoustic guitar.

In order to make the most of the advanced features and performance provided

by your guitar, please read this manual carefully before using the instrument.

NOMENCLATURE/THE CONTROLS

The built-in preampliﬁer is automatically turned ON when a guitar cable is

connected to the output jack.

MASTER VOL. (Master Volume) Control Adjusts the overall output volume level.

*

MakesurethattheMASTERVOL.isturnedto“0”beforeconnectingordisconnecting.

BATT. (Battery Check) Indicator This indicator will light when the battery needs

to be replaced. Please replace the battery as soon as possible when the BATT. indicator lights.

*The battery check indicator may light momentarily when the TUNER switch is

pressed.Thisisnotasignhowever,thatthebatterypowerislow.

3 Band Equalizer

LOW : Boosts or cuts the level of the low frequencies.

MID : Boosts or cuts the level of the middle frequencies.

HIGH : Boosts or cuts the level of the high frequencies.

PICKUP MIX Control

TREBLE : Controls the volume of the treble side pickup.

BASS : Controls the volume of the bass side pickup.

*Thesystemwill notproducesoundwhenboth theTREBLESIDEandBASSSIDE

controlsaresetto“0”,evenifthemastervolumecontrolisturnedup.

Tuner Switch Switches the tuner ON/OFF.

Tuner Display Displays tuner information.

Using the Sound Hall Cover

If feedback occurs when playing at high volumes, the Sound Hole Cover should be inserted into the

sound hole. When inserted into the sound hole, Sound Hole Cover effectively reduces feedback.

q MASTER VOL.

Bass Side

Pickup

Mix of Bass Side

Pickup

Treble Side

Pickup

Mix of Treble

Side Pickup

Battery compartment

Control Section

Output Jack (with power switch function)

Sound Hole Cover for

feedback control

(Accessory)

Pickups

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe and handy place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury

or even death from electrical shock, short-circuiting, damages, ﬁre or other hazards.

These precautions include, but are not limited to, the following:

Do not open

• This instrument contains no user-serviceable parts. Do not open the instrument or at-

tempt to disassemble or modify the internal components in any way. If it should appear

to be malfunctioning, discontinue use immediately and have it inspected by qualiﬁed

Yamaha service personnel.

Water warning

•

Do not expose the instrument to rain, use it near water or in damp or wet conditions, place it on

any containers (such as vases, bottles, or glasses) containing liquids that might spill into any

openings. If any liquid such as water seeps into the instrument, turn off the power immediately

and have the instrument inspected by qualiﬁed Yamaha service personnel.

If you notice any abnormality

•

When one of the following problems occur, immediately turn off the power and remove all bat-

teries from the instrument, then have the instrument inspected by Yamaha service personnel.

- It emits unusual smells or smoke.

- Some object has been dropped into the instrument.

- There is a sudden loss of sound during use of the instrument.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical

injury to you or others, or damage to the instrument or other property. These precautions

include, but are not limited to, the following:

Connection

•

Before connecting the instrument to other electronic components, turn off the power for all compo-

nents. Before turning the power on or off for all components, set all volume levels to minimum.

• Be sure to set the volumes of all components at their minimum levels and gradually raise

the volume controls while playing the instrument to set the desired listening level.

Location

• Do not place the instrument in an unstable position where it might accidentally fall over.

Handling caution

• Do not rest your weight on, or place heavy objects on the instrument, and do not use

excessive force on the buttons, switches or connectors.

• Do not use the instrument/device or headphones for a long period of time at a high or

uncomfortable volume level, since this can cause permanent hearing loss. If you experi-

ence any hearing loss or ringing in the ears, consult a physician.

* Yamaha cannot be held responsible for damage caused by improper use or modiﬁ-

cations to the instrument, or data that is lost or destroyed.

* Information on the battery can be found in the section at the end of this sheet.

* Please read the instruction manual for the external audio device such as a guitar

ampliﬁer, etc., prior to use.

USING THE TUNER

The guitar is equipped with an A4=440Hz standard pitch tuner. The tuner’s circuitry is inde-

pendent from the guitar’s output circuit so switching the tuner ON/OFF will have no affect

on sound output.

q Press the TUNER switch, with or without the cable connected, the and lamps will

ﬂash simultaneously and the tuner is switched ON.

w Tune the guitar string until the note name of the desired pitch appears in the tuner’s display.

The lamp indicates the pitch is low. The lamp indicates the pitch is high.

The pitch indicator ( ) ﬂashes slower as the string’s pitch nears the note shown in the display.

e The string is in tunewhen the and lamps both light.

r Press the TUNER switch again to switch the tuner OFF.

*

ThetunerwillautomaticallyswitchOFFapproximatelytwominutesaftertheTUNERswitch

ispressed(energysavingfunction).Tocontinuetuning,presstheTUNERswitchagain.

*ItmaytakeafewsecondsbeforethetunercandetectpitchesafterbeingswitchedON.

*The note name and displays may have difculty keeping up with irregular

pitchchanges.Graduallychangethepitchandcheckwhentuning.

*Thetunermayhavedifcultydetectingnotesrichwithovertonesorwithveryshortsustain.

*The batterycheck indicatorlights continuously whenbatterypoweris low.Pleasechange

thebatteryatthistime.

SPECIFICATIONS

System: SYSTEM-61(Monaural 2 way) Pickup: Contact Pickup (installed inside

of the body) Pre-amplifier Controls:

MASTER VOL., 3 Band (HIGH, MID, LOW)

EQ control, PICKUP MIX control (TREBLE SIDE, BASS SIDE) Output jack:

Combina-

tion end pin/power switch Output impedance:

1 kΩ Power supply: 9V DC,

S-006P (6F22, 6LR61) dry cell battery x1 Battery life:

Approx. 80 hours (without

tuner), Approx. 70 hours (with the preamp switched ON and the tuner used 2 minutes

every 1 hour) *Whenusingamanganesebattery.*Variesaccordingtooperating

conditions. Tuner: : Chromatic type (12 semitones), A4=440Hz Tuning System Auto

OFF Function Input: Tuner automatically switches OFF after 2 minutes. : Built in pickup

Pitch Accuracy Range: +/– 3 cents Accessories: Hexagonal wrench for neck

adjustment x1, S-006P (6F22, 6LR61) dry cell battery x1, Sound hole cover x1

BATTERY REPLACEMENT

In order to avoid reduced sound quality, replace the battery as soon as possible when the

battery check indicator lights.

q Press the release lever on the battery holder in the direction indicated by the arrow in the

illustration in order to unlock it.

w Slide out the battery case.

e Remove the old battery from the battery case, and insert the new battery making sure that

the (+) and (–) terminals of the battery are positioned as shown in the illustration. Use only

a DC9V, S-006P (6F22, 6LR61) or equivalent battery.

Slide the battery case back into the battery holder and press ﬁrmly so that the battery

case locks into place.

Release lever

DC9V S-006P

(6F22, 6LR61)

Battery case

q w, r e

Electric Acoustic Guitar

Owner’s Manual

System61_WR33590_R3_0819.indd 2 14/08/21 13:50

警告この表示内容を無視した取り扱いをすると、

死亡や重症を負う可能性が想定されます。

電池

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious

injury or even death from electrical shock, short-circuiting, damages, ﬁre or other

hazards. These precautions include, but are not limited to, the following:

Battery

• Follow the precautions below. Failure to do so might result in explosion, ﬁre, overheating

or battery ﬂuid leakage.

- Do not tamper with or disassemble batteries.

- Do not dispose of batteries in ﬁre.

- Do not attempt to recharge batteries that are not designed to be charged.

- Keep the batteries separate from metallic objects such as necklaces, hairpins, coins,

and keys.

- Use the speciﬁed battery type only.

- Use new batteries, all of which are the same type, same model, and made by the same

manufacturer.

- Always make sure all batteries are inserted in conformity with the +/- polarity markings.

- When the batteries run out, or if the instrument is not to be used for a long time,

remove the batteries from the instrument.

• Do not carry or store batteries with other metal objects such as necklaces, hairpins,

metal coins, or keys.

• If the batteries do leak, avoid contact with the leaked ﬂuid. If the battery ﬂuid should come

in contact with your eyes, mouth, or skin, wash immediately with water and consult a doc-

tor. Battery ﬂuid is corrosive and may possibly cause loss of sight or chemical burns.

Make sure to discard used batteries according to local regulations.

AVVERTENZA

Attenersi sempre alle precauzioni di base indicate di seguito per evitare il rischio

di lesioni gravi o addirittura di morte conseguente a scosse elettriche, cortocircuiti,

danni, incendi o altri pericoli. Tali precauzioni includono, fra le altre, quelle indica-

te di seguito:

Batteria

• Attenersi alle precauzioni indicate di seguito. In caso contrario, si potrebbero causare

esplosioni, incendi, surriscaldamento o fuoriuscite di liquido dalle batterie.

- Non manomettere né disassemblare le batterie.

- Non smaltire le batterie nel fuoco.

- Non ricaricare batterie non ricaricabili.

Tenere le batterie lontane da oggetti metallici come collane, fermacapelli, monete e chiavi.

- Utilizzare solo il tipo di batterie speciﬁcato.

- Utilizzare batterie nuove, tutte dello stesso tipo, modello e produttore.

- Assicurarsi che tutte le batterie siano inserite nel rispetto delle indicazioni di polarità +/-.

- In caso di esaurimento delle batterie o se si prevede di non utilizzare lo strumento per

molto tempo, rimuovere le batterie dallo strumento.

• Conservare le batterie lontano dalla portata dei bambini, che potrebbero ingerirle acci-

dentalmente.

• In caso di fuoriuscite, evitare il contatto con il liquido delle batterie. Se il liquido delle

batterie viene a contatto con gli occhi, la bocca o la cute, lavare immediatamente con

acqua e rivolgersi a un medico. Il liquido delle batterie è corrosivo e potrebbe causare la

perdita della vista o ustioni chimiche.

Smaltire le batterie esauste in conformità alle normative locali.

AG-Stomp の電源供給機能に関するご注意

本ギターは弊社多機能プリアンプ AG-Stomp の電源供給機能には対応しており

ません。

電源供給機能を使用しますと、本ギターの内蔵プリアンプ内の回路が破損し、音

出力・チューナー機能等に支障をきたすおそれがあります。

※AG-Stomp に接続する場合は、電源供給機能を OFF(+9VSUPPLY スイッチを OFF)

にし、本ギターのバッテリーホルダーに電池を挿入した状態でお使いください。

電池を分解しない。

電池を火の中に入れない。

使い切りタイプの電池は、充

電しない。

指定以外の電池を使用しない。

複数の電池を使う場合、同じ

メーカーの同じ種類、同じ品

番の新しい電池を使用する。

電池はすべて＋ / －の極性表

示どおりに正しく入れる。

長時間使用しない場合や電池

を使い切った場合は、電池を

本体から抜いておく。

電池は子供の手の届くところ

に置かない。

電池を金属製のネックレスや

ヘアピン、コイン、鍵などと一

緒に持ち運んだり保管しない。

電池が液漏れした場合は、漏

れた液に触れない。万一液が

目や口に入ったり皮膚に付い

たりした場合は、すぐに水で

洗い流し、医師に相談してく

ださい。

Caution! Regarding the AG-Stomp Guitar

Power Supply Function

This guitar is not compatible with the power supply function on the AG-Stomp

acoustic guitar preamplifier. Using the guitar power supply function on the AG-

Stomp can damage the guitar’s built-in preampliﬁer resulting in abnormal sound

output, tuner operation, etc.

* Before connecting the guitar to the AG-Stomp, make sure that the AG-Stomp’s guitar power

supply function is switched OFF (switch OFF the +9V SUPPLY switch) and insert a battery

into the guitar’s battery holder.

・使用済みの乾電池は、各自治体で決められたルールに従って廃棄しましょう。

Attention ! À propos de la fonction d’alimentation

électrique de la guitare du AG-Stomp

La guitare n’est pas compatible avec la fonction d’alimentation électrique du pré-

ampliﬁcateur de guitare acoustique AG-Stomp. L’utilisation de cette fonction sur

l’AG-Stomp peut endommager le préampliﬁcateur intégré de la guitare, ce qui nuit

à la qualité du son, au fonctionnement de l‘accordeur, etc.

* Avant de raccorder la guitare à l’AG-Stomp, assurez-vous que la fonction d‘alimentation élec-

trique de guitare de l‘AG-Stomp est désactivée (commutateur +9V SUPPLY en position OFF)

et introduisez une pile dans le porte-pile de la guitare.

Attenzione! Funzione di alimentazione della

chitarra AG-Stomp

Questa chitarra non è compatibile con la funzione di alimentazione del preampliﬁca-

tore per chitarra acustica YAMAHA AG-Stomp. Usando la funzione di alimentazione

della chitarra AG-Stomp si può danneggiare il preamplificatore incorporato della

chitarra, producendo suoni ed un funzionamento dell’accordatore anormali, ecc.

* Prima di collegare la chitarra all’AG-Stomp, controllare che la funzione di alimentazione della

chitarra AG-Stomp sia spenta (portando su OFF l’interruttore +9V SUPPLY) ed inserire una

batteria nel vano batteria della chitarra.

AVERTISSEMENT

Veillez à toujours observer les précautions élémentaires énumérées ci-après pour

éviter de graves blessures, voire la mort, en raison d'une électrocution, d'un court-

circuit, de dégâts, d'un incendie ou de tout autre risque. La liste de ces précautions

n'est pas exhaustive :

Piles

• Veillez à respecter les précautions détaillées ci-après. Le non respect de ces instruc-

tions risque de provoquer une explosion, un incendie ou une fuite du liquide des piles.

- N'altérez pas les piles et n'essayez pas de les démonter.

- Ne jetez pas les piles au feu.

- Ne tentez pas de recharger une pile non rechargeable.

- Gardez les piles éloignées des objets métalliques tels que les colliers, les épingles à

cheveux, les pièces de monnaie ou les clés.

- Utilisez uniquement le type de pile spéciﬁé.

- Veillez à utiliser des piles neuves, de type et de modèle identiques, issues du même

fabricant.

- Prenez soin de respecter la polarité (+/-) lors de la mise en place des piles.

- Lorsque les piles sont épuisées ou en cas de non-utilisation de l'instrument pendant

une durée prolongée, retirez les piles de l'instrument.

• Conservez les piles hors de portée des enfants car ceux-ci risquent de les avaler.

• En cas de fuite du liquide des piles, évitez tout contact avec ce liquide. En cas de contact

avec les yeux, la bouche ou la peau, rincez immédiatement à l'eau claire et consultez un

médecin. Le liquide présent dans la pile est corrosif et peut provoquer la cécité ou des

brûlures chimiques.

Veiller à éliminer les piles usagées selon les réglementations locales.

System61_WR33590_R3_0819.indd 10 14/08/21 13:51

Produkt Specifikationer

Mærke:	Yamaha
Kategori:	Guitar
Model:	NCX2000R
Type:	Akustisk elektrisk guitar
Bredde:	370 mm
Produktfarve:	Black,Rosewood,Wood
Bæretaske:	Ja
Længde:	990 mm
Bagside materiale:	Rosentræ
Guitar model:	Klassisk
Række:	Standard
Bånd type:	Standard
Bånd, antal:	19
Nakke materiale:	Mahogni
Smidighed:	Højre
Master, tonekontrol:	Ja
Strenge, antal:	6 strenge
Nut, bredde:	52 mm
Gribebræt, materiale:	Ibenholt
Skala, størrelse:	650 mm
Top finish:	Glans
Halsfinish:	Mat
Pickguard:	Ingen
Nut, materiale:	Knogle
Sadel, materiale:	Knogle
Mellemrum mellem strenge:	11.8 mm
Side materiale:	Rosentræ
Top materiale:	Gran
Bro, materiale:	Ibenholt + palisander
Strenge, spænding:	Mellemmåler
Krop dybde (min.):	94 mm
Krop dybde (maks.):	100 mm
Kropslængde:	490 mm
