Yamaha NS-PA120 Manual

Yamaha Højttaler NS-PA120

Læs gratis den danske manual til Yamaha NS-PA120 (40 sider) i kategorien Højttaler. Denne vejledning er vurderet som hjælpsom af 17 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 9 anmeldelser. Har du et spørgsmål om Yamaha NS-PA120, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/40

(NS-PA120: NS-F120 + NS-C120 + NS-B120)

SPEAKER PACKAGE

PACKAGE ENCEINTES

OWNER'S MANUAL

MODE D'EMPLOI

BEDIENUNGSANLEITUNG

MANUAL DE INSTRUCCIONES

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

໪ቂངಖ༚

1 En

Please read the following operating precautions before use. Yamaha will not be held responsible for any damage and/or

injury caused by not following the cautions below.

1. To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2. Install the speakers in a cool, dry, clean place – away

from windows, sources of heat, sources of excessive

vibration, dust, moisture or cold. Avoid sources of

electrical humming (e.g., transformers and motors). To

prevent fire or electric shock, do not expose the speakers

to rain or water.

3. To prevent the enclosure from warping or discoloring, do

not expose the speakers to direct sunlight or excessive

humidity.

4. Avoid installing the speakers where foreign objects may

fall onto them and/or where they may be exposed to

liquid dripping or splashing.

5. Do not place the following objects on top of the

speakers:

– Other components, as they might damage or discolor

the surface of the speakers.

– Burning objects (e.g., candles), as they might cause

fire, damage to the speakers or personal injury.

– Containers of liquid, as they might spill and cause

electric shock to the user or damage to the speakers.

6. Do not place the speakers where they are liable to be

knocked over or struck by falling objects. Stable

placement will also ensure better sound performance.

7. Placing the speakers on the same shelf or rack as the

turntable can result in feedback.

8. Do not insert a hand or object into the port or pick up the

speaker by holding the port, as it may cause personal

injury or damage to the speaker.

9. Any time you note distortion, reduce the volume control

on your amplifier to lower setting. Never allow your

amplifier to be driven into “clipping”. Otherwise, the

speakers may be damaged.

10. When using an amplifier with a rated output power

higher than the nominal input power of the speakers,

care should be taken not to exceed the maximum input of

the speakers.

11. Do not attempt to clean the speakers with chemical

solvents as this might damage the finish. Use a clean, dry

cloth.

12. Do not attempt to modify or fix the speakers. Contact

qualified Yamaha service personnel when service is

needed. The cabinet should never be opened for any

reason.

13. Secure placement or installation is the owner’s

responsibility. Yamaha is not liable for accidents

caused by improper placement or installation of

speakers.

Precautions

Information for Users on Collection and Disposal of

Old Equipment

This symbol on the products, packaging,

and/or accompanying documents means

that used electrical and electronic

products should not be mixed with

general household waste.

For proper treatment, recovery and

recycling of old products, please take

them to applicable collection points, in

accordance with your national

legislation and the Directives

2002/96/EC.

By disposing of these products correctly,

you will help to save valuable resources

and prevent any potential negative

effects on human health and the

environment which could otherwise

arise from inappropriate waste handling.

For more information about collection

and recycling of old products, please

contact your local municipality, your

waste disposal service or the point of

sale where you purchased the items.

[Information on Disposal in other

Countries outside the European Union]

This symbol is only valid in the

European Union. If you wish to discard

these items, please contact your local

authorities or dealer and ask for the

correct method of disposal.

Contents

Package contents .................................................. 2

Installing the speakers ......................................... 3

Installing the front speakers .................................. 3

Installing the center speaker.................................. 3

Installing the surround speakers .......................... 4

Wall-mounting the speakers ................................. 4

Connecting the speakers .....................................5

Connection diagram............................................... 5

Specifications .........................................................6

Produkt Specifikationer

Mærke:	Yamaha
Kategori:	Højttaler
Model:	NS-PA120
Produktfarve:	Sort
Udgangseffekt (RMS):	300 W
Anbefalet brug:	Universel
Lyd-output kanaler:	5.0 kanaler
Strømkilde:	Vekselstrøm
Antal kanaler:	5 kanaler
Frekvensområde for centerhøjttaler:	90 - 46000 Hz
Satellithøjttalere RMS-effekt:	100 W
Antal satellithøjttalere:	2
Satellithøjttaler type:	2-vejs
Frekvensområde for satellithøjttaler:	90 - 46000 Hz
Satellithøjttalerimpedans:	6 ohm (Ω)
Følsomhed for satellithøjttaler:	82 dB
Centerhøjttaler dimensioner (BxDxH):	305 x 125 x 133 mm
Centerhøjttaler vægt:	1800 g
Satellithøjttaler dimensioner (BxDxH):	150 x 99 x 305 mm
Satellithøjttaler vægt:	1800 g
Centerhøjttaler type:	2-vejs
Centerhøjttaler RMS-effekt:	100 W
Følsomhed for centerhøjttaler:	82 dB
Centerhøjttalerimpedans:	6 ohm (Ω)
Forstærkningsenhed inkluderet:	Ingen
Fronthøjttaler type:	2-vejs
Fronthøjttaler, frekvensinterval:	90 - 46000 Hz
Fronthøjttaler, impedans:	6 ohm (Ω)
Fronthøjttaler, sensitivitet:	82 dB
Fronthøjttaler vægt:	4400 g
Fronthøjttalere RMS-effekt:	100 W
Fronthøjttaler dimensioner (BxDxH):	259 x 205 x 1043 mm
Satellithøjttalere kan monteres på væggen:	Ja
Fronthøjttalerne kan monteres på væggen:	Ingen
