Side 1/27

English Français

Deutsch Español

Read this before using the speakers.

•

To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

•

Install the speakers in a cool, dry, clean place – away from

windows, heat sources, sources of excessive vibration,

dust, moisture and cold. Avoid sources of humming

(transformers, motors). To prevent fire or electrical shock,

do not expose the speakers to rain or water.

• To prevent the enclosure from warping or discoloring, do

not place the speakers where they will be exposed to

direct sunlight or excessive humidity.

•Do not place the following objects on the speakers:

Glass, china, etc.

If glass etc. falls by vibrations and breaks, it may cause

personal injury.

A burning candle etc.

If the candle falls by vibrations, it may cause fire and

personal injury.

A vessel with water in it

If the vessel falls by vibrations and water spills, it may

cause damage to the speakers, and/or you may get an

electric shock.

• Do not place the speakers where foreign objects such as

water drips might fall. It might cause a fire, damage to

the speakers, and/or personal injury.

• Do not place the speaker where it is liable to be knocked

over or struck by falling objects. Stable placement will

also ensure better sound performance.

PRECAUTIONS

Thank you for selecting this YAMAHA Soavo-1 speaker system.

• Placing the speakers on the same shelf or rack as the

turntable can result in feedback.

• Never put a hand or a foreign object into the port located

on the front of the speaker as this might cause personal

injury and/or damage to the speaker.

• When moving the speaker, do not hold the port as it

might cause personal injury and/or damage to the

speaker.

• Any time you note distortion, reduce the volume control

on your amplifier to a lower setting. Never allow your

amplifier to be driven into “clipping”. Otherwise the

speakers may be damaged.

•

When using an amplifier with a rated output power higher

than the nominal input power of the speakers, care

should be taken never to exceed the speakers’ maximum

input.

•

Do not attempt to clean the speakers with chemical solvents

as this might damage the finish. Use a clean, dry cloth.

• Do not attempt to modify or fix the speakers. Contact

qualified YAMAHA service personnel when any service

is needed. The cabinet should never be opened for any

reasons.

• As this unit is heavy, whenever it is moved, two people

are requierd to transport it safely.

•Secure placement or installation is the owner’s

responsibility.

YAMAHA shall not be liable for any accident caused

by improper placement or installation of speakers.

The speaker is constructed with the majority of the weight

located in its upper portion, and is thus susceptible to falling

over if proper care is not taken to insure its stability. If the

speaker falls over, it may damage the speaker or be the

cause of injury (or even death) to persons and/or damage to

personal property.

PRECAUTIONS WHEN POSITIONING

For safe and proper use of the speaker:

• Position the speaker in a location that is solid, level,

smooth, and low (with respect to the floor).

• Do not push or apply pressure to the side of the speaker

when moving, or lean objects against the side of the

speaker.

• Do not sit on or set objects on top of the speaker.

• Do not remove the stands attached to the bottom of the

speaker as this might cause the serious accidents,

resulting from falling over of the speaker.

Vibrations or jolts associated with earthquakes and other

phenomena or activities may cause the speaker to fall over.

For safety reasons, using commercially available products

that increase stability in the speaker is recommended

(metal fittings or chains, etc.).

Soavo-1 Speaker System

OWNER’S MANUAL

URGT

Attach the spikes at the four point on the speaker stand

to increase stability and improve sound quality.

How to attach the spikes:

1Lay down this unit on the floor.

2Turn the nut and position it near the tip of the spike.

3Screw the spikes into the hole of the stands.

Place the speaker in the desired location in an upright

position and adjust the length of the spike to match

the depth of the carpet. (repeat step 1, 2 and 3.)

5When adjustment is finished, turn the nut up to the

base of the stand firmly.

Notes

•The tips of the spikes may scratch or damage the

flooring. Please be careful when positioning the

speakers.

•Do not push or lean against the speaker to prevent

falling over, which may cause damage to this unit

or personal injury.

•As this unit is heavy, whenever it is moved, two

people are requierd to transport it safely.

FEATURES

Nut x 4

■ Using as 2ch stereo speakers

Better stereo images will be obtained when the speakers

are slightly angled in towards the listeners.

■ Using as front speakers in a multi channel

system

Position the speakers on both sides of the TV. The

positioning of speakers is important, because it controls the

whole sound quality of a multi channel system. Set up the

speakers on the basis of your listening position by following

the owner’s manual supplied with your amplifier.

Notes

• These speakers feature a magnetically shielded

design, but there is still a chance that placing them

too close to a TV set might impair picture color or

buzzing noise. Should this happen, move the

speakers away from the TV set.

• Do not remove the stands attached to the bottom of

the speaker as this might cause the serious

accidents, resulting from falling over of the speaker.

Subwoofer

Center

Soavo-1

Surround

PLACING THE SPEAKERS

• Type: 3-way, 4-speaker bass-reflex floor standing tower speaker for main channels. Aluminum diecast stand

included.

• Woofer: Dual 16 cm A-PMD cone, Midrange: 13 cm A-PMD cone, Tweeter: 3 cm Aluminum dome.

When setting up this unit on a thick

carpet etc.

Spike x 4

Produkt Specifikationer

Mærke:	Yamaha
Kategori:	Højttaler
Model:	Soavo-1
Bredde:	349 mm
Vægt:	27000 g
Produktfarve:	Sort
Udgangseffekt (RMS):	200 W
Dybde (med stativ):	487 mm
Højde (med stativ):	1051 mm
Frekvensområde:	35 - 50000 Hz
Impedens:	6 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	3-vejs
Lyd-output kanaler:	2.0 kanaler
Højttaler, placering:	Gulv
Diskanthøjttaler:	Ja
Sensitivitet:	89 dB
Diskant diameter:	1 "
Bashøjttaler:	Ja
Forstærker:	Ingen
Woofer diameter (britisk mål):	6.5 "
Basrefleks:	Ja
Mid-range driver diameter (britisk mål):	5 "
