Side 1/9

PLEASE READ CAREFULLY BEFORE PROCEEDING

* Please keep this manual in a safe place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of

serious injury or even death from electrical shock, short-circuiting, damages,

fire or other hazards. These precautions include, but are not limited to, the

following:

• This device contains no user-serviceable parts. Do not open the device or attempt

to disassemble the internal parts or modify them in any way. If it should appear to

be malfunctioning, discontinue use immediately and have it inspected by qualified

Yamaha service personnel.

• Do not expose the device to rain, use it near water or in damp or wet conditions, or

place on it any containers (such as vases, bottles or glasses) containing liquids

which might spill into any openings. If any liquid such as water seeps into the

device, have the device inspected by qualified Yamaha service personnel.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of

physical injury to you or others, or damage to the device or other property.

These precautions include, but are not limited to, the following:

• Do not place the device in an unstable position where it might accidentally fall over.

• Do not place the device in a location where it may come into contact with corrosive

gases or salt air. Doing so may result in malfunction.

• Construction work should be carried out in accordance with construction-related

law and always by a professional constructor. If the device installation requires

construction work, make sure to observe the following precautions.

- Choose mounting hardware and an installation location that can support the

weight of the device.

- Avoid locations that are exposed to constant vibration.

- Use the required tools to install the device.

- Inspect the device periodically.

• When transporting or moving the device, always use two or more people.

Attempting to lift the device by yourself may damage your back, result in other

injury, or cause damage to the device itself.

• Before connecting the device to a power amplifier, turn off the power for all devices.

Before turning the power on or off for all devices, set all volume levels to minimum.

• Use only speaker cables for connecting speakers to the speaker connectors. Use of

other types of cables may result in fire.

• Do not wipe the outer packaging with benzine, thinner, or synthetic detergent and

do not use electrical contact cleaner. These may damage the outer packaging and

dissolve the parts.

• Avoid inserting or dropping foreign objects (paper, plastic, metal, etc.) into holes of

the grille. If this happens, have the device inspected by qualified Yamaha service

personnel.

• Do not operate the device if the sound is distorting. Prolonged use in this condition

could cause overheating and result in fire.

• When choosing a power amplifier for use with this device, make sure that the output

power of the amplifier is lower than the power capacity of this device (see

SPECIFICATIONS).

Even if the output power of the amplifier is lower than the power capacity of this

device (PGM), use of excessive input signals resulting in clipping may cause

damage to the device.

Malfunction or fire may occur especially when the following sounds or noises are

generated:

- feedback, when using a microphone

- continuous and extreme volume sound from a musical instrument

- extreme continuous distorted sound

- noise caused by plugging/unplugging the cable while the amplifier is turned on

PRECAUTIONS

Do not open

Water warning

Location

Connections

Maintenance

Handling caution

NOTICE

To avoid the possibility of malfunction/damage to the product or damage to other

property, follow the notices below.

ƔHandling and Maintenance

• Do not place vinyl, plastic or rubber objects on the device, since this might discolor

the cabinet.

• When cleaning the device, use a dry and soft cloth. Do not use paint thinners,

solvents, cleaning fluids, or chemical-impregnated wiping cloths.

• Condensation can occur in the device due to rapid, drastic changes in ambient

temperature-when the device is moved from one location to another, or air

conditioning is turned on or off, for example. Using the device while condensation is

present can cause damage. If there is reason to believe that condensation might

have occurred, leave the device for several hours until the condensation has

completely dried out.

• Be sure to observe the amplifier’s rated load impedance (see SPECIFICATIONS),

particularly when connecting speakers in parallel. Connecting an impedance load

outside the amplifier’s rated range can damage the amplifier.

• When connecting the speakers with high impedance, be sure that the output total of

each speaker does not exceed the rated output of the power amplifier.

• ABOUT THE PROTECTION CIRCUIT

This speaker system has an internal protection circuit that shuts off the speaker unit

when an excessive input signal is applied.

If the speaker unit emits no sound, reduce the volume level of the amplifier

immediately.

The sound will return automatically in several seconds.

• Place the speaker on a flat and smooth surface.

ƔAbout This Manual

The illustrations as shown in this manual are for instructional purposes only, and may

appear somewhat different from those on your device.

Yamaha cannot be held responsible for damage caused by improper use or

modifications to the device.

Information for Users on Collection and Disposal of Old Equipment

This symbol on the products, packaging, and/or accompanying

documents means that used electrical and electronic products

should not be mixed with general household waste.

For proper treatment, recovery and recycling of old products, please

take them to applicable collection points, in accordance with your

national legislation and the Directives 2002/96/EC.

By disposing of these products correctly, you will help to save

valuable resources and prevent any potential negative effects on

human health and the environment which could otherwise arise from inappropriate

waste handling.

For more information about collection and recycling of old products, please contact

your local municipality, your waste disposal service or the point of sale where you

purchased the items.

[For business users in the European Union]

If you wish to discard electrical and electronic equipment, please contact your dealer

or supplier for further information.

[Information on Disposal in other Countries outside the European Union]

This symbol is only valid in the European Union. If you wish to discard these items,

please contact your local authorities or dealer and ask for the correct method of

disposal.

Owner’s Manual

Surface Mount Speaker

English

ZG14070

UNPACKING

Unpack the contents and confirm that all the following items are included.

• Speaker × 1

• Bracket base × 1

• Mounting bracket × 1

• Captive washer screw × 4

• Rubber spacer × 4 (14 mm thickness)

• Hexagon bolt × 4

• Spring washer × 4

• Flat washer × 4

• Safety wire × 1

• Owner’s Manual (this manual)

* Screws/bolts to fasten the bracket onto the wall and speaker cables are not included.

SPECIFICATIONS

*1: Half-space (2π)

*2: Calculated based on power rating and sensitivity, exclusive of power compression.

*3: Impedance lower limit (per satellite output) VXS10S/VXS10SW: 4 Ω, VXS10ST/VXS10STW: 8 Ω

The contents of this manual apply to the latest specifications as of the printing date. Since Yamaha makes continuous improvements to the product, this manual

may not apply to the specifications of your particular product. To obtain the latest manual, access the Yamaha website then download the manual file. Since

specifications, equipment or separately sold accessories may not be the same in every locale, please check with your Yamaha dealer.

The dimensions are shown overleaf.

VXS10S/VXS10SW VXS10ST/VXS10STW

Type Subwoofer, Bass reflex

Component 10" (25 cm) Cone driver, Dual voice coil

Nominal impedance 8 Ω + 8 Ω –

Power rating NOISE 100 W + 100 W –

PGM 200 W + 200 W –

MAX 400 W + 400 W –

Sensitivity (1W, 1m) *196 dB SPL 96 dB SPL

Maximum SPL (Calculated, 1m) *2125 dB SPL –

Frequency range (-10 dB) *145 Hz – 250 Hz 45 Hz – 250 Hz

Subwoofer filter Network: Low-pass filter 6 dB/Oct, 200 Hz

Acoustic filter: Low-pass filter 6 dB/Oct, 200 Hz

Satellite filter Network: High-pass filter 6 dB/Oct, 200 Hz

Satellite impedance 8 Ω load per satellite output recommended *

Connector Euroblock (4 pin) × 1:

Input (CH1: +/-, CH2: +/-)

Euroblock (4 pin) × 1:

Input (input: +/-, loop-thru: +/-)

Euroblock (4 pin) × 1: Satellite output (ST1: +/-, ST2: +/-)

– Euroblock (5 pin) × 1: transformer taps

Transformer taps 70 V – 200 W, 100 W, 50 W, 25 W

100 V – 200 W, 100 W, 50 W

Overload protection Full-range power limiting to protect network and transducers

Magnetically shielded No

Enclosure Shape Rectangle

Cabinet material MDF

Finish VXS10S/VXS10ST: Black (PVC, approximate value: Munsell N3)

VXS10SW/VXS10STW: White (PVC, approximate value: Munsell 3.5PB9.0/1)

Dimensions (Speaker only) 260 × 500 × 389 mm (10.2" × 19.7" × 15.3")

Net weight (Speaker only) 16.5 kg (36.4 lb) 19.5 kg (43.0 lb)
