Side 1/21

E-1

DeutschFrançais EspañolEnglish

Read this before using the speaker.

•To assure the finest performance, please read this

manual carefully. Keep it in a safe place for future

reference.

•Install the speaker in a cool, dry, clean place – away

from windows, heat sources, sources of excessive

vibration, dust, moisture and cold. Avoid sources of

humming (transformers, motors). To prevent fire or

electrical shock, do not expose the speaker to rain or

water.

•To prevent the enclosure from warping or discoloring, do

not place the speaker where it will be exposed to direct

sunlight or excessive humidity.

•Do not place the following objects on the speaker:

Glass, china, etc.

If glass etc. falls by vibrations and breaks, it may cause

personal injury.

A burning candle etc.

If the candle falls by vibrations, it may cause fire and

personal injury.

A vessel with water in it

If the vessel falls by vibrations and water spills, it may

cause damage to the speaker, and/or you may get an

electric shock.

•Do not place the speaker where foreign objects such as

water drips might fall. It might cause a fire, damage to

the speaker, and/or personal injury.

PRECAUTIONS

NS-M325 Speaker System

OWNER’S MANUAL

URGT

Thank you for selecting this YAMAHA NS-M325 speaker system.

•Do not place the speaker where it is liable to be knocked

over or struck by falling objects. Stable placement will

also ensure better sound performance.

•Placing the speaker on the same shelf or rack as the

turntable can result in feedback.

•Any time you note distortion, reduce the volume control

on your amplifier to a lower setting. Never allow your

amplifier to be driven into “clipping”. Otherwise the

speaker may be damaged.

•When using an amplifier with a rated output power

higher than the nominal input power of the speaker, care

should be taken never to exceed the speaker’s

maximum input.

•Do not attempt to clean the speaker with chemical

solvents as this might damage the finish. Use a clean,

dry cloth.

•Do not attempt to modify or fix the speaker. Contact

qualified YAMAHA service personnel when any service

is needed. The cabinet should never be opened for any

reasons.

•Secure placement or installation is the owner’s

responsibility.

YAMAHA shall not be liable for any accident caused

by improper placement or installation of the speaker.

E-2

WARNING:

•This speaker weighs 3.8 kg (8.4 lbs). Do not mount it

on thin plywood or a wall with soft surface material. If

mounted, the screws may come out of the flimsy

surface and the speaker may fall. This damages the

speaker or causes personal injury.

•Do not install the speaker to a wall with nails,

adhesives, or any other unstable hardware. Long-

term use and vibrations may cause it to fall.

•To avoid accidents resulting from tripping over loose

speaker cable, fix it to the wall.

■To mount the speaker on a wall by using

the attached mounting bracket

Fasten screws into a firm wall or wall support as shown

in the figure, and hang the holes of the mounting

bracket on the protruding screws.

* Make sure that the screws are securely caught by the

narrow parts of the holes.

Wall/ wall

support

Tapping screw (3.5–4 mm)

(Available at the hardware

store)

40 mm

Min.

20 mm

3 mm

You can also use the screw holes on the rear of the

speaker for installing the speaker using a commericially

available speaker bracket (if you do not use the attached

mounting bracket).

Screw holes

Diameter: 6 mm

Hole depth: 15 mm

60 mm

Place the speakers on a sturdy, vibration-free surface, on a

well-built stand.

■ Using as 2ch stereo speakers

Better stereo images will be obtained when the speakers

are slightly angled in towards the listeners.

■ Using as front speakers in a multi channel

system

Position the speakers on both sides of the TV. The

positioning of speakers is important, because it controls the

whole sound quality of a multi channel system. Set up the

speakers on the basis of your listening position by following

the owner’s manual supplied with your amplifier.

■ Using as presence or surround speakers

Mount the speakers on a wall or place the speakers on a

shelf. Determine the best position by following the owner’s

manual supplied with your amplifier.

Note:

This speaker features a magnetically shielded design,

but there is still a chance that placing it too close to a

TV set might impair picture color or create a buzzing

noise. Should this happen, move the speaker away from

the TV set.

PLACING THE SPEAKERS

Subwoofer

Center

NS-M325

(Front)

NS-M325

(Presence)

NS-M325

(Surround)

NS-M325

(Surround

back)

Produkt Specifikationer

Mærke:	Yamaha
Kategori:	Højttaler
Model:	NS-M325
Type:	Bogreol
Bredde:	149.2 mm
Dybde:	174.6 mm
Højde:	275 mm
Vægt:	3810 g
Produktfarve:	Sort
Udgangseffekt (RMS):	30 W
Equalizer:	Ingen
Husmateriale:	Træ
Anbefalet brug:	Universel
Frekvensområde:	65 - 50000 Hz
Impedens:	6 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2-vejs
Lyd-output kanaler:	2.0 kanaler
Højttaler, placering:	Bordplade/bogreol
Antal drivere:	2
Diskanthøjttaler:	Ja
Antal drivere til diskant:	1
Peak Music-Udgangseffekt (PMPO):	120 W
Sensitivitet:	86 dB
Delefrekvens:	2500 Hz
Plug and play:	Ja
Diskant diameter:	1 "
Bashøjttaler:	Ja
Antal bashøjttalerdrev:	1
Højttaler kabinet:	Lukket
Woofer diameter (britisk mål):	4 "
Højttalerplacering:	Satellit
USB påkrævet:	Ingen
Klemskrue:	Ja
Magnetisk afskærmet:	Ja
