E-1
DeutschFrançais EspañolEnglish
Thank you for selecting this YAMAHA NS-325F speaker system.
NS-325F Speaker System
OWNER’S MANUAL
URGT
Read this before using the speaker.
•
To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
•
Install the speaker in a cool, dry, clean place – away from
windows, heat sources, sources of excessive vibration,
dust, moisture and cold. Avoid sources of humming
(transformers, motors). To prevent fire or electrical shock,
do not expose the speaker to rain or water.
• To prevent the enclosure from warping or discoloring, do
not place the speaker where it will be exposed to direct
sunlight or excessive humidity.
• Do not place the following objects on the speaker:
Glass, china, etc.
If glass etc. falls by vibrations and breaks, it may cause
personal injury.
A burning candle etc.
If the candle falls by vibrations, it may cause fire and
personal injury.
A vessel with water in it
If the vessel falls by vibrations and water spills, it may
cause damage to the speaker, and/or you may get an
electric shock.
• Do not place the speaker where foreign objects such as
water drips might fall. It might cause a fire, damage to
the speaker, and/or personal injury.
• Do not place the speaker where it is liable to be knocked
over or struck by falling objects. Stable placement will
also ensure better sound performance.
PRECAUTIONS
The speaker is constructed with the majority of the weight
located in its upper portion, and is thus susceptible to falling
over if proper care is not taken to insure its stability. If the
speaker falls over, it may damage the speaker or be the
cause of injury (or even death) to persons and/or damage to
personal property.
For safe and proper use of the speaker:
• Position the speaker in a location that is solid, level,
smooth, and low (with respect to the floor).
• Do not push or apply pressure to the side of the speaker
when moving, or lean objects against the side of the
speaker.
• Do not sit on or set objects on top of the speaker.
PRECAUTIONS WHEN POSITIONING THE SPEAKERS
Vibrations or jolts associated with earthquakes and other
phenomena or activities may cause the speaker to fall over.
For safety reasons, using commercially available products
that increase stability in the speaker is recommended
(metal fittings or chains, etc.).
Use the stands included with the speaker to increase
stability:
Be sure to use the stands regardless of where the speaker
is positioned. Attaching the stands included with the
speaker reinforces the base of the speaker not to fall over.
Please be cautioned that even though the stands are
connected, this does not guarantee that the speaker will not
fall over.
• Placing the speaker on the same shelf or rack as the
turntable can result in feedback.
• Never put a hand or a foreign object into the port located
on the rear of the speaker as this might cause personal
injury and/or damage to the speaker.
• When moving the speaker, do not hold the port as it
might cause personal injury and/or damage to the
speaker.
• Any time you note distortion, reduce the volume control
on your amplifier to a lower setting. Never allow your
amplifier to be driven into “clipping”. Otherwise the
speaker may be damaged.
•
When using an amplifier with a rated output power higher
than the nominal input power of the speaker, care should
be taken never to exceed the speaker’s maximum input.
•
Do not attempt to clean the speaker with chemical solvents
as this might damage the finish. Use a clean, dry cloth.
• Do not attempt to modify or fix the speaker. Contact
qualified YAMAHA service personnel when any service
is needed. The cabinet should never be opened for any
reasons.
• Secure placement or installation is the owner’s
responsibility.
YAMAHA shall not be liable for any accident caused
by improper placement or installation of the speaker.
E-2
ATTACHING THE STANDS
When placing the speakers, be sure to use the stands to
increase stability.
Note:
The provided stands are in two types. Two stands are
for the right side and others are for the left side. Attach
each stand to the proper position on the bottom of the
speaker by following the figure below.
Use the 8 specified holes located on the base of the
speaker.
1
2
Procedure:
1Put the 6mm screw through the large hole on the
stand, and screw it into the speaker at one of the
outside holes on the base of the speaker.
At this time, screw it untightly so that the stand can still
be moved.
2Put the 4mm wood screw through the other hole on the
stand, and screw it into the other hole on the base of
the speaker.
3Tighten both of the screws firmly.
4Attach a pad to the bottom of the end portion of the
stand.
5Attach the other stands to the other corners of the base
of the speaker in the same way and confirm that all 4
stands have been firmly attached.
Note:
Be carefull not to apply force to the side of the speaker,
otherwise the speaker may fall causing damage to the
speaker or personal injury.
View from the bottom of the speaker
(L)
(R) (L)
Front
Back
Supplied Accessories
Pad x 4
Screw
(
6mm) x 4
Stand (R x 2, L x 2)
Wood screw
(
4mm) x 4
(L) (R)
(R)
