Side 1/3
Device Power Supply PoE Total Power
RCH80 PoE/PoE+ 130 W
RCH240 PoE/PoE+ 370 W
Device Power Supply Methods PoE Port Rated Power
UVC86 DC/POE 25 W
SmartVision 80 DC/POE 25 W
CM50 POE 19.3 W
CM20 POE 9 W
CS10/CS10-D POE 24 W
CT200 POE 10 W
EN300 DC/POE 7.5 W
DE300 POE 8.5 W
Introduction
To set up your Pro AV system, a switch with multicast capability and audio and video management
functions is required. The switch must be compatible with the Yealink AV One solution. Yealink
RCH80/RCH240 is the recommended option.
Network: Multicast-capable AV-managed switch compatible with Yealink AV One audio/video
solution, enabling plug-and-play deployment for basic scenarios.
Transmission rate: Supports at least Gigabit (1Gbps) speed.
Features:
Supports PoE power delivery (Energy-Efficient Ethernet/EEE disabled by default).
Multicast configuration: IGMP snooping, IGMP querier, and IGMP query interval.
Supports unknown multicast discard and fast leave functions.
NOTE: The total rated power consumption of connected devices must not exceed the switch's
maximum PoE output capacity (recommended 10% power headroom, 20% for optimal safety
margin).
Device Power Supply
Different devices in the Yealink AV One solution can be powered either via PoE or DC adapters.
The following tables help you estimate the PoE requirements when planning your network.
PoE Total Power
Individual Device Power Ratings
Device Power Supply Methods PoE Port Rated Power
AVBridge POE 13 W
RCH80 (Max 130W) RCH240 (Max 370W)
Recommended Reference Solution
The following are two reference solutions that show how to connect devices with RCH80 and
RCH240.
EN300 x 1: DC
DE300 x 1: 8.5W
CM20 x 1: 9W
CS10/CS10-D x 2: 48W
AVBridge x 1: 13W
Camera x1: 30W
Total PoE Power: 109W
Ports needed: 7
CT200 x 1: 10W
EN300 x 2: DC
DE300 x 2: 17W
CM50 x 2: 39W
CS10/CS10-D x 6: 144W
Camera x 3: 90W
AP08 x 1: AC
Total PoE Power: 300W
Ports needed: 17
Switch Configuration
This chapter introduces the configuration of the network environment in the Pro AV system, using
RCH240 as an example. The configuration method for RCH80 is the same.
Access the Switch Configuration Interface
Step 1: Physical Connection
Connect your computer’s Ethernet port to any port on the switch using a network cable.
Step 2: Configure the Computer’s IP Address
Open Network Settings on your computer and manually configure the USB network
adapter/IP address:
IP Address: 192.168.0.100 (must be in the same subnet as the switch’s management IP)
Subnet Mask: 255.255.255.0
Default Gateway: only required for cross-subnet management.
Step 3: Access the Web Management Interface
1. Open a browser (Chrome/Firefox recommended) and enter the switch’s default management
address (http://192.168.0.1).
2. Change the login password upon first login, then log in again using the new password (The
default username and password are admin).
Cascaded Setups
Step 1: Resolving IP Conflicts in Cascaded Setups
If multiple switches are cascaded, modify each switch’s management IP to avoid conflicts. For
example:

Produkt Specifikationer

Mærke: Yealink
Kategori: Videokonferencesystem
Model: RCH240
