Side 1/20
E-1
EspañolEnglish Français Deutsch
Read this before using the speaker.
•To assure the finest performance, please read this
manual carefully. Keep it in a safe place for future
reference.
•Install the speaker in a cool, dry, clean place – away
from windows, heat sources, sources of excessive
vibration, dust, moisture and cold. Avoid sources of
humming (transformers, motors). To prevent fire or
electrical shock, do not expose the speaker to rain or
water.
•To prevent the enclosure from warping or discoloring, do
not place the speaker where it will be exposed to direct
sunlight or excessive humidity.
•Do not place the following objects on the speaker:
Glass, china, etc.
If glass etc. falls by vibrations and breaks, it may cause
personal injury.
A burning candle etc.
If the candle falls by vibrations, it may cause fire and
personal injury.
A vessel with water in it
If the vessel falls by vibrations and water spills, it may
cause damage to the speaker, and/or you may get an
electric shock.
•Do not place the speaker where foreign objects such as
water drips might fall. It might cause a fire, damage to
the speaker, and/or personal injury.
PRECAUTIONS
NS-M525 Speaker System
OWNER’S MANUAL
URGT
Thank you for selecting this YAMAHA NS-M525 speaker system.
•Do not attempt to clean the speaker with chemical
solvents as this might damage the finish. Use a clean,
dry cloth.
•Do not attempt to modify or fix the speaker. Contact
qualified YAMAHA service personnel when any service
is needed. The cabinet should never be opened for any
reasons.
•Secure placement or installation is the owner’s
responsibility.
YAMAHA shall not be liable for any accident caused
by improper placement or installation of the speaker.
•Do not place the speaker where it is liable to be knocked
over or struck by falling objects. Stable placement will
also ensure better sound performance.
SUPPLIED ACCESSORIES
•Placing the speaker on the same shelf or rack as the
turntable can result in feedback.
•Never put a hand or a foreign object into the port located
on the rear of the speaker as this might cause personal
injury and/or damage to the speaker.
•When moving the speaker, do not hold the port as it
might cause personal injury and/or damage to the
speaker.
•Any time you note distortion, reduce the volume control
on your amplifier to a lower setting. Never allow your
amplifier to be driven into “clipping”. Otherwise the
speaker may be damaged.
•When using an amplifier with a rated output power
higher than the nominal input power of the speaker, care
should be taken never to exceed the speaker’s
maximum input.
Bass control plug x 2
This is used when mouting the speaker to the wall. See “placing the speaker” on page 5.
E-2
■To mount the speaker on a wall by using
the attached mounting bracket
Fasten screws into a firm wall or wall support as shown
in the figure, and hang the holes of the mounting
bracket on the protruding screws. By setting the two
supplied bass control plugs into the ports on the rear of
the speaker, the tone and volume balance of the low
bass sound produced between the port and the wall will
be better.
* Make sure that the screws are securely caught by the
narrow parts of the holes.
Wall/ wall
support
Tapping screw (3.5–4 mm)
(Available at the hardware
store)
40 mm
Min.
20 mm
3 mm
You can also use the screw holes on the rear of the
speaker for installing the speaker using a commericially
available speaker bracket (if you do not use the attached
mounting bracket).
Screw holes
Diameter: 6 mm
Hole depth: 15 mm
60 mm
Place the speakers on a sturdy, vibration-free surface, on a
well-built stand.
■ Using as 2ch stereo speakers
Better stereo images will be obtained when the speakers
are slightly angled in towards the listeners.
■ Using as front speakers in a multi channel
system
Position the speakers on both sides of the TV. The
positioning of speakers is important, because it controls the
whole sound quality of a multi channel system. Set up the
speakers on the basis of your listening position by following
the owner’s manual supplied with your amplifier.
■ Using as presence or surround speakers
Mount the speakers on a wall or place the speakers on a
shelf. Determine the best position by following the owner’s
manual supplied with your amplifier.
Note:
This speaker features a magnetically shielded design,
but there is still a chance that placing it too close to a
TV set might impair picture color or create a buzzing
noise. Should this happen, move the speaker away from
the TV set.
PLACING THE SPEAKERS
Subwoofer
Center
NS-M525
Front
NS-M525
Presence
NS-M525
Surround
NS-M525
Surround back
WARNING:
•This speaker weighs 4.5 kg (9 lbs.14.7 oz.). Do not
mount it on thin plywood or a wall with soft surface
material. If mounted, the screws may come out of the
flimsy surface and the speaker may fall. This
damages the speaker or causes personal injury.
•Do not install the speaker to a wall with nails,
adhesives, or any other unstable hardware. Long-
term use and vibrations may cause it to fall.
•To avoid accidents resulting from tripping over loose
speaker cable, fix it to the wall.

Produkt Specifikationer

Mærke: Yamaha
Kategori: Højttaler
Model: NS-M525
